Machine description – quick overview

Taurus Synergic drive 200C

4 Machine description – quick overview
4.1 Taurus Synergic drive 200C
4.1.1

Front view

Item Symbol Description
1
2
3
4
5
6
7
8
9
10
11
14
1
2
3
4
0
Carrying handle
Cover for wire delivery unit and operating elements
Wire spool inspection window
Check wire supply
Wire feed unit cover lock
Central connection for welding torch (Euro)
Integrated welding current, shielding gas and torch trigger
19-pole connection socket (analogue)
For connecting analogue remote controls
Gas flow regulator for the fine adjustment of the gas flow
Rapid-action closure coupling (red)
coolant return
Rapid-action closure coupling (blue)
coolant supply
Stirrup (optional)
Fitting an additional torch tube package strain relief
Machine control
See Machine control – operating elements chapter
5 6 7
Figure 4-1
11
10
9
8
