Owner´s manual Koala
Battery voltage indicator
The window display on the control
panel (fig.12) shows the following indi-
cator lights:
Red+Yellow+Green = Fully charged
Red+Yellow
Red
Warning symbol
When you press the switch, the indica-
tor lamps flash on the control panel for
the warning symbol (red lamp) and for
both indicator lights (green lamp). If
your wheelchair has lights, both indi-
cator lamps flash too, to attract attention.
NB! This function works even when
the start button is switched off
Speed selector
The speed can be set in 5 stages, and
one or more of the indicator lamps light
depending on which speed range has
been selected.
1 - 2 lamps = Low speed
2 - 4 lamps = Medium speed
5 lamps = Maximum speed
= Half charged
= Charge the batteries
Fig.12. Battery voltage indicator
Fig. 13. Switch warning
Fig. 14. Speed selector
-31-
Design and Function
