- Page 1 KVM switch and rackmount screen technology User Manual CV-S101 Combo KVM Extender Designed and manufactured by Austin Hughes UM-CV-751-CV-S101-Q215V1 www.austin-hughes.com...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > CV-S101 Package Contents Transmitter Receiver Application < Part. 2 > Extending the KVM console port to 150 meters Extending the computer to KVM port to 150 meters Extending the computer up to 150 meters < Part. 3 > Keyboard Hotkey Command UM-CV-751-CV-S101-Q215V1 www.austin-hughes.com... -
Page 4: Part. 1 > Cv-S101
Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. -
Page 5: Transmitter
< 1.2 > Transmitter CV-S101 Local Computer Remote I/O Power Front Rear KB Mouse Power Status Status Description Power Solid Red Power is on ( from the local computer or power adapter ) No Light There is no Power Status Solid Blue The connection to Receiver is active Flashing Blue... -
Page 6: Receiver
< 1.3 > Receiver CV-S101 Local Computer Remote I/O Power Front Rear KB Mouse Local Remote Button Button Button Status Description Local Solid Blue Local port is pressed & connected to the local PC Blinking Blue Local port is pressed & no PC signal is detected No Light The local port is not selected or the power is off Remote... -
Page 7: Part 2 > Application
< Part 2 > Application CV-S101 < 2.1 > Extending the KVM console port to 150 meters USB Console KVM switch Monitor CE-6 combo KVM cable Transmitter Transmitter Front Rear Cat6 cable up to 150 meters Monitor CE-6 6ft combo KVM cable Front Receiver Rear... -
Page 8: Extending The Computer To Kvm Port To 150 Meters
< 2.2 > Extending the computer to KVM port to 150 meters CV-S101 Cat6 KVM port Cat5/6 dongle KB Mouse Rear Receiver Front DB-15 KVM port Cat6 cable up to 150 meters Monitor CE-6 6ft combo KVM cable Front Transmitter Rear UM-CV-751-CV-S101-Q215V1 www.austin-hughes.com... -
Page 9: Extending The Computer Up To 150 Meters
< 2.3 > Extending the computer up to 150 meters CV-S101 Monitor CE-6 6ft combo KVM cable Front Rear Transmitter Cat6 cable up to 150m Monitor CE-6 6ft combo KVM cable Receiver Front Rear UM-CV-751-CV-S101-Q215V1 www.austin-hughes.com... - Page 10 < Part 3 > Keyboard Hotkey Command CV-S101 You can switch the Receiver from “Local Host” port to “RJ-45” port and vice-versa through simple key se- quences made by the remote console side. To send commands to the Receiver, you must press the hotkey (default is Scroll Lock) twice within 2 seconds.
- Page 12 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2015 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-CV-S101-Q215V1 www.austin-hughes.com...
