POWER ON:
Press and release the power button on the inside of the headset
housing, shown in Figure 1. A voice message in the earpiece will say "Headset #,
Battery Full/Half or Low" and the power light on the opposite side of the earpiece will
go on (See Figure 2).
POWER OFF:
Press and hold the power button on the inside of the headset
earpiece for approximately 3 seconds. A voice message in the earpiece will say
"Headset off," and the power light on the opposite side of the earpiece will go off.
Figure 2
CONFIGURE HEADSET:
powering the unit ON. Immediately release all buttons after pressing the power button. All of these settings have
associated voice prompts when applying the setting. Please listen to confirm desired setting:
•
Hands Free (HF) on / off – Press and hold "B" and UP arrow to turn on HF. Press and hold "B" and
DOWN arrow to turn HFoff.
•
Auto HF (AHF) – Press "A1" (or A2) and the UP arrow to turn on the Auto HF mode. Set the base Xcvr
switch K1-3 to on. When you power the unit off AHF mode is not saved.
•
Language selection – Press and hold "A1" and the DOWN arrow to toggle between English and another
language. Doing this again toggles back to first language.
•
Registration to Base – Set base to accept registration and power up HS6000 while holding "B". Hold the
HS6000 within 2 meters of the base. (Must be done before use, see Wireless I/Q operation manual)
•
Play Status – Press "A2" and DOWN arrow buttons. (e.g. "Headset #, Battery Full/Half/Low,
English/Espanol, Hands-free on/off, firmware version #")
If you have questions regarding the HS6000, please call HM Electronics, Inc. at (800)848-4468.
OPERATING INSTRUCTIONS
Power
Light
Start with power OFF and press any of the following button combinations while
DRAFT
October 3, 2005
Transmit
Light
VOLUME UP:
Lightly press the "VOL" up-arrow
button on the side of the earpiece. Each time it is
pressed, a short beep will be heard in the earpiece.
VOLUME DOWN:
Lightly press the "VOL" down-
arrow button on the side of the earpiece. Each time it is
pressed, a short beep will be heard in the earpiece.
DRAFT
Figure 1
