2 Frequency for the channel selected.
3 DOCSIS Bonding Group selected and carrier (if any).
4 According to signal type:
•Digital signal: Power for channel bandwidth or frequency.
•Analogue signal: Level for channel or frequency selected.
5 Carrier/Noise ratio of the channel.
6 Full band RF cable power.
7 Marker for selected channel / frequency.
8 Arrows to change reference level.
9 Span lower frequency.
10 Arrows to increase / decrease span. Current span.
11 Bandwidth resolution.
12 Span upper frequency.
Options Menu
►
There are some options at the bottom of the screen:
: Screenshot.
DATALOGGER: It creates a datalogger with measurement data.
: Back to home screen.
TILT: Access the TILT function.
DEMOD: Demodulator (refer to "Demodulator" chapter).
