Machine description – quick overview
Taurus Synergic drive 300C
4.2.2
Rear view
Item
Symbol Description
1
2
3
4
5
6
7
8
9
10
18
1
2
4
5
6
8
0
Carrying handle
Connecting nipple G¼, shielding gas connection
Stirrup
Intermediate tube package strain relief
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, etc.)
Connector plug, welding current "+"
Welding current connection on wire feed unit
Rapid-action closure coupling, red (coolant return)
Rapid-action closure coupling, blue (coolant supply)
Conveyor rolls
Wire spool inspection window
Check wire supply
Wire feed unit cover lock
3
7
Figure 4-5
9
10
099-005211-EW501
