Chapter 3 Error Code

3.1 Error Code Details

3.1.1 Error Code Details
iR2016J / iR2016 / iR2020 / / iR2016i / iR2020i
E000
E001
E002
E003
E007
E010
E019
E052
E100
E197
E716
Display
Detail Code
Main Cause/Symptom
Code
0000
Startup error
The temperature detected by the main
or sub thermistor does not rise to the
specified value during startup control.
0000
Abnormally high temperature (detected by main thermistor)
The main thermistor detected an
abnormally high temperature (240 deg
C) during temperature control.
0001
Abnormally high temperature (detected by sub thermistor)
The sub thermistor detected an
abnormally high temperature (295 deg
C) during temperature control.
0000
Low temperature during temperature control.
The target temperature is not reached
during temperature control.
0000
Abnormally low temperature (detected by main thermistor)
After the temperature detected by the
main thermistor has reached the
specified value, it does not reach the
specified value during initial rotation.
0001
Abnormally low temperature (detected by sub thermistor)
After the temperature detected by the
sub thermistor has reached the
specified value, it does not reach the
specified value during initial rotation.
0000
Fixing film sensor failure
The fixing film sensor is faulty.
0000
Main motor failure
The main motor is faulty.
0000
Waste toner full detection
The waste toner full state was detected. Replace the drum unit.
0001
Waster toner full detection sensor is faulty.
The waste toner full state was detected
continuously for five or more seconds
while the main motor was turning.
0000
Erroneous connection to duplex unit
Disconnection of the duplex unit was
detected after power-on, detection of
normal connection to the duplex unit,
and start of communication.
0000
BD detection PCB failure
The BD detection PCB is faulty.
0000
Printer engine communication error
Erroneous communication between the
DC controller PCB and image
processor PCB was detected.
0000
Erroneous communication with optional cassette
Disconnection of the optional cassette
was detected after power-on, detection
of normal connection to the optional
cassette, and start of communication.
T-3-1
Countermeasure
- Check the fixing film connector.
- Replace the fixing film unit.
- Replace the DC controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit.
- Replace the DC controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit.
- Replace the DC controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit.
- Replace the DC controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit.
- Replace the DC controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit.
- Replace the DC controller PCB.
- Check the connector of the fixing film
sensor.
- Replace the fixing film sensor.
- Replace the DC controller PCB.
- Check the connector of the main motor.
- Replace the main motor.
- Replace the DC controller PCB.
- Check the connector of the waster toner full
sensor.
- Replace the waste toner full sensor.
- Replace the DC controller PCB.
- Check the connectors of the duplex unit and
DC controller PCB.
- Replace the duplex controller PCB.
- Replace the DC controller PCB.
- Check the connector of the BD detection
PCB.
- Replace the laser scanner unit.
- Replace the DC controller PCB.
- Check the connectors of the DC controller
PCB and image processor PCB.
- Replace the DC controller PCB for normal
connection.
- Replace the image processor PCB.
- Check the connectors of the optional cassette
PCB and DC controller PCB.
- Replace the optional cassette PCB for
normal connection.
- Replace the DC controller PCB.
