Owner´s manual Koala Design and Function
Lights
Lights
Press the switch to turn on the lights
Indicators
of the wheelchair.
Indicators
Pressing the right or left arrow acti-
vates the chair's indicators.
Fig.15. Light/indicator switches
Warning horn
Press the button to sound the horn and
attract attention.
Joystick
Fig.16. Horn switch
The joystick is used to regulate the
speed of the wheelchair forwards or
backwards, to turn and to brake.
The speed is regulated proportionally
by moving the joystick forwards or
backwards.
The speed is directly proportional to
the movement of the joystick (small
movement low speed - large move-
ment high speed).
The wheelchair is turned by moving
the joystick to the left or right.
The wheelchair is braked by moving
the joystick back to the neutral position
or letting it go.
Fig.17. Joystick
