HME NEXEO HDX HS7000 Quick Start Manual

The NEXEO ® HS7000 is an all-in-one headset used for communicating with crew and customers in a store or
drive-thru lane environment. It uses one rechargeable lithium-ion battery (BAT70). With moderate use in a typical
environment, the headset will operate for about eight hours on a single battery charge.
HEADSET
Side View
Status
LED
Lane 1 Lane 2
Volume Up
Volume Down
Action HME
Group Chat
Icon Label Status LED Boom LED Status/Description
Lane 1
Green
Lane 2
Red
Volume
Up
Volume
Down
Group
Action
Notes: Both the Status and Boom LEDs flash slowly with alternating colors
Status LED indicates a low battery. The low battery Status LED is also accompanied by audio prompts.
Push-to-Talk mode: Press and hold any audio button (L1, L2 or Group Chat) to use in this mode (there is an audible single-tone
confirmation). Release to cease communication and exit this mode (there is an audible two-tone confirmation).
HM ELECTRONICS, INC.
2848 Whiptail Loop, Carlsbad, CA 92010 USA
Phone: 1-800-848-4468 Fax: 858-552-0172
Website: www.hme.com Email: support@hme.com
Status
Raised sections on
LED
the bezel allow users
to identify keypad
buttons by touch.
Boom
LED
Keypad Reference Table
Tap to talk to lane 1. The Status LED flashes green while the Boom LED turns on solid
Green
green. Tap again to stop. The Status LED turns solid; the Boom LED turns off.
Tap to talk to lane 2. The Status LED flashes red while the Boom LED turns on solid red.
Red
Tap again to stop. The Status LED turns solid; the Boom LED turns off.
Tap to increase volume (the headset beeps become louder as confirmation). Press and
hold to maximize volume to loudest.
Tap to decrease volume (the headset beeps become quieter as confirmation). Press and
hold to minimize volume to quietest.
Tap for group chat. Both Status and Boom LEDs flash quickly, alternating red & green.
Tap again to stop. The Status LED changes to a solid yellow in listening only mode.
If the headset is set to answer phone calls. Tap once to answer, tap again to end call.
Press the 1 or 2 key twice to put the phone call on hold and talk to a respective lane.
Press 1 or 2 once followed by the Action key to return to call. Press again to end call.
Quick Start Guide
NEXEO | HDX™ HS7000 AIO HEADSET
HEADSET
Front View
Battery Release
Latch (silver)
Power Button
(blue)
Earpad
BAT70 Battery
(not included)
Fig. 1
when the headset needs to be paired. A yellow
HME# PUB - 00072
Rev H 05/23/23
