  • Page 1 4600 Campus Place Mukilteo, WA 98275 1.800.SYNRAD1 1.425.349.3500 1.425.349.3667 e-mail synrad@synrad.com www.synrad.com...
  • Page 2 OEM v30 Operator’s Manual Version 2 SYNRAD is a registered trademark of Novanta Corporation. Novanta Corporation © © 2019. All Rights Reserved. No reproduction without written authorization. DATE: March 2019...

  • Page 3: Table Of Contents

    Control connections ........................Operation Controls and indicators .....................2-2 OEM v30 front panel ........................OEM v30 rear panel ........................Initial start-up .......................2-4 Status LEDs ............................With a UC-2000 Controller ......................Without a UC-2000 Controller ....................SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 4 Storage/shipping ..........................Cleaning optical components ....................Troubleshooting ......................4-6 Introduction............................Operational flowchart ........................LED/output signal status ......................4-12 Laser fault indications ........................4-12 Resetting faults ..........................4-13 Laser troubleshooting........................4-17 Beam delivery optics ........................Index SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 5 Figure 3-18 OEM v30 fan-cooled package outline and mounting dimensions ....................3-23 Figure 3-19 OEM v30 water-cooled package outline and mounting dimensions ....................3-24 Figure 3-20 OEM v30 air-cooled packaging instructions ......3-25 Figure 3-21 OEM v30 fan-/water-cooled and pre-aligned packaging instructions ....................3-26 SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 6 List of Figures (cont.) Figure 4-1 Operational flowchart ...............4-7 Figure 4-2 DB-9 Quick Start Plug wiring diagram .........4-14 SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 7 Table 4-10 Laser Enable input not connected ..........4-11 Table 4-11 Over Temperature fault ..............4-11 Table 4-12 DC Voltage fault ...................4-11 Table 4-13 PWM Sense/Control Board fault ............4-12 Table 4-14 Laser fault codes ..................4-12 SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 8: Synrad Oem V30 Operator's Manual Version

    Trademark/copyright information SYNRAD and Firestar are registered trademarks of SYNRAD All other trademarks or registered trademarks are the property of their respective owners. © 2019 by SYNRAD All rights reserved. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 9 Warranty information This is to certify that v30 lasers are guaranteed by SYNRAD to be free of all defects in materials and workmanship for a period of one year from the date of purchase. This warranty does not apply to any defect caused by negligence, misuse (including environmental factors), accident, alteration, or im- proper maintenance.
  • Page 10 Reference materials Your Regional Sales Manager can provide reference materials including Outline & Mounting drawings, Operator’s Manuals, Technical Bulletins, and Application Newslet- ters. Most of these materials are also available directly from SYNRAD web site at http:// www.synrad.com viii...
  • Page 11 EU headquarters For assistance in Europe, contact SYNRAD European subsidiary, Synrad Europe, at: © Novanta Distribution (USD) GmbH © Parkring 57-59 85748 Garching bei München, Germany Phone: +49-89-31707-0 web: www.synrad.com e-mail: EMEA- service@novanta.com SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 12 ■ Inventory – displays and describes all components shipped with your laser. ■ Mounting – describes how to attach the OEM v30 laser to a mounting surface. ■ Connecting – explains how to cool the laser and connect both power and control cables. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 13 getting started Introduction The Introduction section includes subsections: ■ Firestar nomenclature ■ Model numbers The Firestar v30 laser is designed to provide OEMs a compact, cost-effective 30 W laser package. Al- ® though the OEM v30 is part of the Firestar family of lasers, its user interface differs significantly from the standard Firestar interface design.
  • Page 14 Upon arrival, inspect all shipping containers for signs of damage. If you discover shipping damage, document the damage (photographically if possible), then immediately notify the shipping carrier and SYNRAD, Inc. The shipping carrier is responsible for any damage occurring during transportation from SYNRAD, Inc. to your receiving dock. Packaging guidelines ■...
  • Page 15 Table 1-1 lists items included in the Firestar v30 ship kit. Table 1-1 Ship kit contents Shipping Box Contents Shipping Box Contents SYNRAD Firestar OEM v30 Laser ....1 Mounting Bolts ............3 SYNRAD CO Lasers Manual CD......1 Spare Fuse ..............2 Quick Start Plug (except SA models) ....1 Final Test Report (not shown) ......1...
  • Page 16 Inventory Contents description Each item listed in Table 1-1 is described below. SYNRAD Firestar OEM v30 Laser – for cutting, welding, drilling, and marking a wide variety of products and materials. SYNRAD CO Lasers Manual CD – contains a Firestar v30 manual that provides setup, operation, and maintenance information for your OEM v30 laser.
  • Page 17 To prevent possible distortion of the tube, you must fasten the v30 base plate di- rectly to your mounting surface. Caution SYNRAD does not recommend mounting lasers in a vertical “head- down” or “tail-down” orientation. If you must mount your laser in possible this manner, please contact the factory for limitations as a vertical orientation increases the risk of damage to the laser’s output optic.
  • Page 18 Because Firestar’s cooling tubing is specified in inch sizes, do not use metric tubing fittings unless you have installed the appropriate inch-to-metric tubing adaptors. The use of metric fittings on inch size tubing will lead to coolant leaks or may allow the pressurized tubing to blow-off the fitting. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 19 Avoid glycol-based additives because they reduce the coolant’s heat capacity and high concentrations may affect power stability. For SYNRAD lasers, the minimum coolant setpoint is 18 °C (64 °F) so glycol is not necessary unless the chiller is subjected to freezing temperatures. If tap water is used, chloride levels should not exceed a concentration of 25 parts per million (PPM).

  • Page 20: Table 1-2 Dew Point Temperatures

    Caution Operating the laser at coolant temperatures above 22 °C (72 °F) may result in decreased laser performance and/or premature failure of possible electronic components. equipment damage SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 21: Figure 1-3 Oem V30 Cooling Connections

    getting started Connecting Cooling tubing connections The following procedure will guide you in configuring the most efficient cooling system. Please connect your system exactly as described below. To connect cooling tubing to your v30 laser, refer to Figure 1-3 and perform the following steps. Figure 1-3 OEM v30 cooling connections Cut and connect a length of 1/2-inch O.D.
  • Page 22 Air-cooled v30 (SAG) lasers are shipped without cooling fans so customers must provide some type of air cooling to prevent overheating. SYNRAD recommends using two cooling fans rated for at least 4.0 m min (140 CFM) at a static air pressure of 13.2 mm H O (0.52 in H...
  • Page 23 getting started Connecting Figure 1-5 Recommended fan shroud design – rear cooling Guidelines for rear cooling ■ Design the cooling shroud so that it encloses the full length of both the laser and the cool- ing fan. ■ Fit the shroud snugly against the laser’s heatsink fins so air is ducted between the fins and not around them.
  • Page 24 (24 A peak for a minimum of 0.5 ms) while fan-cooled (SFG) models require 30 VDC at 16 A (24 A peak for a minimum of 0.5 ms). SYNRAD recommends our PS-2, a 30 V, 750 W DC power supply (shown in Figure 1-6).
  • Page 25 getting started Connecting Important Note: The OEM v30 control board does not incorporate a built-in tickle generator; there- fore, an externally-generated 5 kHz, 1 µs tickle pulse must be applied between PWM Command signals to achieve optimum laser performance. See Controlling laser power in the Technical Reference chapter for tickle signal descriptions.
  • Page 26 You may need to refer to Interface connections, in the Technical Refer- ence chapter, for Interface A and Interface B connection details. To connect a UC-2000 Controller (available separately from SYNRAD), perform the following steps: Interface A (DB-9) connector Remove DC power from the laser.
  • Page 27 getting started Connecting Connect your system’s +5V enable input to Pin 7, Laser Enable, on the RJ45 plug. Connect your RJ45 plug to the Interface B (RJ45) connector on the rear of the laser. Connect the miniature DC power plug on the UC-2000’s Power/Control cable to the miniature connector on the wall plug transformer cable.
  • Page 28 Do not allow the laser beam to contact a person! This product emits an invisible laser beam that is capable of seriously burning human tissue. Always be aware of the beam’s path and always use a beam block while testing. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 29: Terms

    For laser systems being used or sold outside the U.S.A., customers should refer to and follow the laser safety precautions described in European Normative and International Electrotechnical Commission documents IEC/ TR 60825-14:2014, Safety of Laser Products – §14: A User’s Guide. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 30: General Hazards

    Do not use air dusters containing difluoroethane in any area adjacent to CO 2 laser systems because difluoroethane persists for long time periods over wide areas. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 31 Always wear safety glasses or protective goggles with side shields to reduce the risk of dam- age to the eyes when operating the laser. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 32: Other Hazards

    III, Chapter 6 and Appendix III are good resources for laser safety information. Another excellent laser safety resource is the Laser Institute of America (LIA). Their compre- hensive web site is located at http://www.lia.org. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 33 This laser component does not comply with standards for complete laser products as specified by 21 CFR 1040.10 or IEC 60825-1. SYNRAD, Inc. 4600 Campus Place, Mukilteo WA 98275 425.349.3500 This laser product is manufactured under one or more of the following U.S. Patents:...

  • Page 34: Agency Compliance

    Standards for complete laser processing systems as specified by 21 CFR, §1040 or EN 60825-1. SYNRAD assumes no responsibility for the compli- ance of the system into which OEM laser products are integrated.

  • Page 35: Federal Communications Commission (Fcc) Requirements

    § §§ of 47 CFR, 213. Interference Potential In our testing, SYNRAD has not discovered any significant electrical interference traceable to laser lasers. System Maintenance Ensure that all exterior covers are properly fastened in position. Measures to Correct Interference If you suspect that your laser interferes with other equipment, take the following steps to...

  • Page 36: European Union (Eu) Requirements

    OEM lasers are OEM products intended for incorporation as components in laser processing systems. As supplied by SYNRAD, these lasers do not meet the requirements of EN 60825-1 without additional safeguards. European Union Directives state that “OEM laser products which are sold to other manufacturers for use as components of any system for subsequent sale are not subject to this Standard, since the final product will itself be subject to the Standard.
  • Page 37 Illuminates green when laser temperature is within operating limits, changing to red when thermal limits are exceeded. Warning laser exterior labels Labels attached to various external housing locations to warn personnel of potential laser hazards. 1 Not available on laser OEM lasers SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 38 ® responsible for meeting all applicable Standards to obtain the CE mark. To aid this compliance process, SYNRAD testing program has demonstrated that laser lasers comply with the relevant requirements of Directive 2014/30/EU, the Electromagnetic Compatibility Directive, as sum- marized in the table below.

  • Page 39: Declaration Of Conformity

    Radiated Emissions, Group 1, Class A  EN 61000‐6‐4:2007  Conducted Emissions, Group 1, Class A  EN 61000‐6‐2:2005  Electrostatic Discharge Immunity  EN 61000‐6‐2:2005  RF Electronic Fields Immunity  EN 61000‐6‐2:2005  Electrical Fast Transient/Burst Immunity  EN 61000‐6‐2:2005  Conducted RF Disturbances Immunity    *OEM lasers do not comply with EN 60825‐1:2014, Safety of Laser Products. Buyers of OEM laser products are  solely responsible for meeting applicable Directives and Standards for CE compliance and marking.    Corporate Officer:  European Contact:  Novanta Distribution (USD) GmbH  Parkring 57‐59  85748 Garching bei München, Germany    Tim Freni, Quality Manager of SYNRAD                 Dated:  3/4/19 MADE IN THE U.S.A.  900‐20976‐18 Rev B  Figure 2-4 Declaration Document. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 40 Use information in this chapter to familiarize yourself with OEM v30 controls and indi- cators and to begin operating the laser. This chapter contains the following information: ■ Controls and indicators – displays and describes exterior controls and indicators on OEM v30 lasers.

  • Page 41: Operation

    Optical Accessories Mounting – provides six threaded holes (8–32 UNC) for mounting optional beam delivery components Because excessive weight may damage the laser, consult SYNRAD before mounting components not specifically designed as Firestar options. Refer to OEM v30 package outline drawings in the Technical Reference chapter for mounting hole dimensions.

  • Page 42: Oem V30 Rear Panel

    10 WATER IN Port (water-cooled models only) – labeled IN, this connection provides the cooling water inlet to the v30’s coolant path. 11 WATER OUT Port (water-cooled models only) – labeled OUT, this connection provides the cooling water outlet from the v30’s coolant path. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 43: Initial Start-Up

    Remove the aperture seal before firing the laser. The self-adhesive seal is installed to prevent dust from entering the laser housing during possible shipment and installation and must be removed before operation. equipment damage SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 44: With A Uc-2000 Controller

    Press the UC-2000’s Lase On/Off button to stop lasing. LASE indicators on the UC-2000 and the laser should turn off. If your OEM v30 laser fails to lase, refer to Troubleshooting in the Maintenance/Troubleshooting chapter for troubleshooting information. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 45: Without A Uc-2000 Controller

    Remove the PWM Command signal from the laser and re-apply tickle pulses every 200 µs. The LASE indicator on the laser should turn off. If your OEM v30 laser fails to lase, refer to Troubleshooting in the Maintenance/Troubleshooting chapter for troubleshooting information. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 46: Technical Reference

    OEM v30 general specifications – provides specifications for Firestar OEM v30 lasers. ■ OEM v30 package outline drawings – illustrates laser package and mounting dimen- sions for OEM v30 lasers. ■ OEM v30 packaging instructions – illustrates how to package v30 lasers for shipment using SYNRAD-supplied packaging materials.

  • Page 47: Technical Overview

    OEM v30 laser Laser tube Firestar OEM v30 lasers were developed using new technology patented by SYNRAD, Inc. This patented ® “v” technology, based on a combination of free-space and waveguide resonator designs, enables SYNRAD to economically produce a symmetrical laser beam from a small but powerful laser capable of operating for many years with virtually no maintenance.

  • Page 48: Optical Setup

    Note: Optical components in the beam path must always be aligned to the actual beam path, not the laser faceplate. Because of slight variations in laser construction, the beam path may not always be centered in, or perpendicular to, the aperture in the faceplate. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 49 > 99.997% purity; filtered to ISO Class 1 particulate level Nitrogen Cutting/Drilling High Purity Grade > 99.9500% purity; filtered to ISO Class 1 particulate level Oxygen Cutting/Drilling Ultra Pure Grade > 99.9998% purity; filtered to ISO Class 1 particulate level SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 50: Controlling Laser Power

    Operating modes Control signals Much of the information provided in this section describes the use of a SYNRAD UC-2000 Universal La- ser Controller to provide tickle and PWM Command signals to the v30 laser. If using an alternate method of laser control, thoroughly review this section, Controlling laser power, as well as the following section, Interface connections, for an understanding of the signal requirements necessary to control Firestar lasers.
  • Page 51 50% duty cycle; if the amplitude is high for 190 µs and low for 10 µs, it has a 95% duty cycle. The following figure illustrates PWM Command signal parameters while the following table lists PWM signal specifications. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 52: Operating Modes

    To generate the proper analog current, install a D/A card that can generate 4 mA (laser off ) to 20 mA (maximum power). Software able to control your analog output card is required for either configu- ration. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 53 (PWM) section for information regarding high-frequency operation. Note: SYNRAD lasers are designed for maximum performance at a 95% duty cycle. Increasing the maximum PWM percentage beyond 95% greatly increases the laser’s heat load with little or no corresponding increase in laser output power.

  • Page 54: Interface Connections

    OEM v30’s rear panel while the following table on the next page provides connection descriptions. Pin 5 Pin 1 INTERFACE LASE Pin 9 Pin 6 Figure 4-4 Interface A (DB-9) connector pinouts SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 55 When switching +5 VDC to the Laser Enable input on Pin 9 through a switch or relay contact, we highly recommend adding a 100 Ohm, 1/4 watt resister in series between the switching device and the Laser Enable input. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 56 DB-9 (INTERFACE A) CONNECTOR – INPUT PINS 430 Ohm PWM POSITIVE (+) (1) PWM NEGATIVE (–) (6) EMI Filter 100 Ohm FIRESTAR v30 LASER ENABLE (9) INPUT CIRCUITRY GND (8) Figure 4-5 DB-9 input equivalent schematic SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 57 OEM v30’s DC Out output (+5 V, 250 mA). DB-9 (INTERFACE A) CONNECTOR PINS (5) DC OUT Laser enabled when switch or contact closed (9) LASER ENABLE 100 Ohm Figure 4-6 OEM v30 powered Laser Enable circuit SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 58 The Interface A (DB-9) connector also includes a +5 VDC output voltage source, DC Out. This output can provide a maximum current of 250 mA and is useful for driving the Laser Enable input as described in the DB-9 input circuitry subsection. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 59 EMI Filter 100 Ohm FIRESTAR v30 (4) OVERTEMP FAULT OUTPUT CIRCUITRY EMI Filter 100 Ohm (7) DC VOLTAGE FAULT 5 VDC, 250 mA (5) DC OUT (8) GND Figure 4-9 DB-9 output equivalent schematic SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 60: Interface B (Rj45) Connector

    Figure below illustrates the pin arrangement of the Interface B (RJ45/8P8C) connector on the OEM v30’s rear panel while Table 3-6 on the next page provides connection descriptions. Pin 1 Pin 8 INTERFACE LASE Figure 4-11 Interface B (RJ45) connector pinouts SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 61 100 Ohm, 1/4 watt resister in series between the switching device and the Laser Enable input. This connection is the ground, or return, reference for all RJ45 inputs and outputs. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 62 RJ45 (INTERFACE B) CONNECTOR – INPUT PINS 430 Ohm PWM POSITIVE (+) (1) PWM NEGATIVE (–) (6) EMI Filter 100 Ohm FIRESTAR v30 LASER ENABLE (7) INPUT CIRCUITRY GND (8) Figure 4-12 RJ45 input equivalent schematic SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 63 In this case, the customer must also supply the +5V voltage necessary to drive the circuit. RJ45 (INTERFACE B) CONNECTOR PINS (7) LASER ENABLE 100 Ohm Laser enabled when switch or contact closed +5 VDC (8) GND 5 VDC RETURN Figure 4-13 Customer powered Laser Enable circuit SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 64 Output Device Type and Specifications Laser OK 5V logic output buffer Temperature OK On state Vmin +4.5 VDC @ 50 mA Voltage OK On state (typical) +5.0 VDC @ 0.5 mA Off state Vmax +0.8 VDC SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 65 RJ45’s Laser OK status, or any other RJ45 output, using an isolated 5 VDC input module. 5 VDC ISOLATED INPUT RJ45 (INTERFACE B) CONNECTOR PINS MODULE (3) LASER OK (8) GND COM1 Figure 4-16 Laser OK output to PLC input SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 66: Oem V30 General Specifications

    5 Published specifications guaranteed at a temperature of 22 °C. Some performance degradation may occur in ambient temperatures above 22 °C. For air-cooled lasers, laser power typically decreases 0.5–1% per degree Celsius increase in ambient temperature. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 67: Oem V30 Package Outline Drawings

    OEM v30 package outline drawings Figure 4-17 OEM v30 air-cooled package outline and mounting dimensions SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 68 OEM v30 package outline drawings Figure 4-18 OEM v30 fan-cooled package outline and mounting dimensions SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 69 OEM v30 package outline drawings Figure 4-19 OEM v30 water-cooled package outline and mounting dimensions SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 70: Oem V30 Packaging Instructions

    OEM v30 packaging instructions Figure 4-20 OEM v30 air-cooled packaging instructions SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 71: Instructions

    OEM v30 packaging instructions Figure 4-21 OEM v30 fan-/water-cooled and pre-aligned packaging instructions SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 72: Maintenance

    Use information in this chapter to perform maintenance or troubleshoot your Firestar OEM v30 laser. This chapter contains the following information: ■ Maintenance – describes typical v30 maintenance procedures. ■ Troubleshooting – explains how to troubleshoot v30 problems. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 73: Disabling The V30 Laser

    Caution If you operate your laser or marking head in a dirty or dusty environ- ment, contact SYNRAD about the risks of doing so and precautions possible you can take to increase the longevity of your laser, marking head, and associated optical components.

  • Page 74: Storage/Shipping

    When finished, cap all cooling connections to prevent debris from entering the cooling system. When shipping SYNRAD lasers to another facility, we highly recommend that you ship the unit in its original SYNRAD shipping container. If you no longer have the original shipping box and inserts, contact SYNRAD Customer Service about purchasing replacement packaging.

  • Page 75: Troubleshooting

    Air bulb Clean air bulb Ethyl or isopropyl alcohol Spectroscopic or reagent grade Acetone Spectroscopic or reagent grade Lens wipe (preferred) Optical (cleanroom) quality Cotton balls or cotton swabs High-quality surgical cotton/high-quality paper-bodied SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 76 Carefully examine the optic under a good light. Certain contaminants or damage such as pitting cannot be removed. In these cases the optic must be replaced to prevent catastrophic failure. Repeat Steps 4 through 6 as required, removing all traces of contaminants and deposits. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 77: Introduction

    Contact SYNRAD or a SYNRAD Authorized Distributor for repair/replacement information. To troubleshoot the OEM v30 laser, it is necessary to understand the sequence of events that must happen before the laser can turn on and operate.

  • Page 78: Operational Flowchart

    DC power Yellow? Apply tickle pulses for 5–10 seconds and then send PWM Command signals to laser LASE indicator illuminates Red to indicate laser output Figure 5-1 Operational flowchart SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 79: Led/Output Signal Status

    Normal operating condition LED Indicator LED Status Output Signal DB-9 Output Status LASE (if tickle applied) Lase Indicator LASE (if PWM applied) Lase Indicator High Yellow Laser Ready High Overtemp Fault Green DC Voltage Fault SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 80 DB-9 Output Status LASE (if tickle applied) Lase Indicator LASE (if PWM applied) Lase Indicator Laser Ready Overtemp Fault Blinking DC Voltage Fault High 1 See the Laser fault indications section for details. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 81: Overview

    Normal operating condition LED Indicator LED Status Output Signal RJ45 Output Status LASE (if tickle applied) – – LASE (if PWM applied) – – Yellow Laser OK High Temperature OK High Green Voltage OK High SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 82 Output Signal RJ45 Output Status LASE (if tickle applied) – – LASE (if PWM applied) – – Laser OK Temperature OK High Blinking Voltage OK 1 See the Laser fault indications section for details. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 83: Laser Fault Indications

    RDY indicator flashing continuously). To reset an over temperature fault, lower coolant temperature below 22 °C (water-cooled) or 40 °C (air-/fan-cooled) and then cycle DC power. When the RDY LED illumi- nates without flashing, lasing is enabled. SYNRAD OEM v30 Operator’s Manual Version 2...

  • Page 84: Laser Troubleshooting

    PWM Sense/Control Board fault A PWM Sense or control board fault is indicated by both RDY and PWR indicators flashing continuously. If this fault occurs, the laser requires service—contact SYNRAD or a SYNRAD Authorized Distributor. Laser troubleshooting During normal operation or when laser faults occur, OEM v30 status LEDs and output signals annunciate laser status as previously described in Tables 5-2–5-13.
  • Page 85 If there is much less than one gallon in the container, check the cooling path for kinked or pinched cooling tubes and check the chiller for a clogged or dirty filter. SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 86 – Low (0V) Laser OK – Low (0V) PWR LED – 3 blink code Overtemp Fault – Low (0V) Temperature OK – High (+5V) DC Voltage Fault – High (+5V) Voltage OK – Low (0V) SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 87 Troubleshooting Possible Causes: ■ An DC Sense fault has occurred. If this fault occurs, the laser requires service—contact SYNRAD Customer Service or a SYNRAD Autho- rized Distributor. Symptom: ■ The following status LED and I/O states exist: LASE LED – Off Lase Indicator –...

  • Page 88: Beam Delivery Optics

    Caution If you operate your laser or marking head in a dirty or dusty environ- ment, contact SYNRAD about the risks of doing so and precautions possible you can take to increase the longevity of your laser, marking head, and associated optical components.
  • Page 89 A risk of exposure to toxic elements, like zinc selenide, may result when certain optical or beam delivery components are damaged. In serious the event of damage to laser, marking head, or beam delivery optics, contact SYNRAD, Inc. or the optics manufacturer for handling personal instructions. injury If the focusing optic is pitted, it must be replaced immediately.
  • Page 90 Worldwide headquarters, x coolant temperature, 1-9, 1-10 definition, 1 Continuous wave (CW) 3-8 dirty environments, 3-4, 4-2, 4-17 Control Board/PWM Sense Fault 4-10, 4-12, FCC, 6 4-13, 4-16 interface connectors, 1-14, 3-9, 3-15 SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 91 Divergence 3-2, 3-3 Daily inspections 4-2 specifications, 3-21 Danger definition, 1 explosive atmospheres, 1 eye protection, 1, 2-4, 4-6 Electrical connections 1-12—1-13 laser radiation, 1, 2-4, 4-3, 4-6, 4-18 Error codes. See Fault codes SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 92 1-3, 4-3 status LEDs, 2-4 technical overview, 3-2—3-4 with a UC-2000 Controller, 2-5 troubleshooting, 4-6—4-17 without a UC-2000 Controller, 2-6 Firestar base plate Input circuitry (DB-9) 3-9, 3-11—3-13 mounting, 1-6 equivalent schematic, 3-11 SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 93 3-8 3-17, 3-19, 4-8, 4-9, 4-11, 4-12, 4-13 external control, 3-7 signal description, 3-10, 3-16 gated operation, 3-8 signal specifications, 3-12, 3-18 Operational flowchart 4-7 Laser faults 4-8—4-17 Operator’s manual 1-5 SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 94 Over Temperature fault 3-10, 3-16, 4-9, 4-11, connecting, 1-14 4-12, 4-14 warning, 1-14 Over-temperature protection 7 wiring diagram, 4-14 Overtemp Fault output 3-13, 4-8, 4-9, 4-10, 4-13, 4-14, 4-15, 4-16 signal description, 3-10 signal specifications, 3-14 SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 95 RJ45 output circuit, 3-19 signal specifications, 3-19 OEM v30, 3-21 PWM Command signal, 3-7 Status LEDs 2-4, 3-9, 4-8—4-12, 4-13, 4-14, 4-15, 4-16 Warning aerosol dusters, 2, 4-17 Storage/shipping 1-3, 4-3 air contaminants, 2 definition, 1 SYNRAD OEM v30 Operator’s Manual Version 2...
  • Page 96 1-8 coolant temperature, 1-8, 1-9, 1-10, 2-5, 3-21, 4-12, 4-14 fittings, 1-7 flow rate, 1-8, 1-10, 4-14 tubing connections, 1-7 tubing guidelines, 1-7 Water In/Water Out ports 1-7, 1-10, 2-3 Worldwide headquarters x SYNRAD OEM v30 Operator’s Manual Version 2...
