• If the vertical lines are misaligned, when the "ALIGNMENT:
ON", message is displayed, press the
chine will carry out the print head aligning procedure, at the
end of which:
- the following 10 alignment samples (each consisting of a
series of vertical lines) will be printed on an automatically
inserted sheet and the display will show the "XX" message
where "XX" is a value between 00 and 19.
At this point, if this value does not correspond to the correct
alignment sample, set a value (which may be between those
shown on the printout) that represents the best alignment solu-
tion using the |/} keys, then press the
The fax machine prints a row of aligned vertical lines, to con-
firm the choice made, and then returns automatically to the
initial stand-by mode.
AUTOMATIC RX
25-07-01
T
O SET THE DATE AND TIME
If the date and time shown on the display are not correct,
you can change them at any time.
Until the display shows:
FAX SET-UP
The display shows:
DATE AND TIME
The display shows:
FORMAT: DD/MM/YY
If you want to select a different format from the one dis-
played, press the |/} keys.
The display shows:
FORMAT: 24 H
If you want to select the other time format (12-hour), press
the |/} keys.
The display shows:
DD/MM/YY
25-07-01
Enter the new date and time (e.g. 26-07-01; 12:00). As
each digit is entered, the cursor will move to the next one.
DD/MM/YY
26-07-01
If you only want to change a few digits, move the cursor to
them using the |/} keys and overwrite them with the correct
digits.
To confirm the setting. The date and time setting procedure
has been completed. The new date and time will be up-
dated automatically and will be printed on each page sent.
To return the fax machine to the initial stand-by mode.
6
key. The fax ma-
key.
11:23
HH:MM
11:23
HH:MM
12:00
n o t e
If you have chosen the 12-hour time format, the display will
show the letter "p" (post meridiem) or the letter "a" (ante
meridiem). To switch from one letter to another, move the
cursor to the letter to be changed, using the |/} keys, and
press the key.
If you think you have made a mistake or want to abort the
procedure in progress for any reason, press the
If no data is entered for about two minutes in any phase
of operation, the fax machine returns automatically to
its initial stand-by mode.
n o t e
Remember that the stand-by mode is the status in which it is
idle and that it is the mode from which the machine can be
programmed.
A '
LL THAT S MISSING NOW IS YOUR NAME

AND FAX NUMBER

Once set, the name (max. 16 characters) and number
(max. 20 digits) will remain unchanged until they are in-
tentionally changed and will be printed on each page re-
ceived by your correspondent's fax machine.
Until the display shows:
INSTALLATION
The display shows:
TEL. LINE SET-UP
Until the display shows:
STATION NAME
The display shows:
TYPE YOUR NAME
To select the characters of each key cyclically.
To leave a space, press |/}.
To include a variety of special symbols, e.g. &, in your
name.
If there are any incorrect characters: position the cursor on
the incorrect character using the |/} keys and overwrite it
with the correct character.
To delete the name completely.
For example, to enter the name "LARA":
Until you have selected the letter "L".
Until you have selected the letter "A".
Until you have selected the letter "R".
Until you have selected the letter "A".
To confirm the name. The display shows:
PHONE NUMBER
key.
