Meter Block Diagram - ComSonics CyberTek QUALIFIER User Manual

Home Qualification System - Signal Level Meter Block Diagram
Test Signal
Connection
The Qualifier meter is powered by an internal battery and is portable in design.
A test sequence consists of the following steps:
Meter is connected to ground block or tap / pedestal of home under test.
•
User interface operation turns on the activate encoder. The activate encoder has been
•
previously setup to match the intended vehicle transmitter. The activate transmitter is
powered on and the activate signal is radiated from the internal antenna.
The vehicle transmitter receives the activation signal and verifies the coding. If the
•
coding matches, the vehicle transmitter powers on and radiates the home with a test
signal.
The input tuner section receives the test signal resulting from ingress into the home. The
•
test signal detector qualifies the test signal as originating from the test transmitter. If the
test signal qualifies, the display converter sends the level measurements to the visual
display. A 'Q' factor percentage is displayed.
Measurement data is stored to data memory by the user interface.
•
Internal Activate Antenna
Activate
Transmitter
Input Tuner
Section
User
Interface
3-9
Appendix - Qualifier System
Activate
Encoder
Test Signal
Detector Converter
Data
Memory
Battery
Power
Display
Visual
Display
