Qualifier Meter

Battery Care

The Qualifier meter uses a rechargeable battery. For recharging this battery, ComSonics
includes a single-unit battery charger as a standard accessory.
The single-unit charger's contact end (see illustration) consists of a yellow plastic housing,
with flanges on either side, and two spring-loaded prongs. It fits into the slot on the bottom
edge of the Qualifier meter, which has contacts corresponding to the charger prongs (see
illustration).
Prongs of a single-unit charger Contact end of Qualifier metert and points
To engage the contacts properly, hold the Qualifier meter face up, place the charger
connector so the flanges fit into the corresponding grooves in the Qualifier meter's contact
end, and push towards the front of the Qualifier meter. When the charger connector is
completely inserted, the prongs will be in contact with the Qualifier meter's contact points.
Plug in the charger pack to begin recharging your Qualifier meter. Fully recharging a
depleted battery takes approximately 10 to 16 hours.
When the battery charge drops below a set level, the battery low indicator ( ) appears.
The bar graph of the display blinks while this indicator is present, and shows the relative
amount of charge remaining.
1-2
