Duplo DocuCutter CC-330 Service And Parts Manual page 18

. Slitting Module, 2" x 3.5" 882-112-010A
Index
1.06.01 882-106-010A
1.06.02 882-106-020A
1.06.03 882-106-030A
1.06.04 882-106-040A
1.06.05 00H-000-0015
1.06.06 882-106-060A
1.06.07 882-106-070A
1.06.08 882-106-080A
1.06.09 882-106-090A
1.06.10 882-106-100A
1.06.11 882-106-110A
1.06.12 00B-000-6802
1.06.13 882-106-130A
1.06.14 882-106-140A
1.06.15 882-106-150A
1.06.16 882-106-160A
1.06.17 882-106-170A
1.06.18 882-106-180A
1.06.19 882-106-190A
1.06.20 00B-000-6902
1.06.21 882-106-210A
1.06.22 882-106-220A
1.06.23 882-106-230A
P/N
Frame, Slitter, 2x3.5", CC-330
Cover, Upper, Slitter, CC-330
Cover, Lower, Slitter, CC-330
Cover, Top, Slitter, CC-330
Handle, Slitter, CC-228
Shaft, Slitter, CC-330
Block, Anti Shaft Bending, CC-330
Base
, Slitting Wheel, Upper, Center, CC-330
Base,
Slitting Wheel, Upper, Side, CC-330
Collar, Slitting Wheel Holding , CC-330
Slitting Wheel, Upper, CC-330
Ball Bearing, 6802ZZ
Spring
, Compression, Wheel Tension, CC-330
Base,
Slitting Wheel, Lower, Center, CC-330
Base,
Slitting Wheel, Lower, Side, CC-330
Collar, Lower , Center Slitter, CC-330
Collar, Lower, Side Slitter, CC-330
Slitting Wheel, Lower, CC-330
Gear, CC-330
Ball Bering, 6902ZZ
Guide, Waste, Center Gutter, CC-330
Guide, Waste, Side Trim, CC-330
Plate,
Screw, Waste Guide Fastening, CC-330
Part Name
13
Qty Remarks
1
1
1
1
2
2
1
2
2
6
6
1
36
2
2
2
2
4
2
4
2
2
4
