SETUP

Power On/Off

To turn the power on
Press and release the red power button on the headset
earpiece. A voice message in the earpiece will say
"Headset #, Battery Full/Half/Low" and the red power
light will begin blinking. See Figure 1.
To turn the power off
Press and hold the power button for approximately
3 seconds. A voice message in the earpiece will say
"Headset off," and the power light will go off.

Configure Headset

Start with power OFF and press any of the following button combinations while turning the power ON.
Immediately release all buttons after pressing the power button. Each of these settings has an
associated voice prompt. Listen to the voice prompt to confirm the setting.
Hands Free (HF) on/off – Press and hold B and the
UP arrow
while you press the power button to turn
the headset on in the HF mode. With the power off,
press and hold B and the DOWN arrow
press the power button to turn off the HF mode.
Auto HF (AHF) – Press and hold A1 or A2 and the
UP arrow
while you press the power button to turn
the headset on in the Auto HF mode. Set the base
transceiver switch K1-3 to on (See Figure 4). When
you turn the unit off, the AHF mode will not be saved.
"B" Channel HF (BHF) – Press and hold B and A2
while you press the power button to turn the headset
on in the BHF mode. This will keep the B channel
open to allow hands-free communication with other
crew members. If a customer arrives, B-channel
communication will automatically be interrupted to
allow communication with the customer on A1 or A2.
Language selection – To change between English and another language, press and hold A1 and the
DOWN arrow
while you press the power button to turn the headset on. Doing this again changes
back to the first language.
Play status – Press A2 and the DOWN arrow
headset on. An example of the status you will hear is: "Headset #, Battery Full/Half/Low,
English/Espanol, Hands-free on/off, firmware version #."
HM ELECTRONICS, INC.
OPERATING INSTRUCTIONS
while you
14110 Stowe Drive, Poway, CA 92064 USA • Phone: 1-800-848-4468 Fax: (858) 552-0172
Wireless Headset
Power
light
Figure 1. Headset power button
A1
Figure 2. Headset buttons
while you press the power button to turn the
HS6100
Power
button
and power light
A2
B
HME# 400G653
Rev A
6/22/10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS6100 and is the answer not in the manual?

Questions and answers

Summary of Contents for HME HS6100

  • Page 1 HS6100 Wireless Headset OPERATING INSTRUCTIONS SETUP Power On/Off Power light To turn the power on Press and release the red power button on the headset Power earpiece. A voice message in the earpiece will say button “Headset #, Battery Full/Half/Low” and the red power light will begin blinking.
  • Page 2 Headset Registration Each HS6100 Headset must be registered for use with a specific base station. The base station thereby recognizes all headsets registered to it when their power is on, and will be able to tell the difference between them and other electronic equipment operating on similar frequencies. A maximum of 15 headsets can be registered.
  • Page 3 ® ™ For ion IQ Audio Systems, register each COMMUNICATOR as follows: • On the ion IQ base station STATUS display, press the Menu button. • On the MAIN MENU display, press the Register button. • The REGISTRATION display indicates the number of headsets already registered and how many more can be registered.
  • Page 4 Wearing the Headset Adjust the Headset to Your Head Size You can adjust the head size of HS6100 for best fit by sliding the metal headband in or out of its plastic size adjuster, as show in Figure 5. Size...
  • Page 5 Talking to Customers With your fingertip, press and release either the A1 or the A2 button and speak into the microphone. You will hear a single tone in the headset, indicating the microphone is on. When you have finished talking to the customer, press the A1 or A2 button again.
  • Page 6 Routine Operation SINGLE-LANE OPERATION DUAL-LANE OPERATION (one base station for one speaker post) (two base stations for two speaker posts) Hands-Free (HF) Mode: Hands-Free (HF) Mode: • Alert tone (single beep) sounds in headset, then • Alert tone (single beep for Lane 1, double beep for Lane 2) customer at speaker post or menu board can be heard.
  • Page 7 The European Union (EU) WEEE Directive (2002/96/EC) places an obligation on producers (manufacturers, distributors and/or retailers) to take-back electronic products at the end of their useful life. The WEEE Directive covers most HME products being sold into the EU as of August 13, 2005. Manufacturers, distributors and retailers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements.
