Assembly; Package Contents - Taurus TF-ERGO-X Assembly And Operating Instructions Manual

3

ASSEMBLY

3.1

Package contents

The package contains the parts represented in the illustration, including a power cable with mains plug. If
one of the illustrated parts is missing, please contact your contract partner.
Main frame
Console
(J1)Screw
M8*60
# 17
#13
(G-1)Foot Support
(H1) Pedal( left)
(H2) Pedal ( right)
(J2)Screw (J3)Spacer
M8*30 Ring
Cu stom ize d Wrenc h
#15
Front stabilizer
Rear stabilizer
(G-2)End Cap
Metal xing plate
(J4)NUT
(J5)Screw
M8 M6*16
4m/m 5m/m
Console tube
Swing handle
bar (L-R)
(J6)Screw
M10*20
6m/m
