4. Commissioning positioning systems
Cylinder length/
Cylinder swivel angle
Cylinder diameter
Measuring system
design
Measuring system length/
Measuring system swivel
angle
Measuring system
parameter
Valve type
4−24
The length or swivel range of the drive (see type plate).
Permitted: 50 ... 10000 [mm] or [°]
The diameter of the drive used (see type plate).
Design of the measuring system. Select here the type of
measurement system used from the list:
potentiometer
temposonics (digital measuring system)
encoder
(the measuring system length is defined fixed with the
selection Encoder")
The length or swivel range of the measuring system used
(see type plate).
Permitted: 50 ... 10000 [mm] or [°]
This parameter is only displayed in the Encoder" setting of
the Measuring system design" field. The setting is reserved
for later developments.
Identification of the valve. Here select the type of valve used
from the list:
MPYE−5−M5−010B
MPYE−5−1/8−LF−010B
MPYE−5−1/8−HF−010B
MPYE−5−1/4−010B
MPYE−5−3/8−010B
