The DC Power cables section includes subsections:
■
f201 DC Power cables
Note: If you lengthen the DC Power cable, you must calculate and measure the additional voltage drop
to ensure that 96 VDC is available at the laser's DC POWER connector under full-load conditions.
Depending on the additional length required, you may need to use larger gauge wire.
f201 DC Power cables
DC Power cables for f201 lasers are manufactured with #12 AWG wire; however, DC input current is split
between two positive (+) and two negative (–) conductors. Firestar f201 DC Power cables are available in
5 meter (16.4 ft) and 7 m (23 ft) lengths. The standard length is 5 meters. The minimum bend radius for
f201 DC Power cables must be greater than 124.5 mm (4.9 in).
F201 DC Power cables are wired into a Canon-type ME3476L14-4S plug that connects with a matching
receptacle on the laser's rear panel. Table below provides pinout information for f201 DC Power cable
connectors.
Table 4-7 f201 DC Power connector pinouts.
Function Wire Color Code
+96 VDC Red
– VDC Black
+96 VDC Red
– VDC Black
Ground Green
SYNRAD f201 Operator's Manual Version 3.2
74

DC Power cables

Terminal Designation
A
B
C
D
Shell
