Duplo DocuCutter CC-330 Service And Parts Manual page 16

. Cutting Knife Asm 882-105-000A
Index
1.05.01 882-105-010A
1.05.02 882-105-020A
1.05.03 882-105-030A
1.05.04 881-713-0000
1.05.05 881-714-0000
1.05.06 881-714-0000
1.05.07 881-715-0000
1.05.08 881-716-0000
1.05.09 881-717-0000
1.05.10 881-718-0000
1.05.11 882-105-110A
1.05.12 882-105-120A
1.05.13 882-105-130A
1.05.14 881-719-0000
1.05.15 882-105-150A
1.05.16 882-105-160A
1.05.17 881-720-0000
1.05.18 882-105-180A
1.05.19 881-722-0000
1.05.20 00B-000-0696
1.05.21 00B-000-1260
1.05.22 00B-00F-6900
1.05.23 00B-000-6900
1.05.24 882-105-240A
P/N
Knife, Upper, CC-330
Knife, Lower, CC-330
Bar, Knife Asm Mounting, CC-330
Bracket
, L, Upper Knife Mounting, CC-228
Bracket,
Asm, Spring, Middle, Knife Holding, CC-228
Asm, Spring, Left, Knife Holding, CC-228
Asm, Spring, Right, Knife Holding, CC-228
Nut, Middle, Knife Holding Spring, CC-228
Nut, L/R, Knife Holding Spring, CC-228
Block, R, Lower Knife Mounting, CC-330
Block, L, Lower Knife Mounting, CC-330
Chassis, Sensor Mounting, CC-330
Link, Cutting Knife, Driving, CC-228
Shaft, Cutting Knife Driving, CC-330
Arm, R, Cutting Knife Driving, CC-330
Arm, L, Cutting Knife Driving, CC-228
Block, Cutting Knife Driving, CC-330
Shutter, Cutting Knife Interrupter, CC-228
Ball Bearing, 696ZZ
Ball bearing, 1260ZZ
Ball Bearing, F6900ZZ
Ball Bearing, 6900ZZ
Bushing
Part Name
R, Upper Knife Mounting, CC-228
11
Qty Remarks
1
1
1
1
1
2
1
1
2
2
1
1
1
2
1
1
1
1
1
2
1
1
1
2
