Promax RANGER mini User Manual page 22

2 Level for the selected frequency.
3
Full band RF cable power.
4 Marker in the selected frequency.
5 Arrows to change reference level.
6 Span lower frequency.
7 Arrows to increase / decrease span. Current span.
8 Bandwidth resolution.
9 Span upper frequency.
Options Menu
►
There are some options at the bottom of the screen:
: Screenshot.
: Back to home screen.
Settings
►
Click on the MENU icon
menu. The UPSTREAM function has these options:
Frequency step: It allows you to select full span maximum frequency
(0.25 MHz, 1 MHz, 8 MHz, other value).
Full span maximum frequency: It allows you to select full span
maximum frequency (900 MHz, 1700 MHz, other value).
Chapter 3: MEASUREMENT
at the upper right corner to access the Settings
17 September 2018
