OCULUS BIOM 5c Instruction Manual page 43

Instruction Manual BIOM® 5 (G/55400/0413/en)
®
Dimensions BIOM 5ml and BIOM
Dimensions (W x D x H)
Overall height
Travel of the safety rod
Weight
BIOM® 5
m
BIOM® 5
ml
BIOM® 5
c
BIOM® 5
cl
Reduction lens
Front lens: depending on the model
Operating Conditions for Optical System
Temperature
Humidity
Air pressure
Sterilization and Disinfection Procedures
BIOM® 5
Reduction lens (only the reduction lenses listed in
this manual)
Ophthalmoscopy lens (only the lenses listed in this manual)
Adapter
Drive belt
17 Technical Data
®
5cl
63 x 112 x 124-160 mm
(2.5 x 4.4 x 4.9-6.2 in)
approx. 137-173 mm
(5.4 - 6.8 in)
approx. 29 mm (1.14 in)
approx. 186 g (0.41 lbs)
approx. 190 g (0.42 lbs)
approx. 250 g (0.56 lbs)
approx. 260 g (0.57 lbs)
approx. 30 g (0.07 lbs)
approx. 3—10 g
(0.007 —0.02 lbs)
+10°C to +40°C
30% to 70%
700 hPa to 1060 hPa
Steam auto-
clave, 134°C
Steam auto-
clave, 134°C
Steam auto-
clave, 134°C
Steam auto-
clave, 134°C
Steam auto-
clave, 134°C
39 / 40
