Qualifier Meter
The Qualifier meter makes available two Units of Measure to provide worldwide
measurement compatibility. The user selects between dBmV and dBµV by: (a) placing the
Qualifier meter into Units of Measure Define mode; (b) choosing between dBmV and
dBµV; and (c) selecting Quick-Tune Channels Define.
(continued from previous page)
STEP KEYPRESS
4.
5.
F2
F1 , F3 ~ F6

Units of Measure Define

During this sequence, the Channel Name, Measured Value, and
the Bar Graph are suppressed from the display.
RESULTS
The dBmV / dBµV display blinks, indicating that this setting can
be changed.
Toggles between dBmV and dBµV.
The device continues to the next sequence in the SETUP mode,
Quick-Tune Channels Define, described on the next page.
Keys remain inactive during Units of Measure Define.
1-6
or may be used.
Going straight to Step 5 leaves
current Units of Measure Define
setting unchanged and continues to
the next sequence in the SETUP
mode, Quick-Tune Channels Define.
