►Channel Demodulation
Parameter
Audio Carrier signal level, A/V
C/N
HUM (over audio carrier)
CTB/CSO
Sound
►Configuration Menu
Parameter
Channel Plan
Standard TV Channel plans
Customized Channel plan
Units
Reference Line
Units
Reference Line
Thresholds
5.3 Tilt
►Downstream
Parameter
Frequency:
Bandwidth resolution
Frequency Tuning resolution
Dynamic range
Screen range
Max Input level
Resolution
Measurements
Resolution
►Upstream
Parameter
Frequency:
Chapter 5: SPECIFICATIONS
Value
0- 30 dB (for PAL, SECAM or NTSC
standard)
48 dB for input level > 10 dBmV
1-15%, 1% accuracy
60 dB dynamic range. (In channel
with removed carrier or out of channel
selecting a not used channel)
broadcast FM demodulation from
internal speaker
Value
Yes
CCIR,EIA,HRC,IRC,OIRL,FCC up to 10
Up to 30
dBmV, dBuV, dBm
from –60 dBmV to 120 dBmV
dBmV, dBuV, dBm
from –60 dBmV to 120 dBmV
Max and Min limits for quality evalua-
tion
Value
Four selectable tuning frequencies
(pilots) from 45 MHz to 1700 MHz
230 kHz
10 kHz
-50 dBmV to 60 dBmV
50 dB
70 dBmV
0.1 dB
Level of four selected frequencies
0.1 dB
Value
Four selectable tuning frequencies
(pilots) from 45 MHz to 1700 MHz
43
Additional Data
± 3 dB accuracy
Additional Data
Additional Data
±0 to 30 dB/ MHz (Tilt) between two
selected pilots
Additional Data
