INSTALLATION and OPERATION MANUAL
Self-Priming Centrifugal Pumps
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Series: B4, B6, B9, B12,
B19*, B21*, SB4,
SB6, SB9, SB12,
SB19*, SB21*,
BH7, SBH7
Universal Drive
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
Form No. 099811-Rev. H
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Crane Crown B4 Series
Summary of Contents for Crane Crown B4 Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notifi cation.
-
Page 2: Table Of Contents
Other brand and product names are trademarks or registered trademarks of their respective holders. ® CROWN is a registered trademark of Crane Pumps & Systems, Inc ® Tefl on is a registered trademark of E.I. Dupont de Nemours and Company ®... -
Page 3: Safety First
(fl ammable, caustic, etc.) unless the pump is specifi cally designed and designated to handle them. IMPORTANT! - Crane Pumps & Systems, Inc. is not responsible for losses, injury, or death resulting from a CAUTION! - Do not block or restrict discharge hose, as failure to observe these safety precautions, misuse or discharge hose may whip under pressure. -
Page 4: Specifications B4, Sb4, B6, Sb6, B9, Sb9, Series Pumps
SECTION: A - PUMP SPECIFICATIONS: B4, B6, B9, SB4, SB6, SB9 SUCTION/DISCHARGE: SEAL:B Design ...Single Mechanical B4, SB4, B6, SB6 ....1½” x 1½" NPT, Female Lubrication ..Grease, with Self-Feeding Lubricator B9, SB9 .......2" X 2" NPT Female Material ..Rotating Faces - Carbon LIQUID TEMPERATURE ..160°F (71°C) Continuous Stationary Faces - Ceramic VOLUTE/WEARPLATE .. -
Page 5: B12, Sb12, Bh7, Sbh7 Series Pumps
SECTION: A - PUMP SPECIFICATIONS: B12, SB12, BH7, SBH7 SUCTION/DISCHARGE ... 2" X 2" NPT Female SEAL: LIQUID TEMPERATURE ..160°F (71°C) Continuous B & BH Design ...... Single Mechanical VOLUTE/WEARPLATE Lubrication ....Grease, with Self-Feeding B & BH ......Cast Iron ASTM A-48, Class 30 Lubricator SB &... -
Page 6: B19, Sb19, B21, Sb21, Series Pumps
SECTION: A - PUMP SPECIFICATIONS: B19, SB19, B21, SB21 SUCTION/DISCHARGE ..3" X 3" NPT Female Design ....Single Mechanical LIQUID TEMPERATURE ..160°F (71°C) Continuous Lubrication ..Pumped Fluid VOLUTE/WEARPLATE Material ..... Rotating Faces - Carbon B ....... Cast Iron ASTM A-48, Class 30 Stationary Faces - Ceramic SB ..... -
Page 7: General Information (Receiving, Storage, Service Centers)
For the location of the nearest Crown Service Center, check without a strainer on the end of the suction line your representative or Crane Pumps & Systems, Inc., in to prevent sticks, stones, rags and other foreign Piqua, Ohio, telephone (937) 778-8947 or Crane Pumps &... -
Page 8: Preventative Maintenance
FIGURE 1 3. In cold weather operation, the pump will not freeze as If the pump is inoperative for a long period of time, or appears long as it is running. However, it may freeze if it is not drained not to use any grease, remove and clean the cup thoroughly. - Page 9 1 - Ni-Resist Stationary Seat 1A - Ceramic Stationary Seat 2 - Buna-N Seat Ring 2A - Buna-N Seat Cup 3 - Stainless Retainer 4 - Stainless Drive Band 5 - Stainless Spring 6 - Stainless Springholder 7 - Cran-Carb® Mating Ring 7A - Carbon Mating Ring 8 - Buna-N Bellows Cross SEction of SEals.
-
Page 10: Trouble Shooting
TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. SYMPTOM POSSIBLE CAUSE(S) CHECK 1. Air leak in suction side of system. a. -
Page 11: Replacement Parts
TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. SYMPTOM POSSIBLE CAUSE(S) CHECK 1. Drawdown too great a. Automatic cut-off control for failure a. -
Page 12: B4, B6, B9, Cross-Section
MODEL: B4, B6, B9... -
Page 13: Parts List
MODEL: B4, B6, B9 PARTS LIST ITEM QTY. PART NO DESCRIPTION 20-14-1 Washer, Lock, Split, 3/8”, Stainless MT-8650 Gasket, Flange 1-36-1 Screw, Hex Hd. 3/8-16 x 1.25”Lg, Stainless FP-4487 Flange 1-1/2” (B4, B6) FP-4488 Flange 2” (B9) T-28700 Gasket, Pump Case 20-22-1 Washer, Lock, Split 5/16”, Stainless... -
Page 14: Sb4, Sb6, Sb9 Cross-Section
MODEL: SB4, SB6, SB9... -
Page 15: Parts List
MODEL: SB4, SB6, SB9 PARTS LIST ITEM QTY. PART NO DESCRIPTION 1-36-1 Screw, Hex Hd 3/8-16 x 1.25”Lg, Stainless M-9597 Gasket, Flange Viton 20-14-1 Washer, Lock, Split 3/8”, Stainless FSS-4487 Flange 1-1/2” (SB4, SB6) FSS-4488 Flange 2”, (SB9) M-9595 Gasket, Pump Case Viton 1-156-1 Screw, Hex Hd. -
Page 16: B12 Cross-Section
MODEL: B12... -
Page 17: Parts List
MODEL: B12 PARTS LIST ITEM QTY. PART NO DESCRIPTION 20-15-1 Washer, Lock, Split 1/2”, Stainless 1-68-1 Screw, Hex Hd. 1/2-13 x 1.25”Lg, Stainless FP-4498 Flange 2” MT-8655 Gasket, Flange T-28699 Gasket, Pump Case 20-14-1 Washer, Lock, Split 3/8”, Stainless 1-34-1 Screw, Hex Hd. -
Page 18: Sb12 Cross-Section
MODEL: SB12... -
Page 19: Parts List
MODEL: SB12 PARTS LIST ITEM QTY. PART NO DESCRIPTION 20-15-1 Washer, Lock, Split 1/2”, Stainless 1-68-1 Screw, Hex Hd. 1/2-13 X 1.25”Lg, Stainless FSS-4498 Flange 2” M-9596 Gasket, Flange Viton M-9594 Gasket, Pump Case 20-14-1 Washer, Lock, Split 3/8”, Stainless 1-34-1 Screw, Hex Hd. -
Page 20: Bh7 Cross-Section
MODEL: BH7... -
Page 21: Parts List
MODEL: BH7 PARTS LIST ITEM QTY. PART NO DESCRIPTION 20-15-1 Washer, Lock, Split 1/2”, Stainless 1-68-1 Screw, Hex Hd. 1/2-13 x 1.25” Lg, Stainless FP-4498 Flange 2” MT-8655 Gasket, Flange T-28699 Gasket, Pump Case 20-14-1 Washer, Lock, Split 3/8”, Stainless 1-34-1 Screw, Hex Hd. -
Page 22: Sbh7 Cross Section
MODEL: SBH7... -
Page 23: Parts List
MODEL: SBH7 PARTS LIST ITEM QTY. PART NO DESCRIPTION 20-15-1 Washer, Lock, Split 1/2”, Stainless 1-68-1 Screw, Hex Hd. 1/2-13 X 1.25” Lg, Stainless FSS-4498 Flange 2” MT-8655 Gasket, Flange T-28699 Gasket, Pump Case 20-14-1 Washer, Lock, Split 3/8”, Stainless 1-34-1 Screw, Hex Hd. -
Page 24: B19, B21 Cross-Section
MODEL: B19, B21... -
Page 25: Parts List
MODEL: B19, B21 PARTS LIST ITEM QTY. PART NO DESCRIPTION 20-15-1 Washer, Lock, Split 1/2”, Stainless 1-71-1 Screw, Hex Hd. 1/2-13 x 1.75” Lg, Stainless FP-4499 Flange 3” MT-8655 Gasket, Flange T-28699 Gasket, Pump Case 20-14-1 Washer, Lock, Split 3/8”, Stainless 1-34-1 Screw, Hex Hd. -
Page 26: Sb19, Sb21 Cross-Section
MODEL: SB19, SB21... -
Page 27: Parts List
MODEL: SB19, SB21 PARTS LIST ITEM QTY. PART NO DESCRIPTION 20-15-1 Washer, Lock, Split 1/2”, Stainless 1-71-1 Screw, Hex Hd. 1/2-13 X 1.75” Lg, Stainless FSS-4499 Flange 3” M-9596 Gasket, Flange Viton M-9594 Gasket, Pump Case 20-14-1 Washer, Lock, Split 3/8”, Stainless 1-34-1 Screw, Hex Hd. -
Page 28: Warranty
Limited 24 Month Warranty Crane Pumps & Systems warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for twenty-four (24) months after manufacture date, when installed and maintained in accordance with our instructions.This warranty gives you specifi c legal rights, and there may also be other rights which vary from state to state. -
Page 29: Start-Up Report For Electric Motor Drive
Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material. - Page 30 A Crane Co. Company START-UP REPORT General Information Pump Owner’s Name: __________________________________________________________ Address: ____________________________________________________________________ Location of Installation: _________________________________________________________ Contact Person: __________________________________Phone: _______________________ Purchased From: _____________________________________________________________ Nameplate Data Pump Model #: ___________________ Serial #: _____________________________________ Part #: __________________________ Impeller Diameter: ____________________________ Voltage: _________ Phase: _____ Ø...
-
Page 31: Start-Up Report For Engine Driven Pumps
( ) Operator: ________________________ ( ) Contactor: ____________________________ ( ) Other: ___________________________ All parties should retain a copy of this report for future trouble shooting/reference A Crane Co. Company 420 Third Street 83 West Drive, Brampton Piqua, Ohio 45356 Ontario, Canada L6T 2J6... - Page 32 Notes...
