Appendix C: Feature Installation Utility

The Feature Installation Utility is a Windows 95/98/ME/2000/XP/NT program necessary for
the customization and installation of a user defined channel line-up set or group. Digital
channel definitions can only be installed by use of the utility. A special interface cable is
used with a standard DB-9 serial communications port. An adapter may be needed (not
supplied) for computers with DB-25 ports. Only one user defined group can reside in the
Qualifier meter. It is selected in the Qualifier meter by choosing country set 0. See section
Country Set Define.
Install Programmer Utility
Place the CD-ROM into the drive. The installation program will automatically start.
If the PC auto-start function is turned off, follow the instructions below to manually
install the program.
Manual Install:
Click Start, then click Run. Type D:\SETUP (If your CD-ROM drive is not D,
substitute with your drive letter) or choose Browse and select your drive, then select
SETUP.EXE. Click OK and follow on-screen instructions.
Run Programmer Utility
Double-click the desktop icon to start the Utility.
or
From the Program list, move the pointer to Feature Installation Utility. Then click on
Feature Intallation Utility.
Select a Channel Group
From the File Menu select Open. Click on the selected group. Click OK.
or
From the File Menu select Import. A properly formatted text file can be imported,
modified, and saved as a group. Select the text file to import and click on Open.
Note: For a sample of the format needed for an import file,
open a copy of a factory default group in a text editor
program.
