Page 1 Business IP Range Administration and Provisioning Manual Temporis IP100/ IP150/ IP151/ IP251G/IP300/ IP301G/ IP700G/ IP701G Alcatel IP2015/ IP2115 Conference IP1850 Edition 2.2, Oct 2016...
Page 2: Parts Checklist
Congratulations on your purchase of this Alcatel product. Before using it, please read Important Safety Information on page 246 of this manual. Please thoroughly read this manual for all the feature operations and troubleshooting information necessary to install and operate your new product. You can also visit our website at alcatel-business.com.
Page 3: Table Of Contents
Getting started ......................8 Temporis IP100 ..................... 9 Quick reference guide ..................9 Programmable Keys ..................10 Temporis IP150 (M) ..................... 11 Quick reference guide ..................11 Programmable Keys ..................12 Temporis IP151 ....................13 Quick reference guide ..................13 Programmable Keys ..................
Page 4 Find IP address ....................48 Static IP configuration ..................48 VLAN configuration ................... 48 Enable VLAN ....................48 Disable VLAN ....................49 Setting up IP300/IP301G/IP700G/IP701G with IP70H accessory DECT headset ... 50 Register a DECT headset ................... 50 Deregister a DECT headset ................50 Deregister a DECT headset without a deskset ............
Page 5 Basic Network Settings (IPv4) ................141 Basic Network Settings (IPv4/IPv6) ............... 142 Advanced Network Settings .................. 146 Contacts ....................... 150 Local Directory ....................150 Directory Import/Export ................... 152 Directory Import using configuration files ............153 Black List ......................154 Black List Import/Export ................... 155 Black List Import using configuration files ............
Page 6 “speed_dial” Module: Speed Dial Settings .............. 228 “audio” Module: Audio Settings ................229 “file” Module: Imported File Settings ..............230 “xml_app” Module: XML App Settings ..............232 “system_event” Module: Action URI Settings ............233 “tr069” Module: TR-069 Settings ................234 “tone”...
Page 7: Introduction
Temporis IP100, Temporis IP150, Temporis IP151, Temporis IP251G, Temporis IP300, Temporis IP301G, Temporis IP700G, Temporis IP701G, all IP3xx and IP7xx bundles with cordless accessories, Alcatel IP2015, Alcatel IP2115 and Conference IP1850. Please read this guide before installing the telephone.
Page 8: Getting Started
Getting started Alcatel business IP range includes full-featured business phones designed to work with popular SIP telephone (IP PBX) services. Once you have ordered and configured your SIP service, the device enables you to make and receive calls as you would with any other business phone.
Page 9: Temporis Ip100
See also Programmable Keys on page 15. Directory card To write names on the directory card, pull out the directory card from under the plastic cover. A fill-in printable template is available at extranet.alcatel- business.com RJ9 Corded headset input (on side) Access F11 To F20 Press F5 to switch to the second possible value of a programmable key.
Page 10: Programmable Keys
* You can assign more than one key to a certain type of function. For example, you can configure keys 1 and 2 to access Line 1. Label the keys appropriately for deskset users after configuration. A printable fill-in template is available for download at extranet.alcatel- business.com To assign functions to programmable keys, please see Programmable Function Keys on page 118.
Page 11: Temporis Ip150 (M)
Dual 10/100 Mbps Ethernet ports with Power over Ethernet 100-entry Call Log, downloadable local and LDAP phonebooks While Temporis IP150 supports PoE, Temporis IP150M does not and requires a power supply to work. Apart from this difference, they are exactly the same in terms of features, firmware and configuration.
Page 12: Programmable Keys
See also Programmable Keys on page 15. Directory card To write names on the directory card, pull out the directory card from under the plastic cover. A fill-in printable template is available at extranet.alcatel- business.com RJ9 Corded headset input (on side) Access F11 To F20 Press F5 to switch to the second possible value of a programmable key.
Page 13: Temporis Ip151
IP150. Please refer to Temporis IP150 Quick reference guide chapter on page 11. Programmable Keys Usage and default values are the same as in IP150. Please refer to Temporis IP150 Programmable Keys chapter on page 12. Business IP Range Administration and Provisioning Guide ed 2.2...
Page 14: Temporis Ip251G
Temporis IP251G Temporis IP251G is an entry level business phone. Its features include: 2.5-inch backlit Liquid Crystal Display Speakerphone, Headset, Hold and Mute Up to 2 SIP Registrations Up to 6 active SIP sessions 3-way conferencing, N-way network conferencing 2 programmable keys with bicolor led backlight Customizable softkeys, hardkeys, logo, ringtone and language, XML browser, action urls 10 speed dial numbers (long press dial keypad) Message Waiting alert LED...
Page 15: Programmable Keys
Redial Press to access redial list Voicemail Press to access Voicemail menu The deskset external features that are relevant to installation and configuration are described below. Programmable keys with backlight Can be programmed to perform various functions or access various features. For example: Press to access a line to make a call Press to dial a monitored extension or a quick-dial number...
Page 16: Temporis Ip300
Temporis IP300 Temporis IP300 is a mid-range business phone with cordless capabilities. Its features include: 2.5-inch backlit Liquid Crystal Display Speakerphone, Headset, Hold and Mute Up to 3 SIP Registrations Up to 6 active SIP sessions 3-way conferencing, N-way network conferencing IP70H DECT headset and IP15 DECT handset support 12 dual-function programmable keys with bicolor led Customizable softkeys and logo...
Page 17: Programmable Keys
Directory card To write names on the directory card, pull out the directory card from under the plastic cover. A fill-in printable template is available at extranet.alcatel-business.com 2.5mm corded headset input (on side) Access F13 to F24 Press this key to switch to the second possible value of a programmable key.
Page 18: Temporis Ip301G
Temporis IP301G Temporis IP301G is a mid-range business phone with cordless capabilities. Its features include: 2.5-inch backlit Liquid Crystal Display Speakerphone, Headset, Hold and Mute Up to 3 SIP Registrations Up to 6 active SIP sessions 3-way conferencing, N-way network conferencing IP70H DECT headset and IP15 DECT handset support 12 dual-function programmable keys with bicolor led Customizable softkeys, hardkeys, logo and ringtone, XML browser, action urls...
Page 19: Temporis Ip700G
Temporis IP700G Temporis IP700G is a feature business phone with cordless capabilities. Its features include: 3.5-inch backlit Liquid Crystal Display Speakerphone, Headset, Hold and Mute Up to 6 SIP Registrations Up to 6 active SIP sessions 3-way conferencing, N-way network conferencing IP70H DECT headset and IP15 DECT handset support 16 dual-function programmable keys with bicolor led Customizable softkeys and logo...
Page 20: Programmable Keys
Directory card To write names on the directory card, pull out the directory card from under the plastic cover. A fill-in printable template is available at extranet.alcatel-business.com 2.5mm corded headset input (on side) Access F13 to F24 Press this key to switch to the second possible value of a programmable key.
Page 21: Temporis Ip701G
Temporis IP701G Temporis IP701G is a feature business phone with cordless capabilities. Its features include: 3.5-inch backlit Liquid Crystal Display Speakerphone, Headset, Hold and Mute Up to 6 SIP Registrations Up to 6 active SIP sessions 3-way conferencing, N-way network conferencing IP70H DECT headset and IP15 DECT handset support 16 dual-function programmable keys with bicolor led Customizable softkeys, hardkeys, logo and ringtone, XML browser, action urls...
Page 22: Programmable Keys
Directory card To write names on the directory card, pull out the directory card from under the plastic cover. A fill-in printable template is available at extranet.alcatel-business.com 2.5mm corded headset input (on side) Access F13 to F24 Press this key to switch to the second possible value of a programmable key.
Page 23: Alcatel Ip2015/Ip2115
Alcatel IP2015/IP2115 Alcatel IP2015/IP2115 are multiline multi-handset IP DECT systems. Basic package includes one base and one handset. IP2015/IP2115 features include: Out-of-sight, wall mountable, PoE enabled base station Up to 6 independent SIP Registrations Up to 6 IP15 handsets supported per base, with over-the air sw upgrade (SUOTA)
Page 24 Although there are often dedicated menu items, navigation key also provides shortcuts to the following functions: DIR/VOL + In idle mode press to quickly access CID/VOL - Contacts menu In idle mode press to quickly access Call Logs menu When in a call press to increase received audio volume When in a call press to decrease received audio...
Page 25: Conference Ip1850
Conference IP1850 Conference IP1850 is an advanced audioconference device. Its features include: Wideband, high power speaker 2 embedded microphones 4 detachable wireless microphones with built-in charging cradle 2.5-inch backlit Liquid Crystal Display Up to 3 SIP Registrations Up to 6 active SIP sessions 3-way conferencing, N-way network conferencing, hold, mute, transfer USB connector for PC audio device mode Customizable softkeys and logo...
Page 26 On the wireless microphones you have the following elements: Remove and activate mic Push gently on the arrow area to remove the microphone from its cradle. MUTE Please note wireless mics are deactivated In conversation, press to while on their cradle. For best user temporarily deactivate experience, if users are located at or (mute) all microphones.
Page 27: Network Requirements
Network Requirements A switched network topology is recommended for your LAN (using standard 10/100 or 10/100/1000 Ethernet switches). The office LAN infrastructure should use Cat.-5 (or better) cable for 10/100, and Cat.-6 for 10/100/1000. The LAN connections to the devices(s) should all be wired. However, wireless connections to other devices (such as laptops) in your office will not impede performance.
Page 28: Installation
If you are not using PoE, install the phone near a power outlet not controlled by a wall switch. The phone can be placed on a flat surface or vertically mounted on the wall. For customer service or product information, visit our website at extranet.alcatel- business.com.
Page 29 NOTE: You may need to use a network switch connected to your router if your router does not have sufficient ports for the number of phones you want to install. If you use a network switch, connect the phone to the switch instead of the router in the previous step.
Page 30 To mount the phone on the wall: 1. Disassemble the foot stand 2. Install wall mount fittings and foot stand as displayed: 3. Put the corded handset aside. Use a coin to rotate the handset tab 180 degrees. The protruding edge holds the corded handset when the phone is mounted on the wall. 4.
Page 31: Temporis Ip251G/Ip300/Ip301G/Ip701G Installation
Temporis IP251G/IP300/IP301G/IP701G installation To install the phone: 1. If you plan to place the phone on a flat surface, you can use one of the two available positions depending on the work angle you wish to have. To assemble the stand line up the tabs on the stand (marked with lozenges) with the slots on the rear of the phone as shown in the picture Plug the end of the coiled handset cord into the Handset jack at the back of the phone.
Page 32 IMPORTANT INFORMATION 1. Use only original power adapters. Contact your distributor to order. 2. The power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.
Page 33: Temporis Ip700G Installation
Temporis IP700G installation To install the phone: 1. If you plan to place the phone on a flat surface, you can use one of the multiple available positions depending on the work angle you wish to have. Simply adjust the foot stand with the slots on the rear of the phone as shown in the picture 2.
Page 34 a. Connect the power adapter to the deskset power jack. b. Plug the power adapter into an electrical outlet not controlled by a wall switch. IMPORTANT INFORMATION 1. Use only original power adapters. Contact your distributor to order. 2. The power adapter is intended to be correctly oriented in a vertical or floor mount position.
Page 35: Alcatel Ip2015/Ip2115 Installation
Alcatel IP2015/IP2115 installation To install the base: 1. Plug one end of the Ethernet cable into the Ethernet port at the side of the base, and plug the other end of the cable into your network router or switch. NOTE: You may need to use a network switch connected to your router if your router does not have sufficient ports for the number of phones you want to install.
Page 36: Conference Ip1850 Installation
IMPORTANT INFORMATION 1. Use only supplied power adapters and battery pack. 2. The power adapter is intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.
Page 37 To install the wireless microphones: 1. For each microphone, activate the battery by pulling away the plastic tag, or insert the battery into its compartment. 2. Place the microphones on the charging cradles NOTE: If the microphone unit does not turn on when plastic tag is removed, take the battery out, reinsert and charge for 8 hours.
Page 38 To associate a new wireless microphone: Your IP1850 is shipped with all four wireless microphones already associated to the main unit. In the unlikely event you need to replace any of them, you will find herewith instructions to associate a new microphone. 1.
Page 39: Configuring Your Device
Configuring your device You can configure your device using three methods: From the phone itself, using the menus. The phone menus are best suited to configuring a few settings, perhaps after the initial setup has been done. For administrators, the settings available on the phone menus menu include network, account, and provisioning settings.
Page 40: Configuring Programmable Keys
Note “Line” softkey will be shown only if you have configured and registered more than one sip account. Configuring Programmable keys Temporis IP100, IP150, IP151, IP251G, IP300, IP301G, IP700G and IP701G models are equipped with programmable keys with a dual-color backlight (orange and green).
Page 41: Led Behavior
A PFK can be assigned one of the following functions: Line Directory Call History Redial Messages Do not disturb Quick Dial BLF—Busy lamp field keys let you monitor activity at other phones. The key LED indicates call status. Call Forward Unconditional Call Forward Busy Call Forward No Answer Call Forward All...
Page 42 Do Not Disturb DND is off Steady ORANGE DND is on Call Forward Call forwarding is off Steady ORANGE Call forwarding is on Page Steady GREEN Outgoing page in progress Busy Lamp Field Monitored phone is idle Steady ORANGE Monitored phone is on a call or has a held call The monitored phone is ringing Quickly flashing ORANGE...
Page 43: Adding A Custom Logo
The behavior described below is enabled by default and can be modified or disabled using the configuration files. For Temporis IP150, IP151, IP251G, IP300, IP301G and Conference IP1850 you can enable the idle mode logo to appear instead of the idle screen after a specified period of inactivity.
Page 44: Uploading A Custom Logo
See “file” Module: Imported File Settings on page 230 for more details about these parameters. Custom logo user interactions For Temporis IP150, IP151, IP251G, IP300, IP301G and Conference IP1850 users, pressing any hard key will exit the idle logo and perform the key’s function. For example, pressing MENU will show the Main Menu.
Page 45: Customizing Softkeys
Customizing Softkeys For Temporis IP150, IP151, IP251G, IP300, IP301G, IP700g, IP701G and Conference IP1850, configuration file allows you to select which soft keys should appear on the Idle screen, Active Call screen, Held Call screen and Live Dial screen. You can also specify the position of each soft key.
Page 46 Line (visible with more than one account registered) Line Settings Settings Call Active Blank Park Call Park Hold Hold Transfer Transfer Conf Conf XferLine (visible with more than one call) XferCall ConfLine (visible with more than one call) ConfCall hs_pick (visible on IPx01G when a HS is registered) HS_Pick Call Held Blank...
Page 47: Custom Soft Key Configuration File Settings
Redial Redial Messages Message Dial Dial Input (alpha/numeric selection for text input mode) Cancel Cancel Backspc Backspc Custom Soft Key Configuration File Settings The custom soft keys parameters are included in the “softkey” module. For more information, see “softkey” Module: Custom Soft Key Settings on page 239. To modify a soft key parameter, enter values separated by commas.
Page 48: Setting Up Temporis Ip100 Phone
Setting up Temporis IP100 phone Temporis IP100 has specific management procedures due to its simpler user interface without a display. You can configure the phone using one of three methods:  From the phone itself, using the “star codes” to setup very few network related parameters.
Page 49: Disable Vlan
* 7 8 2 8 4 3 # 1 # x #. Where x is the Vlan ID. A confirmation tone will be played on the telephone loudspeaker before the phone applies the new VLAN configuration. No reboot is needed. Disable VLAN When the phone is idle mode, type on the keyboard the following sequence: * 7 8 2 8 4 3 # 0 # #...
Page 50: Setting Up Ip300/Ip301G/Ip700G/Ip701G With Ip70H Accessory Dect Headset
Setting up IP300/IP301G/IP700G/IP701G with IP70H accessory DECT headset Temporis IP300, IP301G, IP700G and IP701G models embed a DECT base which allows you to use compatible cordless accessories. You can register and use up to one IP70H accessory headset and one IP15 accessory handset. Note MMI options are the same for IP30x and IP70xG despite the different display size.
Page 51: Deregister A Dect Headset Without A Deskset
Deregister a DECT headset without a deskset You can use this method when you cannot use the deskset for standard deregistration. The deskset may be out of range or may have been removed from the system. On the headset, press VOL+>ON/OFF>VOL->ON/OFF>VOL+>VOL->ON/OFF Deskset functionality with an IP70H DECT headset With IP70H registered to IP300, IP301G, IP700G or IP701G, users can: ...
Page 52: Deregister A Dect Handset
5. With Register highlighted, press OK on the deskset. Registering…. appears while the deskset searches for the handset When registration is complete, Registration succeeded will be displayed and the handset will display its idle screen. If the handset you are registering to the deskset is equipped with an IP15 firmware version, then you will see a message prompting you to upgrade it for a better compatibility.
Page 53: Setting Up Ip2015/Ip2115 With Multiple Ip15 Handsets Or Ip70H Wireless Headsets
Setting up IP2015/IP2115 with multiple IP15 handsets or IP70H wireless headsets Alcatel IP2015/IP2115 IP DECT systems support up to six wireless devices (IP15 handsets or IP70H headsets), six independent sip accounts, and a maximum of four concurrent calls in wide band.
Page 54: Assigning Sip Accounts To Ip15 Handsets Or Ip70H Headsets
After a few seconds your headset should be subscribed and show only the red or blue lights, depending on battery charge status Note: If the cordless headset is registered to another phone, it must be deregistered first. See “Deregistering a DECT headset”. To rename a handset/headset: Handset name can be modified to suit your needs.
Page 55: Ip2015/Ip2115 Functionality With Ip15 Dect Handsets
IP2015/IP2115 functionality with IP15 DECT handsets With one or more handsets (IP15) registered to IP2015 base, users can:  Select dialing line for a call with LINE softkey  Use the handset’s local directory, or the base’s directories (local, LDAP, black list) ...
Page 56: Using Menu In Your Desktop Phone
Using Menu in your desktop phone Your desktop phone Temporis IP150/IP151/IP251G/ IP300/ IP301G/ IP700G/ IP701G or Conference IP1850 menu have four main sub-menus: Features—manage calls, view and add directory entries, view call history, access messages, and use the speed dial menu.
Page 57 Line 1 3.Block Anonymous … ON/OFF Line n Line 1 4.Dial Anonymous … ON/OFF Line n Yes/No 5.Missed Call Alert Yes/No 6.Call waiting Line 1 Yes/No 7.Auto-answer … Note 1 Line n Entries Search, sort, add, delete, 2. Directory 1.Local delete all, dial, edit, number type Entries...
Page 58: Status
Note 1: Item applicable to IP151, IP251G, IP301G, and IP701G only Status Use the status menu to verify network settings and begin troubleshooting if network problems or account registration issues affect phone operation. You can also find the software version of the phone on the Product Info screen, available from the Status menu.
Page 59: Viewing Line Status
Note2: this item is applicable to IP300, IP301G, IP700G, IP701G only Note To view Network status you can also use the following shortcut. In idle mode, press key. On IP251G you can access the same shortcut by pressing Viewing Line status When you select Line from the Status menu, the Line menu appears, listing the available lines along with icons indicating each line’s current registration status.
Page 60: Customizing Your Phone With User Settings Menu
Customizing your phone with User Settings menu User Settings menu allows easy customization of some aspects of the phone, e.g. language, time and date, preferred ring tone, setting programmable keys or DECT accessories configuration. To view the User Settings menu: 1.
Page 61: Using The Admin Settings Menu
Key 1 Function key type 4. Program Keys Key 2 selection list (May differ) … 1. Line Key m 2. Directory 3. Call History 4. Redial 5. Messages 6. Do not Disturb 7. Call Forward All 8. Call Fwd No answer 9.
Page 62 2. Press  or  to highlight Admin Settings, then press OK. -or- Press 4 (Admin Settings) on the dial pad. 3. Use the dial pad to enter the admin password, the press OK. The default password is admin. The Admin Settings are: Setting Options 1.
Page 63: Network Settings (Ipv4)
Network settings (IPv4) This chapter is applicable for models Temporis IP150, IP300, IP700G, IP1850 Use the Network setting menu to configure network-related settings for the phone. Note: After you confirm any of the network settings, the phone may restart. To use the Network setting menu: 1.
Page 64 3. Press  and enter the Subnet Mask. Use BACKSP softkey, digit dial pad and ”*” key to enter characters and dots. 4. Press  and enter the Gateway. Use BACKSP softkey, digit dial pad and ”*” key to enter characters and dots. 5.
Page 65: Network Settings (Ipv4/Ipv6)
4. Press  and enter the IP address or url for the NTP server. Use BACKSP softkey and dial pad to enter characters and dots. 5. If the base or desktop phone does not use an NTP server, you must manually enter the time and date settings in User settings menu.
Page 66 To set the network mode:   From the Network setting menu, press to highlight your network type (IPv4 or IPv6), and then press SELECT. The selected network type screen appears (IPv4 menu shown below). IPv4 1.Mode 2.Set Static IP 3.Set Static DNS 4.Set PPPoE Back...
Page 67 Set static IP Subnet Mask: Gateway: DNS 1: DNS 2: Cancel Backspc Add dot Save 4. Press  and enter the Subnet Mask. Use the dial pad and the Add dot soft key to enter characters. Press  or  to advance to the next character ...
Page 68: Line Menu
From the Network setting menu, press to highlight IPv4 (which must be in PPPoE mode), and then press SELECT. Highlight Set PPPoE and then press SELECT. The Set PPPoE menu appears. Set PPPoE Username: Password: Cancel Backspc Save 5. On the Set PPPoE menu, enter the PPPoE account Username. 6.
Page 69 To use the Line setting menu: 1. From the Admin Settings menu, press  to highlight Line, and then press SELECT. The Line menu appears. 2. Highlight the desired line, if necessary, by pressing , and then press SELECT. The full configuration menu for that line appears. You can configure: ...
Page 70: Provisioning Menu
Provisioning Menu Use the Provisioning menu to manually configure auto-provisioning settings. For more information about auto-provisioning, see Provisioning on page 173 and Provisioning Using Configuration Files on page 193. On the Provisioning menu you can configure:  Server string—the URL of the provisioning server. The URL can include a complete path to the configuration file.
Page 71  Restricted Config only locks out the menu and voicemail. When Restricted Config is enabled, the following keys/features are restricted: MENU key Settings soft key Messages soft key Messages PFK MESSAGE key  Restricted Call locks out all advanced calling features, including transfer, conference and hold, via hard keys, soft keys and PFKs.
Page 72 Restriction Mode 1.Disable Phone Lock 2.Restricted Config 3.Restricted Call 4.Emergency Call Only Back Select Press  or  to highlight the desired restriction mode, and then press SELECT. The Security menu appears. Press  or  to highlight Enabling Web Server, and then press SELECT. The Enabling Web Server menu appears.
Page 73: Using Menu In Your Ip15 Cordless Handset
Using Menu in your IP15 cordless handset Your cordless handset IP15 menu has nine sub-menus: Message-access voicemail for assigned accounts Directory-access and manage contact directory Call History-access and manage call lists Intercom-launch internal calls to other handsets Speed dial- manage your speed dial list Features—manage calls Status—view the deskset network status, account registration status, and product information.
Page 74 assigned to the handset on IP2x15) Directory Options: Search/Add Local directory new/Delete all/ Review: Dial/Edit/Edit dial/Delete Base directory With IP2015/IP2115 base: Options: Search/Add new/Delete all Review: Dial/Edit/Edit dial/Delete With IP30x/IP70xG deskset: Options: Search Review: Dial, Edit dial LDAP (name depending on Search, Dial, Edit dial, Save configuration) Broadsoft (name depending...
Page 75: Status
Add/Edit/Delete Speed dial … Available or assigned Features accounts list DND status OK to toggle, SET to save Call Forward Available or assigned accounts list CFW statuses OK to toggle, SET to save Available or assigned Block Anonymous accounts list CFW statuses OK to toggle, SET to save Available or assigned...
Page 76: User Settings
Menu Information listed IP address Network DHCP status (Enabled/Disabled) Subnet Mask IP address Gateway IP address DNS server 1 IP address DNS server 2 IP address Line Lines and registration status. On the Line menu, highlight and select the desired line to view detailed line status information: Line status (Registered/Not registered/Disabled) Line display name Line User ID...
Page 77: Admin Settings
Deutsch Nederlands Eλληνικα Date format Edit or select and Set date/time Set date SET/BACK Clock format Set time Phone rename Edit and SET/BACK Contrast (Level 1 to 8) Select and SET/BACK Ringers Ringer Volume Select and SET/BACK Ringer Tones Line 1(Melody 1 to 10) …...
Page 78: Network Settings (Ipv4)
Network settings (IPv4) This chapter is applicable to IP15 when used in conjunction with an IPv4 model (Temporis IP300 or IP700G, Alcatel IP2015 base). Use the Network setting menu to configure network-related settings for the phone. Note: After you confirm any of the network settings, the phone may restart.
Page 79 Set static IP VLAN ID Others (DNS and NTP servers). , then press OK key or ENTER softkey. To enable or disable DHCP: 1. From the Network setting menu, press  or  to highlight DHCP, then press ENTER. 2. Press OK key to toggle between Enabled and Disabled, then press SET softkey. DHCP is enabled by default, which means the base or desktop phone will get its IP address from the network.
Page 80: Network Settings (Ipv4/Ipv6)
Network settings (IPv4/IPv6) This chapter is applicable to IP15 when used in conjunction with an IPv4/IPv6 model (Temporis IP301G or IP701G, Alcatel IP2115 base) Use the Network setting menu to configure network-related settings for the phone. Note: After you confirm any of the network settings, the phone may restart.
Page 81 To use the Network setting menu: 1. From the Admin settings menu, press  or  to highlight Network setting, then press ENTER. The Network setting menu appears. Network setting 1.IPv4 2.IPv6 3.VLAN ID Back Select   Press to highlight the desired option, and then press SELECT: IPv4 ...
Page 82 2. With Mode selected, press SELECT. The Mode menu appears. Mode IP type: DHCP Cancel Save   3. Press to select the network mode for your network type, and then press Save DHCP (IPv4) or Auto (IPv6) is enabled by default, which means the set will get its IP address from the network.
Page 83  Press and enter the IP address for the secondary DNS server. The phone will use this server if the primary server does not respond. Press Save softkey To set static DNS:   From the Network setting menu, press to highlight IPv4 or IPv6 (whichever is in use in Static mode), and then press SELECT.
Page 84 To set the VLAN ID:   From the Network setting menu, press to highlight VLAN ID, and then press zSELECT.   On the VLAN ID menu, press to enable or disable the WAN VLan. VLAN ID WAN VLan: Disabled WAN VID: PC VLan:...
Page 85: Provisioning Menu
Provisioning Menu Use the Provisioning menu to manually configure auto-provisioning settings. For more information about auto-provisioning, see Provisioning on page 173 and Provisioning Using Configuration Files on page 193. On the Provisioning menu you can configure:  Server string—the URL of the provisioning server. The URL can include a complete path to the configuration file.
Page 86: Using The Webui
Using the WebUI The Web User Interface (WebUI or WUI) resides on your phone. You can access it using an Internet browser, either as a user or as an administrator. After you log in to the WebUI, you can configure the phone on different pages. Note the different pages accessible by admin and user profiles, as listed in the following table.
Page 87  Broadsoft   Remote XML phonebook   Call History   Servicing  Reboot   Time and Date   Custom Language   Firmware Upgrade   Provisioning   Security    Certificates  ...
Page 88: Saving Your Settings
e. For Temporis IP100, please see Find IP address on page 48 3. On your computer, open an Internet browser. (Depending on your browser, some of the pages presented here may look different and have different controls.) 4. Type the phone IP address in the browser address bar and press ENTER on your computer keyboard.
Page 89: Status
Status The status page is equivalent to the Status menu on the phone UI. The information page shows different content depending on the model: General information about your phone, including model, MAC address, and software version Account Status information about your SIP account(s) registration Network regarding your phone’s network address and network connection Cordless Status indicating whether a cordless headset and/or handset are registered to the deskset (For DECT enable models).
Page 90: System
System SIP Account Management On the SIP Account Management pages, you can enter the account settings for each line you have ordered from your service provider. There are one or more Account settings pages (one for each available line) with identical settings on each page. The number of pages depends on the model: one for IP100, two for IP150/IP151 and IP251G, three for IP300 and IP1850, four for IP301G, five for IP700G and six for IP701G, IP2015 and IP2115.
Page 91 Display Name appears on the phone display when account x is selected. User identifier Enter the User identifier supplied string blank by your service provider. The User ID, also known as the Account ID, is usually the company's main number and is used as part of the caller ID displayed for outgoing calls.
Page 92 ranges from 2 on IP100 to 10 on IP701G. Page/Intercom Auto Answer Enables the deskset to 0: Disable automatically answer when an 1: Enable intercom request is received. This sip_account.x.auto_answer_enable is usually the desired behavior for paging. Page/Intercom Auto Answer during Enables the desk set to 0: Disable active calls...
Page 93 Unregister after reboot Enables the phone to unregister 0: Disable the account(s) after rebooting— 1: Enable before the account(s) register again as the phone starts up. If other phones that share the same account(s) unregister unexpectedly in tandem with the rebooting deskset, disable this sip_account.x.unregister_after_reboot setting.
Page 94 Setting Description Range Default Server address Enter the IP address or fqdn for IP address blank the SIP server. or fqdn sip_account.x.primary_sip_server_addres Server port Enter the port number that the 0-65535 5060 SIP server will use. sip_account.x.primary_sip_server_port Registration Settings Setting Description Range Default...
Page 95 Backup Outbound Proxy Settings Setting Description Range Default Server address Enter the IP address or blank fqdn for the backup address sip_account.x.backup_outbound_proxy_server_address outbound proxy server. or fqdn Server port Enter the port number 0–65535 5060 that the backup outbound proxy server sip_account.x.backup_outbound_proxy_server_port will use.
Page 96 Audio Settings Setting Description Range Default Ringer Tone Sets the ringer tone for Tone 1–10 Tone 1 incoming calls on the user_pref.account.x.ringer account. Codec Priority 1 Select the codec to be used G.711a, G.711u first during a call. G.711u, G.729, G.726, G.722, sip_account.x.codec_priority.1 ilbc...
Page 97 Codec priority 5 Select the codec to be used None, G.711a, G.722 fifth during a call if previous G.711u, G.729, codecs fail. G.726, G.722, ilbc sip_account.x.codec_priority.5 Enable voice encryption (SRTP) Select to enable secure RTP 0: disable for voice packets. 1: enable sip_account.x.voice_encryption_enabl Enable G.729 Annex B...
Page 98 Transport Select the SIP transport protocol. tls, tcp, TCP (Transmission Control Protocol) is the most reliable protocol and includes error checking and delivery validation. UDP (User Datagram Protocol) is generally faster but SIP data may be subject to network congestion. TLS (Transport Layer Security) transport requires security certificates to establish a secure connection between...
Page 99 Feature Access Codes Settings If your IP PBX or service provider uses feature access codes, then enter the applicable codes here. You can assign many of these features to programmable keys, which enables end users to press the keys to dial out the codes you enter here. Setting Description Assignable...
Page 100 Parked Call Retrieval Enter the call park retrieval access code. Broadsoft and Asterisk/Metaswitch provide a feature access code for park retrieval. sip_account.x.access_code_retrieve_parked_call Call Park variant Supported values are broadsoft and asterisk. The former dials out a feature code, while the latter launches a blind transfer sip_account.x.park_variant to the park code uri...
Page 101 Anonymous Call Reject ON Enter the Anonymous Call Reject ON access code. sip_account.x.access_code_anonymous_call_block_on Anonymous Call Reject OFF Enter the Anonymous Call Reject OFF access code. sip_account.x.access_code_anonymous_call_block_off Anonymous Call ON Enter the Anonymous Call ON access code. sip_account.x.access_code_outgoing_call_anonymous_ Anonymous Call OFF Enter the Anonymous Call OFF access code.
Page 102 Busy Lamp Field Settings Setting Description Range Default List URI Used for list-based BLF Sip URI blank Enter the BLF list URI, as supplied by or set up with your service provider. For example, blf-list1@sipservice.com. This list contains a list of extensions that are eligible for BLF monitoring.
Page 103 If left blank, individual uri-based BLF subscription will be assumed BLF Subscription Expiration Enter desired BLF subscription duration 3600 in seconds. 65535 It is normally 3600 sec sip_account.x.blf_subscription_expire Remote Pickup Code Enter the remote pickup code for the string blank BLF list, as supplied by your service provider.
Page 104 supports unsolicited MWI sip_account.x.mwi_ignore_unsolicited notifications.  you want the Message Waiting LED to indicate new messages when the deskset receives unsolicited MWI notifications. Enable Stutter Dial Tone Enables or disables the stutter dial tone for that line (indicating disable message(s) waiting) when the phone goes off hook.
Page 105 Please disable if you wish to use server provided Music on hold instead. The interval between tones can be controlled with “Call Hold Reminder tone”, in User Preferences section Network Conference Settings Setting Description Range Default Enable Network Conference Enables or disables conferences 0: disable being controlled and mixed by a 1: enable...
Page 106 Jitter Buffer Setting Description Range Default Fixed/Adaptive Toggles between fixed and fixed, adaptive adaptive jitter buffer modes. adaptive audio.x.jitter.mode Fixed Delay (ms) If Fixed is selected, enter the 30-500 fixed jitter delay audio.x.fixed_jitter.delay Normal Delay (ms) If Adaptive is selected, or for 20-500 models not supporting mode audio.x.adaptive_jitter.target_delay...
Page 107: Dial Plan
should be sent whenever the account is registered. OPTIONS traffic will occur periodically according to the keep-alive interval. Keep Alive Interval (secs) Set the interval at which the 90-65535 OPTIONS for the keep-alive sip_account.x.keep_alive_interval mechanism are sent. Ignore Keep Alive Failure Enable the phone to ignore keep- 90-65535 1800...
Page 108 Dialing rules must consist of the elements defined in the table below. Element Description Any dial pad key from 0 to 9, including # and *. [0-9] Any two numbers separated by a hyphen, where the second number is greater than the first. All numbers within the range or valid, excluding # and *.
Page 109: Call Settings
Call Settings You can configure call settings for each line. Call Settings include Do Not Disturb and Call Forward settings. For some models Ringtone selection, Call completion, Auto answer and Customized ringtone upload are also included in this section. When you have finished changing settings on this page, click Save to save them. Call settings are also available as parameters in the configuration file.
Page 110 user_pref.account.x.ringer Sets the ringer tone for incoming calls on the account. Do Not Disturb Settings Setting Description Range Default Enable Do Not Disturb Turns Do Not Disturb on or off. 0: disable 1: enable call_settings.account.x.dnd_enable Incoming Calls Selects whether the phone show, reject displays incoming call information...
Page 111 Enable Call Forward No Answer Enables or disables call 0: disable forwarding for 1: enable unanswered calls on that line. call_settings.account.x.cfna_enable Target Number Enter a number to string blank which unanswered calls will be forwarded. call_settings.account.x.cfna_target Delay Select the number of 1-10 rings before (rings)
Page 112 Auto Answer Setting Description Range Default Enable Auto Answer Enables or disables 0: disable unconditional Auto Answer. Auto 1: enable Answer allows a deskset or conference phone to automatically answer incoming calls to that account without user intervention. An auto call_settings.account.x.unconditional_auto_ answer tone will sound answer_enable...
Page 113: User Preferences
Setting Description Range Default Enable Call Completion Enable or disable the call 0: disable completion feature. Calls to busy 1: enable numbers will prompt a “Retry later?” message on the phone screen. call_settings.account.x.call_completion_ enable Enable Call Completion Alert Enables or disables an audible alert 0: disable (similar to a hold reminder alert 1: enable...
Page 114 The user preference settings are also available as parameters in the configuration file. See “user_pref” Module: User Preference Settings on page 221. Note that, as in previous chapters, some of the settings are model dependent and may or may not appear on your phone’s WUI. General User Settings Setting Description...
Page 115 Phone Language Sets the language that appears on the en: English phone. Not applicable to fr: French IP2015/IP2115. Other languages may es: Spanish be added later de: German it: Italian pt: Portuguese nl: Dutch ru: Russian el: Greek tr: Turkish user_pref.language pl: Polish Backlight Timer (secs.)
Page 116 user_pref.hold_reminder.interva Sets the interval for the call hold 10–300 reminder tone. (seconds) Call Waiting Settings Setting Description Range Default Enable Call Waiting Tone Enables or disables the call waiting 0: disable tone. Select to enable. 1: enable user_pref.call_waiting.tone_enable Call Waiting Tone Interval (secs.) Sets the interval in seconds for the 10–60 call waiting reminder tone.
Page 117 The above operations are server dependent. The server has to support all of the following with Call Park to make one-button operation possible:  Monitoring a park orbit as an extension via BLF subscription (rfc4235)  Remote BLF pickup via one of the two pickup options: -New call via SIP INVITE -Dialog based via SIP INVITE with REPLACE ...
Page 118: Programmable Function Keys
Specify the order and number number,lc available language input _western, uc_western: upper case options when in text uc_wester lc_western: lower case input mode uc_ru: Russian upper case lc_ru: Russian lower case uc_el: Greek upper case user_pref.text_input_option lc_el: Greek lower case Handsfree volume Sets speaker volume for 1-10...
Page 119 Temporis IP70xG “Lower” key You can assign functions to the programmable keys. You can select one option for each physical or virtual key. Keys can have identical functions. For example, you can assign several “Line” keys for Line 1 to enable users to manage multiple calls on Line 1. You can also assign multiple Quick Dial keys.
Page 120 pfk.x.feature = call log Call History Configures the key to access the Call History (x: 1-32, function key number; list. Users can then press the key to view the depends on model) Call History list. pfk.x.feature = redial Redial Configures the key to access the Redial list. (x: 1-32, function key number;...
Page 121 (x: 1-32, function key (FAC) configured on the Account Settings number;depends on model) page. In the Line column, select the line (sip account) on which the feature access code will be dialed out. For example, choose Line 1 if you wish to use the Call Park FAC that you entered for account For some service providers, you must also enter a park extension in the Value column.
Page 122 pfk.x.feature = acd ACD (Automatic Configures the key to display the ACD State pfk.x.account = 1,2, … Call menu on the phone LCD. In the Account Distribution) column, select the applicable account. The key (x: 1-32, function key number; depends on model) LED will indicate the current ACD state.
Page 123 (x: 1-32, function key number; the account configured for the PFK. The digits depends on model) entered under Value are concatenated to any number that the user enters. The outgoing call will include the [Prefix] + [Dialing string]. The Prefix digits are hidden from the user. The prefix digits are visible during Dialing and Call Active states.
Page 124: Programmable Hard Keys
pfk.x.feature = lock_key Phone Lock Configures the key to enable or disable the phone lock. For more information, see Security section pfk.x.feature = unassigned The programmable key has no function pfk.x.account = 1,2… assigned (x: 1-32, function key number; depends on model) Programmable Hard Keys Temporis IP151, IP251G, IP301G and IP701G models are equipped with programmable hard keys.
Page 125 Please refer to Programmable Function Keys chapter and to “pfk” Module: Programmable Feature Key Settings for more details. Business IP Range Administration and Provisioning Guide ed 2.2 125/247...
Page 126: Memory Keys: Speed Dial
Memory Keys: Speed Dial Applicable to Temporis IP100, IP150, IP151, IP251G, IP300, IP301G, IP700G, IP701G and Conference IP1850. On the Speed Dial page, you can enter up to 10 speed dial numbers. For each speed dial number you enter, you must assign the line on which the number will be dialed out. To dial a speed dial number, press and hold the dial pad key that matches the speed dial entry number.
Page 127: Signaling Settings
speed_dial.x.number (x: 0-9) Line The SIP account (line) the phone will 1: Acc 1, use to dial the number. 2:Acc 2, speed_dial.x.account (x: 0-9) Signaling Settings Applicable to Temporis IP100, IP150, IP300, IP700G, IP2015 and Conference IP1850. Voice Settings Setting Description Range Default...
Page 128: Ringer Settings
Enable IP Masquerading Select to enable NAT 1: Enabled traversal via IP 0: Disabled masquerading. network.nat.masquerading_enable Public IP address Enter the external IP IP address blank address of your router. Your router needs a static network.nat.public_ip_addr IP address for IP masquerading to work.
Page 129 Setting Description Range Default Distinctive Ringing Text Enter the text that will String, up to blank match the “info” parameter 40 characters and play the ringer tone. The matching of the “info” parameter and Internal Ringer Text is case sensitive. The maximum ringersetting.x.ringer_text length of the Internal Ringer Text is 40 characters.
Page 130: Paging Zone
Paging Zone Applicable to Temporis IP100, IP150, IP151, IP251G, IP300, IP301G, IP700G, IP701G and Conference IP1850. On the Paging Zone page, you can enter the multicast IP addresses that the phone will monitor. When a page is sent out using this multicast IP address, all phones that are programmed to monitor that IP address will receive the paging RTP stream and play the page on their speakerphone.
Page 131 Multicast Port Enter the multicast port 0-65535 blank used by the multicast IP address. The valid port range is 1 to page_zone.x.multicast_port 65535. (x= page zone ID number, 1 to 10) Priority Select the paging zone 1-10 priority from 1 to 10. Zones with a priority higher than another zone can interrupt the...
Page 132: Server Applications
Server applications This feature applies to models IP151, IP251G, IP301G, and IP701G. On the Server Application page, you can enter Action URIs to allow your desk set to interact with a server application by using an HTTP GET request. The action URI triggers a GET request when a specified event occurs.
Page 133 The table below lists all possible variable values. Note that variables applicable during an Incoming or Active Call (such as INCOMINGNAME and REMOTENUMBER) are initialized at the beginning and at the end of the call. Variable value Description SIPUSERNAME SIP Account User Identifier DISPLAYNAME SIP Account Display Name LOCALIP...
Page 134 Action URI Setting Description Range Default End of boot sequence The End of boot sequence URI is Blank triggered at the end of the phone boot sequence. Using the End of boot sequence URI, it is possible to develop self- provisioning on the phone.
Page 135 Off Hook Select the paging zone priority Blank from 1 to 10. Zones with a priority higher than another zone can interrupt the lower-priority zone’s active page. The Off Hook URI is triggered when the user goes to Dial mode by: ...
Page 136  The Timer Based URI will be Timer Based Blank triggered when the configured timeout expires. The timer starts at the end of the phone boot sequence. system_event.poll.action_uri  Enter the interval before the Timer Based Interval 3600 Timer Based URI is 65535 system_event.poll.interval triggered.
Page 137: Hotline Settings
Hotline Settings This feature is applicable to Temporis IP100, IP150, IP151, IP251G, IP300, IP301G, IP700G, IP701G. Hotline settings enable your desk set to dial a pre-configured number after any off-hook action in idle mode—lifting the handset, pressing SPEAKER, pressing HEADSET, or pressing a PFK Line key.
Page 138: Handset Settings
Handset settings This subsection of SYSTEM section is available for IP2015/IP2115 IP DECT only. It will allow you to configure which handsets are associated to which account(s), what will be the default dial out account for each handset, as well as the name a particular handset will display on its idle screen.
Page 139: Handset Name
Each line corresponds to one handset; you can identify each handset by its name and number. Handset number is shown at the top right corner on the idle screen. And each column corresponds to one account. In the example above, only Handset1 can use Account2 to send and receive calls. The rest of accounts can be used by all handsets.
Page 140 This configuration can be done as well using the handset Phone rename submenu. See User Settings on page 76. Handset name settings are also available as parameters in the configuration file See “hs_settings” Module: Handset management Settings on page 240 Setting Description Range...
Page 141: Network
All these settings are available through configuration files. See “network” Module: Network Settings on page 212. Basic Network Settings (IPv4) Applicable to Temporis IP100, IP150, IP300, IP700G, Alcatel IP2015 and Conference IP1850 Note: If you disable DHCP on this page, you must configure static IP settings for the phone.
Page 142: Basic Network Settings (Ipv4/Ipv6)
Secondary DNS Server network.ip.dns2 Basic Network Settings (IPv4/IPv6) Applicable to Temporis IP151, IP251G, IP301G, IP701G and Alcatel IP2115. IPv4 and IPv6 protocols are supported. When both IPv4 and IPv6 are enabled and available, the following guidelines apply when determining which stack to use: ...
Page 143 Note: You must be familiar with TCP/IP principles and protocols to configure static IP settings IPv4 Setting Description Range Default Disable/DHCP/Static IP/PPPoE You can toggle between disable, dhcp mode selection DHCP, Static IP, PPPoE or dhcp, disabling IPv4. static, pppoe DHCP is selected (enabled) by default, which means the desk set will get its IP...
Page 144 PPPoE username Enter your PPPoE account string blank username. network.ip.pppoe.username PPPoE password Enter your PPPoE account String blank password. network.ip.pppoe.access_password Manually configure DNS Select to enable manual 0:disable DNS configuration 1:enable network.ip.manually_configure_dns Primary DNS If DHCP is disabled, or IPv4 blank manual DNS configuration is network.ip.dns1...
Page 145 Note you need to populate additional parameters when Static IP is selected. IP Address If Static IP is enabled, enter IPv6 blank a static IP address for the deskset. Note you will have to enter network.ip6.static_ip_addr prefix, GW and DNS as well Prefix (0-128) Enter the IPv6 address 0-128...
Page 146: Advanced Network Settings
Advanced Network Settings PC Port You can set the availability of the desk set PC port for network connectivity. When the port is enabled for connectivity, you can set the port to port mirroring, thereby allowing you to use the port to monitor inbound and outbound network traffic and facilitate troubleshooting.
Page 147 Enable PC port Enable or disable the PC port 0:disable to operate in hub/switch 1:enable mode (depending on the Enable PC Port Mirroring setting). network.pc_port.enable Enable PC port mirroring When the PC port is enabled, 0:disable select Enable PC Port 1:enable network.pc_port.mirroring.enable Mirroring to set the port to...
Page 148 network.vlan.pc.id Enter the PC Port VLAN ID (vlan 5, for example). Not applicable to IP100, IP2015/IP2115 or IP1850 Priority Select the VLAN priority that 0–7 matches the Quality of Service (QoS) settings that you have set for that VLAN ID. Outbound packets will be marked and sent according to their priority.
Page 149 This feature is applicable to models Temporis IP151, IP251G, IP301G, IP701G, Alcatel IP2115. You can operate your phone over a Virtual Private Network (VPN). VPN enables remote users and remote sites to connect to a main corporate network and SIP server with a high level of performance and security.
Page 150: Contacts
Contacts Local Directory On the Local Directory page, you can manage your local directory entries. You can sort, edit, dial, delete, and add contact information. In some models, this page will be shown as “Shared Directory”, since contacts will be made available to registered handsets too. Maximum number of entries is model-dependent: up to 1000 for IP151, IP251G, IP301G, IP701G and IP2115, up to 200 entries for the rest of models, except6 for IP100 and IP150 which support up to 100.
Page 151 You can click on an entry to dial out this number. This feature can be enabled/disabled using configuration files, and is enabled by default. See next subchapter, or go to “provisioning” Module: Provisioning Settings on page 214. NOTE: You can also use the phone menu to manage local directory entries. For more information, see Quick User Guides.
Page 152: Directory Import/Export
2. Enter the required information as indicated in the following table. At minimum, a first and last name are required. Create New Entry Setting Description Range Default Call Block (not Blocks incoming calls with caller ID Enable, Disable on WUI) matching the directory entry.
Page 153: Directory Import Using Configuration Files
NOTE: When importing a .csv file, you can select whether the first line should be treated as a header and ignored for the import. Importing a directory file adds the imported directory entries to existing entries. Therefore, it is possible to have duplicate entries after importing a directory file. If you are importing a “complete”...
Page 154: Black List
Contact Import url (overwrite Sets the url from which the blank mode, not in WUI) phone will try to fetch the directory file during provisioning process. The URL must point to an xml file formatted as described above. Contacts in the xml file will overwrite file.contact.directory.overwrite existing entries.
Page 155: Black List Import/Export
Black List Import/Export The best way to create a black list file for import is to first export the directory from the phone as an .xml or .csv file (model dependent). After exporting the file, open it in an .xml or .csv editor and add or modify entries. You can import your modified directory file by clicking on “Import”...
Page 156: Ldap Directory
Contacts in the xml file will file.contact.blacklist.append be appended to existing entries. Contact Import url (overwrite Sets the url from which the blank mode, not in WUI) phone will try to fetch the black list file during provisioning process. The URL must point to an xml file formatted as described above.
Page 157 The LDAP settings are also available as parameters in the configuration file. See “remoteDir” Module: Remote Directory Settings on page 218. LDAP Settings Setting Description Range Default Enable LDAP Select to enable or disable LDAP 0: Disabled remote directory 1: Enabled remoteDir.ldap_enable Directory Name Enter the name to be displayed to...
Page 158 LDAP field names, separated by commas (no spaces). Your directory may include attributes like "cn" (common name) or "ou" (organizational unit) or "dc" (domain component). For example: ou=sales,dc=alcatel- business,dc=com remoteDir.ldap_base Maximum number of Enter maximum number of search 0-32000 entries results to be displayed.
Page 159 the last name attribute for entries remoteDir.ldap_lastname_attr on the LDAP server (sn for surname, ibute for example). This helps ensure that the phone displays LDAP entries in the same format as the Local Directory. Work phone number Sets the attribute for the work string blank attribute...
Page 160: Broadsoft Directory
beginning of the user-entered string. If gn=% is used for a firstname filter, entering “da” returns records such as Daisy, Dale, David, etc. The filter <attribute>=* returns records containing the user-entered string anywhere in that attribute. If gn=* is used for a firstname filter, entering “ar” returns records such as Karen, Arnold, Gary, etc.
Page 161: Remote Xml Phonebook
Remote XML Phonebook This feature is applicable to models Temporis IP151, IP251G, IP301G, IP701G and Alcatel 2115. In those models it will be offered as one more option on the left side bar for Contacts WUI pages. Up to three server-hosted Remote XML directories can be configured, with a total of 5000 entries supported.
Page 162 Sync failed will be displayed if any of the following failure conditions is encountered:  Server not reachable  Remote XML directory file is not available  Invalid XML directory file Remote XML Directory Settings Setting Description Range Default Name Sets the name of the directory as it string Blank...
Page 163 <?xml version="1.0" encoding="utf-8"?> <DIR_ENTRY> <DIR_ENTRY_NAME_FIRST>John</DIR_ENTRY_NAME_FIRST> <DIR_ENTRY_NAME_LAST>Smith</DIR_ENTRY_NAME_LAST> <DIR_ENTRY_NUMBER_OTHER>3333</DIR_ENTRY_NUMBER_OTHER> <DIR_ENTRY_NUMBER_WORK>1111</DIR_ENTRY_NUMBER_WORK> <DIR_ENTRY_NUMBER_MOBILE>2222</DIR_ENTRY_NUMBER_MOBILE> </DIR_ENTRY> Should your pbx or service provider require different tag naming for their supported XML Phonebook, use the table below to see how to configure them. Setting Description Range Default Entry tag Sets the name of the string DIR_ENTRY...
Page 164: Call History
Call History On Call History page you can review your call log details. Missed, received and dialled calls are shown in separate tables. You can also click-to-call entries in these lists. You can disable click-to-dial using configuration file parameter provisioning.click_to_dial . See “provisioning” Module: Provisioning Settings on page 214.
Page 165: Servicing
Reboot page allows you to perform a remote restart of your phone by clicking on the “Reboot” button. On all products (except IP2x15) restart can also be triggered via phone menu (Menu>>4.Admin settings>>5.Restart phone). On Temporis IP150, IP151, IP300, IP301G, IP700G and IP701G you may also use the shortcut “Long press key” Time and Date On the Time and Date menu, you can manually set the time and date, and the time and date formats.
Page 166 Time and Date Settings Setting Description Range Default Date Format Sets the date format. DD/MM/YY, DD/MM/YY MM/DD/YY, YY/MM/DD time_date.date_format Time Format Sets the clock format. 1: 24 Hour 0: 12 Hour time_date.24hr_clock Network Time Settings Setting Description Range Default Enable Network Time Enables or disables getting time 1: Enabled and date information for your...
Page 167 Use DHCP (Option 42) With Enable Network Time is 1: Enabled selected, tick this option to use 0: Disabled DHCP to locate the time server. Option 42 specifies the NTP server available to the phone. When enabled, the phone obtains the time in the following priority: 1.
Page 168: Custom Language
Daylight Savings Offset (minutes) Sets the daylight savings 0, 30, 60 offset (in minutes) if you are in a region that observes daylight savings time. Selecting a setting other than Off immediately sets the clock ahead by the time_date.daylight_saving_amount selected time. Use DHCP (Option 2/100/101) If Enable Network Time is 1: Enabled...
Page 169: Custom Logo
On this page, you can also reset the bootup and idle logos to factory defaults. The default logo for bootup and idle mode is the Alcatel logo. NOTE: All desktop and Conference phones support Custom logo via provisioning file as previously described in “Adding a Custom Logo...
Page 170: Firmware Upgrade
Setting Description Range Default Bootup logo Import a custom logo shown blank during bootup. For logo specifications, see “Adding a file.bootup_logo Custom Logo ” Idle screen logo Import a custom logo shown on blank the idle screen or screensaver. For logo specifications, see file.idle_logo “Adding a Custom Logo ”...
Page 171 Firmware URL The URL where the desk set or base string blank firmware update file resides. This should be a full path, including the filename of the firmware file. provisioning.firmware_url Server authentication name Authentication username for the string blank firmware server provisioning.fw_server_username Server authentication Authentication password for the...
Page 172 firmware will be stored in the deskset or base memory first, and then uploaded to the handset when requested. To update the deskset or base firmware using a file on your computer or local network: 1. On the Manual Firmware Update page, click Choose File to locate and open the firmware update file.
Page 173: Provisioning
Provisioning Provisioning refers to the process of acquiring and applying new settings for the device using configuration files retrieved from a remote computer. After a phone or system is deployed, subsequent provisioning can update it with new settings; for example, if your service provider releases new features.
Page 174 Provisioning Settings Setting Description Range Default Provisioning server URL of the provisioning file(s). The https:// format of the URL must be RFC 1738 ftp, tftp, art.atlinks compliant, as follows: http, “<schema>://<user>:<password>@ .com https <host>:<port>/<url-path>” “<user>:<password>@” may be empty. “<port>” can be omitted if you do provisioning.server_address not need to specify the port number.
Page 175 DHCP Server. see below network.user_class Product name DHCP Option 60/77 default value Temporis IP100 Alcatel Temporis IP100 Temporis IP150 Alcatel Temporis IP150 Temporis IP151 Alcatel Temporis IP151 Temporis IP251 Alcatel Temporis IP251G Temporis IP300 Alcatel Temporis IP300 Temporis IP301G Alcatel Temporis IP301G Business IP Range Administration and Provisioning Guide ed 2.2...
Page 176 Temporis IP700G Alcatel Temporis IP700G Temporis IP701G Alcatel Temporis IP701G Alcatel IP2015 Alcatel IP2015 Alcatel IP2115 Alcatel IP2115 Conference IP1850 Alcatel IP1850 Resynchronization Setting Description Range Default Mode Sets which files the phone config_only: config_and_firmware checks for at regular Configuration intervals.
Page 177 Bootup Check Sets the phone to check 1: On the provisioning URL for 0: Off new configuration and/or firmware files upon boot up. The update is applied as part of the reboot process. provisioning.bootup_check_enable Schedule check mode Toggles among the 3 disable, disable Disabled/Interval/ days of the...
Page 178 Passphrase If the configuration file String Blank has been secured using AES encryption, enter the 16-bit key. See Securing Configuration Files with provisioning.crypto_passphrase AES Encryption. Remote Check Sync If enabled, the phone 0: Disabled will react to a NOTIFY (Not in WUI) 1: Enabled (check-sync) in order to launch automatic...
Page 179 You can export all the settings you have configured on the WebUI and save them as a configuration file on your computer. You can then use this configuration file as a backup, or use it to update other phones. To export the configuration file: 1.
Page 180: Security
Security On the Security page you can reset the admin password, reset the user password, enter web server settings, and configure other security features like phone lock of IP filtering. After changing any settings on this page, press Save to save them. Passwords Administrator Password Setting...
Page 181: Phone Lock
User Password Setting Description Range Default User password: Enter old Enter user password. String user password The password is case User password: Enter new sensitive and can consist of password both numbers and letters. User password: Re-enter new password profile.user.password To change the User password: 1.
Page 182: Pin Masking
(0 stands for the phone.lock.restricted_account Select the account to be default account) used when Phone Lock is active. PIN masking This feature is applicable to Temporis IP151, IP251G, IP301G and IP701G. The PIN masking feature allows users to hide PIN numbers during call operation. The different types of PIN masking are: ...
Page 183: Web Server
Enable Delay for Hidden Enable to add a one-second 0:disable delay before DTMF digits are DTMF digits 1:enable masked. By default, the digits are masked immediately. security.hide_dtmf_delay_enable Enable Password Dial Enable to hide PIN numbers 0:disable entered as part of the dial string. 1:enable security.pwd_dial_enable Enable Delay for Password Dial...
Page 184: Trusted Servers
1. Enter the HTTP Server port number. The default setting is 80. 2. Enable or Disable Secure Browsing. When enabled, the HTTPS protocol is used, and you must select the HTTPS server port in the next step. 3. Enter the HTTPS server port number. The default setting is 443. Trusted servers This feature is applicable to Temporis IP151, IP251G, IP301G and IP701G.
Page 185: Trusted Ip
Trusted IP This feature is applicable to Temporis IP151, IP251G, IP301G and IP701G. In addition to the Trusted Servers setting, incoming IP traffic can be filtered using an "Allowed IP" list of IP addresses. When this means is enabled, all unsolicited IP traffic will be blocked unless it is from one of the trusted IP addresses on the "Allowed IP"...
Page 186: Certificates
Certificates This section applies to models Temporis IP100, IP150, IP300, IP700G, Alcatel IP2015 and Conference IP1850. TLS (Transport Layer Security) transport requires security certificates to establish a secure connection between phone and server. Your phone embeds a web server certificate for this purpose. You can also upload one using WUI and/or configuration files.
Page 187: Enhanced Certificate Management
Enhanced Certificate Management This section applies to models Temporis IP151, IP251G, IP301G, IP701G and Alcatel IP2115. For these devices, you can add two types of certificates using the WebUI or the provisioning file:  Device—A single Device Certificate can be uploaded so that other parties can...
Page 188 The WUI will indicate whether the certificate in use is the Factory default or your custom one. You can always return to the default Factory certificate. To upload a device certificate: 1. On the Device Certificate page, click Choose File 2.
Page 189: Tr069
TR069 This section applies to models Temporis IP151, IP251G, IP301G, IP701G and Alcatel IP2115. The Broadband Forum’s Technical Report 069 (TR-069) defines a protocol for remote management and secure auto-configuration of compatible devices. On the TR069 page, you can enable TR-069 and configure access to an auto-configuration server (ACS).
Page 190 Periodic Inform Interval Periodic inform method calls 1-65535 3600 (seconds) interval. tr069.periodic_inform.interval Connection Request Username If the ACS wants to string blank communicate with the device, it must offer the matching Connection Request user name. When the device sends the report to ACS for the first time, tr069.connection_request.usernam it contains information for this.
Page 191: System Logs
System Logs On the System Logs page, you can enter settings related to system logging activities. You can also generate and download network traces. Syslog Settings Setting Description Range Default Enable Syslog Enable log output to syslog server. 1: Enabled 0: Disabled log.syslog_enable Server Address...
Page 192 DEBUG: Developer messages for troubleshooting/debugging purposes. Network Capture To generate a pcap trace press “Start Capture” To stop tracing, press “Stop Capture” To download your capture press “Save to file” Download Log To download a copy of the system logs press “Save log to file” Business IP Range Administration and Provisioning Guide ed 2.2 192/247...
Page 193: Provisioning Using Configuration Files
Provisioning Using Configuration Files Provisioning using configuration files is the quickest way to configure multiple phones. You can place configuration files on a provisioning server, where the phones can retrieve them and update their configuration automatically. Configuration files have the extension .cfg and contain parameters that define various phone settings.
Page 194: Phone Restart
Product name <model> Temporis IP100 Temporis_IP100 Temporis IP150 Temporis_IP150 Temporis IP300 Temporis_IP300 Temporis IP700G Temporis_IP700G Alcatel IP2015 IP2015 Conference IP1850 IP1850 Thus, for example for Temporis IP300 the files would be Temporis_IP300.cfg and Temporis_IP300_<MACAddress>.cfg Note: if the url the phone obtains for provisioning file location is a full path including file name, then only this one file download will be attempted.
Page 195: Configuration File Types
work hours so that the phones will download the file(s) when there is little or no call activity. When you update the phone by importing a configuration file using the WebUI, the phone restarts immediately after applying any new settings that require a restart, regardless of whether the phone is idle.
Page 196 The audio settings include jitter buffer parameters and RTP port settings. These configuration items affect only models in Group C, and each account is configured independently Setting Description Applic. Range Default audio.x.jitter_mode Select the desired Group C fixed, adaptive mode for the jitter adaptive buffer: fixed (static) or...
Page 197: Configuration File Guide
audio.x.rtcp_xr.enable Enables or disables Group C 0:disabled reporting of RTCP 1:enabled XR via SIP to a collector server. RTP Control Protocol Extended Reports (RTCP XR) are used for voice quality assessment and diagnostics. “file” Module: Imported File Settings on page 230. Configuration File Guide All configuration settings are initially stored in a configuration template file.
Page 198 To encrypt a configuration file: You can use for example an open source tool such as Openssl, which can be downloaded from the Openssl project site. If this is the case, proceed as follows. 1. (Optional) Place your configuration file in the same folder as the openssl.exe file. If the configuration file is not in the same folder as the openssl.exe file, you can enter a relative pathname for the [infile] in the next step.
Page 199 3. Enter the 16-character passphrase that you created when you encrypted the configuration file. 4. Click Save. Note: You must ensure that configuration files are encrypted when enabling AES Encryption. Decrypting an unencrypted file will result in a garbage file that is not processed.
Page 200: Setting Up Provisioning
Setting Up Provisioning Set up your provisioning server and folders for provisioning files. The general and unit configuration files should be in the same folder. Note the IP address, username and password for access to the folder on the provisioning server. The Provisioning Server Settings will enable the phone to find the general configuration file.
Page 201: Soft Keys
Soft Keys Desktop phone soft keys The table below provides an alphabetical list of the labels that appear above the desktop phones soft keys. Label Description abc/ABC/123 Selects the format for text input αβγ/ABΓ абг/АБГ Displays the new directory group editor AddCall Add a call to a network conference Add dot...
Page 202 Delete 1) Deletes current entry 2) Deletes assignment 3) Deletes Directory group Dial Sends and dials currently displayed/highlighted digits Changes the speed dial directory source Directory Opens the list of available directories DirPickup Launches a directed pickup on the default account Displays DND menu Done Confirm...
Page 203 Priv Hold For Broadsoft environments, put a call on a shared line in private hold mode Redial Access the dialed calls list Reject Rejects an incoming call Resume Resumes a call put on hold Save 1) Saves current setting 2) Begins save process Search Opens the Directory search editor Select...
Page 204: Ip15 Cordless Handset Soft Keys
IP15 cordless handset soft keys The table below provides an alphabetical list of the labels that appear above IP15 cordless handset soft keys. Label Description Add an entry Answers an incoming call ANSWER Shows the previous screen BACK Backspace in text editing fields BACKSP Selects IP2015 as the target for a handset registration (vs DESKSET) BASE...
Page 205 Turns ringer vol. bar empty Returns to previous screen Enters into the action list of a directory folder OPTION Rejects an incoming call REJECT Resumes a SIP session put on hold RESUME Enters into a database/list REVIEW Save a setting or a directory entry SAVE Begins Dir searching SEARCH...
Page 206: Appendix A: Configuration File Settings
Parameters may not be applicable to all models. Use “Applicability” column to check if a parameter is valid for your phone. All: applicable to all models Group B: Temporis IP100, IP150, IP300, IP700G; Alcatel IP2015; Conference IP1850 Group C: Temporis IP151, IP251G, IP301G, IP701G; Alcatel IP2115 Group D: Temporis IP151, IP251G, IP301G, IP701G Business IP Range Administration and Provisioning Guide ed 2.2...
Page 207: Sip_Account" Module: Sip Account Settings
“sip_account” Module: SIP Account Settings The SIP Account settings enable you to set up individual accounts for each user. You can add up to three accounts for each phone. Each account requires you to configure the same settings. The SIP account settings for each account would be identified by their own account number, from 1 to 2.
Page 208 (model dep) sip_account.x.shared_line_enable 0, 1 sip_account.x.barge_in_enable 0, 1 sip_account.x.auto_answer_enable 0, 1 sip_account.x.auto_answer_during_active_call 0, 1 sip_account.x.cid_src_priority.1 Group C pai, rpid, from sip_account.x.cid_src_priority.2 Group C pai, rpid, rpid from sip_account.x.cid_src_priority.3 Group C pai, rpid, from from sip_account.x.feature_sync_enable 0, 1 sip_account.x.server_side_ctrl_variant Group C default, default comverse...
Page 209 sip_account.x.access_code_page Text Blank string sip_account.x.access_code_park_call Text Blank string sip_account.x.access_code_retrieve_parked_ca Text Blank string sip_account.x.access_code_retrieve_voicemail Text Blank string sip_account.x.access_code_dnd_on Text Blank string sip_account.x.access_code_dnd_off Text Blank string sip_account.x.access_code_cfa_on Text Blank string sip_account.x.access_code_cfa_off Text Blank string sip_account.x.access_code_cfna_on Text Blank string sip_account.x.access_code_cfna_off Text Blank string sip_account.x.access_code_cfb_on Text Blank...
Page 210 sip_account.x.access_code_hg_off Group D Text Blank string sip_account.x.access_code_sf_on Group D Text Blank string sip_account.x.access_code_sf_off Group D Text Blank string sip_account.x.blf_list_uri Sip uri Blank sip_account.x.blf_remote_pickup_code Text Blank string sip_account.x.blf_subscription_expires 15- - 65535 3600 sip_account.x.nat_traversal_stun_enable 0, 1 sip_account.x.nat_traversal_stun_server_port 0-65535 3478 sip_account.x.nat_traversal_stun_server_addr Ipv4 or Blank fqdn sip_account.x.nat_traversal_stun_keep_alive_...
Page 211 y = 1 to 7 for Group C ilbc (Group C) sip_account.x.blf_variant default, default avaya, extended_b metaswitch freeswitch sip_account.x.unregister_after_reboot_enable Unregister 0, 1 after reboot enable sip_account.x.transport_mode Signalling ‘‘udp’’, ‘‘udp’’ Transport ‘‘tcp’’, Mode ‘‘tls’’ sip_account.x.backup_outbound_proxy_server_p 0-65535 5060 sip_account.x.backup_outbound_proxy_server_a IPv4 or Blank ddress fqdn sip_account.x.registration_retry_time...
Page 212: Network" Module: Network Settings
“network” Module: Network Settings The network settings follow the format: network.[element]. These settings can be exported when you manually export the configuration from the phone, except for the settings shaded in gray in the table. Setting Description Applicab. Range Default network.ip.dhcp_enable Indicates whether Group B...
Page 213: Profile" Module: Security Settings
network.nat.public_ip_addr Public IP address Group B Ipv4 blank network.nat.public_sip_port Public SIP port Group B 0-65535 5060 network.nat.public_rtp_port_start Public RTP port Group B 0-65535 18000 start network.nat.public_rtp_port_end Public RTP port end Group B 0-65535 19000 network.vlan.wan.enable Enable vlan on WAN 0, 1 port network.vlan.wan.id WAN port VID...
Page 214: Provisioning" Module: Provisioning Settings
These settings are not exported when you manually export the configuration from the phone; only their namespaces are. Setting Description Range Default profile.admin.access_password Password for admin string admin profile.user.access_password Password for user string user “provisioning” Module: Provisioning Settings The provisioning settings follow the format: provisioning.[element]. All these settings are exported when you manually export the configuration from the phone.
Page 215 config_and_ firmware provisioning.resync_time Minutes between 0- - 65535 checks for new firmware and/or configuration file provisioning.schedule_mode disable, disable interval, weekday provisioning.weekdays Days for which List of blank provisioning comma should take delimited place. integers, 0 to 6 provisioning.weekdays_start_hr 0-23 provisioning.weekdays_end_hr 0-23 provisioning.server_address Server address...
Page 216: Time_Date" Module: Time And Date Settings
“time_date” Module: Time and Date Settings The time and date settings follow the format: time_date.[element]. All these settings are exported when you manually export the configuration from the phone. Setting Description Applicab. Range Default time_date.date_format Format for DD/MM/YY, DD/MM/YY displaying MM/DD/YY, the date YY/MM/DD...
Page 217: Log" Module: Log Settings
time_date.daylight_saving_start_hour 00:00 - 02:00 23:00 time_date.daylight_saving_end_month "January" November "February ", "March", "April", "May", "June", "July", "August", "Septembe r", "October" "November ", "December " time_date.daylight_saving_end_week time_date.daylight_saving_end_day "Sunday", Sunday "Monday", "Tuesday" "Wednesda y", "Thursday ", "Friday", "Saturday " time_date.daylight_saving_end_hour 00:00 - 02:00 23:00 time_date.daylight_saving_amount DST offset in...
Page 218: Remotedir" Module: Remote Directory Settings
1-error 0-critical log.syslog_server_address Syslog server IP IPv4 blank address log.syslog_server_port Syslog server port 0-65535 “remoteDir” Module: Remote Directory Settings The remote directory settings follow the format: remoteDir.element. All these settings are exported when you manually export the configuration from the phone.
Page 219: Web" Module: Web Settings
remoteDir.ldap_work_number_attributes LDAP work String Blank number attributes remoteDir.ldap_mobile_number_attribut LDAP mobile String Blank number attributes remoteDir.ldap_other_number_attribute LDAP home String Blank number attributes remoteDir.ldap_protocol_version LDAP protocol version_2, version_ version version_3 remoteDir.ldap_search_delay LDAP search 0-500 delay remoteDir.ldap_incall_lookup_enable LDAP incoming call lookup remoteDir.ldap_outcall_lookup_enable LDAP outgoing call lookup remoteDir.ldap_check_certificate Require...
Page 220: Trusted_Ip" Module: Trusted Server And Trusted Ip Settings
These settings can be exported when you manually export the configuration from the phone, except for the settings shaded in gray in the table. Setting Description Applicab Range Default web.http_port Sets the http port for the 0-65535 embedded web server web.https_port Sets the https port when 0-65535...
Page 221: User_Pref" Module: User Preference Settings
on page 185 for more information. “user_pref” Module: User Preference Settings The user settings are accessible to the phone user. These settings are useful for initial setup. You may wish to remove these settings from auto-provisioning update files so that users do not have their own settings overwritten.
Page 222 without additional dialing digits user_pref.text_input_option Specify the order & number, number, available language uc_western, uc_western, input option in lc_western, lc_western user edit mode uc_ru, lc_ru, uc_el, lc_el user_pref.account.x.ringer Ringer tone for 1-10 account x, where x is model dependent user_pref.account.x.diversion_display Enables or disables Group C 0, 1...
Page 223: Call_Settings" Module: Call Settings
when remote party terminates a call user_pref.notify.led.missed_call.enab Sets how the 0, 1 Message Waiting LED operates. When enabled, the LED turns on for missed calls and new messages. When disabled, the LED turns on for new messages only. Note: This setting is not available on the phone menu or WebUI.
Page 224 call_settings.account.x.cfna_del Delay (in # of rings) before call 1-10 is forwarded call_settings.missed_call_alert_ Enable/disable missed call alert 0, 1 enable call_settings.hotline_enable Enables or disables the hotline 0, 1 feature. call_settings.hotline_account Sets the account used for dialing 0 to max 0 (def the hotline number.
Page 225: Pfk" Module: Programmable Feature Key Settings
“pfk” Module: Programmable Feature Key Settings The programmable feature key (PFK) settings store the data associated with each programmable feature key. The programmable feature key settings follow the format: pfk.x.[element], where x is the programmable feature key ID, ranging from 1 to 32. Setting Description Applic.
Page 226 no answer, quick dial, busy lamp field, acd, page, multicast page, park call, retrieve parked call, in call dtmf, callback, group call pickup, direct call pickup, prefix_dial , chp, hg, lock_key, flash, xml Note: Temporis IP151 pfks 6 to 10 and 16 to 20 have no LEDs, hence...
Page 227 pfk.x.account SIP account used for 1-max the assigned feature accounts (if applicable) (model dependent) pfk.[hardkey].account Group C pfk.x.quick_dial Quick dial string to string Blank use if quick dial is assigned to PFK pfk.[hardkey].quickdial Group D pfk.x.blf BLF string to use if string Blank Busy Lamp Field is...
Page 228: Speed_Dial" Module: Speed Dial Settings
[*71] + [user-entered digits] + [#] as the outgoing dialing string. pfk.[hardkey].prefix Same as above Group D String blank pfk.x.multicast_zone Sets the multicast 1-10 Bank paging zone if multicast page is assigned to PFK x. pfk.[hardkey].multicast_zone Same as above Group D 1-10 blank pfk.x.call_handling_profile...
Page 229: Audio" Module: Audio Settings
Setting Description Applic. Range Default speed_dial.x.number Phone number that the memory String blank key will dial when pressed and held. speed_dial.x.name Name associated to this memory String blank key. speed_dial.x.account SIP account (line) used for dialing when memory key x is pressed and held.
Page 230: File" Module: Imported File Settings
audio.x.adaptive_jitter.max_delay When in adaptive Group C 180-500 jitter buffer mode, set the maximum delay (in ms) desirable to maintain data packet capture and audio quality. audio.x.rtp.port_start Sets the Local RTP Group C 1-65535 18000 port range start. audio.x.rtp.port_end Sets the Local RTP Group C 1-65535 19000...
Page 231 file.contact.blacklist.overwrite URL of xml contact blacklist to be imported and will overwrite existing black list. file.bootup_logo URL of custom logo shown during bootup. For logo specifications, see Logo specifications on page 43 file.idle_logo URL of custom logo shown on the idle screen.
Page 232: Xml_App" Module: Xml App Settings
removecertificate_allnonprotected: remove all non-protected trusted certificates removecertificate_all: remove the custom device certificate and all protected or non-protected trusted certificates Enables you to delete a custom language from the WebUI, the deskset screens, or both. Values: removecertificate_ customdevice, removecertificate_ allnonprotected, removecertificate_all removecustomlanguage_all, removecustomlanguage_webui, removecustomlanguage_desksetui...
Page 233: System_Event" Module: Action Uri Settings
xml_app.push_during_call_enable Enable or disable the Group D 0:disabled phone to display 1:enabled pushed XML objects during a call. Otherwise, the XML application is displayed after the call is over. For more information about the XML Browser interface please check with your customer support.
Page 234: Tr069" Module: Tr-069 Settings
For more information about the XML Browser interface please check with your technical support. “tr069” Module: TR-069 Settings Phones in model Group C (Temporis IP151, IP251G, IP301G, IP701G and Alcatel IP2115) support TR-069. The Broadband Forum’s Technical Report 069 (TR-069) defines a protocol for remote management and secure auto-configuration of compatible devices.
Page 235: Tone" Module: Tone Definition Settings
sending Inform messages. “tone” Module: Tone Definition Settings The Tone Definition settings configure data for various tones for the purpose of localization. The Audio Manager component uses the data from this model to populate the mcu on bootup. The tone definition settings follow the format: tone.element.x, where x is the index of the elements, ranging from 1 to 5.
Page 236 tone.hold_reminder.num_of_repeat_all Group C tone.inside_dial_tone.num_of_elements tone.inside_dial_tone.element.1 Group B 2 440 -180 350 -180 0 0 0 0 4294967295 0 65535 tone.inside_dial_tone.element.1 Group C 2 440 -22 350 -22 0 0 0 0 65535 0 65535 tone.inside_dial_tone.element.[2-5] blank tone.inside_dial_tone.num_of_repeat_all Group C tone.stutter_dial_tone.num_of_elements tone.stutter_dial_tone.element.1 2 440 -180 350 -180 0 0 0 0 Group B...
Page 237: Ringersetting" Module: Distinctive Ringing Settings
tone.congestion_tone.element.2 Group C 1 1400 -22 0 0 0 0 0 0 330 0 tone.congestion_tone.element.3 Group C 1 1800 -22 0 0 0 0 0 0 330 1000 tone.congestion_tone.element.[4-5] blank Group C tone.congestion_tone.num_of_repeat_all Group C 65535 tone.ring_back_tone.element.[2-5] blank tone.dial_tone.num_of_elements Group C tone.dial_tone.element.1 Group C 2 440 -22 350 -22 0 0 0 0...
Page 238: Page_Zone" Module: Paging Zone Settings
“page_zone” Module: Paging Zone Settings The paging zone settings allow you to define a maximum of 10 paging zones that the deskset can use for multicast paging. The paging zone parameters (except for page_zone.call_priority_threshold) follow the format page_zone.x.[element], where x is the paging zone ID number, ranging from 1 to Setting Description Applic.
Page 239: Softkey" Module: Custom Soft Key Settings
“softkey” Module: Custom Soft Key Settings The custom soft key settings allow you to select which soft keys can appear on the Idle screen, the Call Active screen, the Call Held screen and the Live Dial screen. You can also specify the position of each soft key.
Page 240: Hs_Settings" Module: Handset Management Settings
end, resume, transfer, conf,,hs_pick softkey.live_dial Specifies the Group B: Model soft keys dependent. (see blank, dir, call_log, visible on redial, message, end, remarks) the live dial dial, input, cancel, screen. backspc, pgm_dial_1, pgm_dial_2, pgm_dial_3 Group C: blank, dir, call_log, redial, message, end, dial, input, cancel, backspc softkey.
Page 241 Business IP Range Administration and Provisioning Guide ed 2.2 241/247...
Page 242: Appendix B: Time Zones
Appendix B: Time Zones Time Zone String in config file Pacific/Pago_Pago Samoa Pacific/Honolulu United States-Hawaii-Aleutian America/Adak United States-Alaska-Aleutian America/Anchorage United States-Alaska Time America/Vancouver Canada(Vancouver,Whitehorse) America/Tijuana Mexico(Tijuana,Mexicali) America/Los_Angeles United States-Pacific Time America/Edmonton Canada(Edmonton,Calgary) America/Chihuahua Mexico(Mazatlan,Chihuahua) America/Denver United States-Mountain Time America/Phoenix United States-MST no DST America/Winnipeg Canada-Manitoba(Winnipeg) Pacific/Easter...
Page 243 Europe/Brussels Belgium(Brussels) Europe/Zagreb Croatia(Zagreb) Europe/Prague Czech Republic(Prague) Europe/Copenhagen Denmark(Kopenhaven) Europe/Paris France(Nice) Europe/Berlin Germany(Berlin) Europe/Budapest Hungary(Budapest) Europe/Rome Italy(Rome) Europe/Luxembourg Luxembourg(Luxembourg) Europe/Skopje Makedonia(Skopje) Europe/Amsterdam Netherlands(Amsterdam) Africa/Windhoek Namibia(Windhoek) Europe/Tallinn Estonia(Tallinn) Europe/Helsinki Finland(Helsinki) Asia/Gaza Gaza Strip(Gaza) Europe/Athens Greece(Athens) Asia/Jerusalem Israel(Tel Aviv) Asia/Amman Jordan(Amman) Europe/Riga Latvia(Riga) Asia/Beirut Lebanon(Beirut)
Page 244 Australia/Adelaide +9:30 Australia(Adelaide) Australia/Darwin +9:30 Australia(Darwin) Australia(Sydney,Melbourne,Canberra) Australia/Sydney Australia/Brisbane Australia(Brisbane) Australia/Hobart Australia(Hobart) Asia/Vladivostok Russia(Vladivostok) Australia/Lord_Howe +10:30 Australia(Lord Howe Islands) Pacific/Noumea New Caledonia(Noumea) Pacific/Auckland New Zeland(Wellington,Auckland) Pacific/Chatham +12:45 New Zeland(Chatham Islands) Pacific/Tongatapu Tonga(Nukualofa) Business IP Range Administration and Provisioning Guide ed 2.2 244/247...
Page 245: Maintenance
Maintenance Taking care of your telephone Your telephone contains sophisticated electronic parts, so you must treat it with care. Avoid rough treatment. Place the corded handset down gently. Save the original packing materials to protect your telephone base if you ever need to ship it.
Page 246: Important Safety Information
Important Safety Information This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. Read and understand all instructions in the user’s manual.
Page 247: Ce Declaration Of Conformity
CE Declaration of conformity Hereby, it’s declared that this phone is in conformity with the essential requirements and other relevant provisions of the CE. You can download full declaration from www.alcatel-business.com CE Mark Warnings Temporis IP100/IP150/IP151/IP251G This is a Class B device, in a domestic environment; this product may cause radio interference, in which case the user may be required to take adequate measures.

This manual is also suitable for:

Temporis ip100 Temporis ip251g Temporis ip301g Temporis ip700g Temporis ip701g Alcatel ip2015 ... Show all

Alcatel Temporis IP150 Administration And Provisioning Manual

Quick Links

Related Manuals for Alcatel Temporis IP150

Summary of Contents for Alcatel Temporis IP150

This manual is also suitable for:

Table of Contents
