Taurus Synergic Drive 300C; Front View - EWM Taurus Synergic drive 200C Operating Instructions Manual

4.2

Taurus Synergic drive 300C

4.2.1

Front view

Item Symbol Description
1
2
3
4
5
6
7
8
9
10
11
12
099-005211-EW501
23.08.2010
Machine description – quick overview
2
3
4
0
Carrying handle
Cover for wire delivery unit and operating elements
Wire spool inspection window
Check wire supply
Wire feed unit cover lock
Machine control
See Machine control – operating elements chapter
19-pole connection socket (analogue)
For connecting analogue remote controls
Changeover switch, remote control on/off
ON Set the welding performance via the remote control
OFF Set the welding performance via the machine control
Gas flow regulator for the fine adjustment of the gas flow
Rapid-action closure coupling (blue)
coolant supply
Rapid-action closure coupling (red)
coolant return
Central connection for welding torch (Euro)
Integrated welding current, shielding gas and torch trigger
Machine feet
1
6
11
10
12
Figure 4-4
Taurus Synergic drive 300C
5
7
8
9
17
