Owner´s manual Koala Design and Function
Main circuit-breaker
You can reset the main circuit-breaker if it trips. It is on the underside of the
chassis, over the right, rear wheel, see fig. 7. The main circuit-breaker is
protected from dirt and water by a rubber flap, which you can easily fold back.
Charging fuse
The charging fuse is next to the main circuit-breaker, on the underside of the
chassis, over the right, rear wheel, see fig. 7.
Charging fuse
15A
Main circuit-
breaker
63A
Fig.7. Main circuit-breaker and
charging fuse
