Drip Tray

Check the drip tray at the bottom of the unit for water and or soil/waste
Pull the drip tray downward, then across towards the oven cleaner tank
Clean in warm soapy water, ensuring the drain hole is clear of any soil
build u
Re-install drip tray. Ensure it snaps back into position

Fan/Element Compartment

Open Fan/Element compartment. Disengage the top and bottom clips
(Clip screws may need to be adjusted if clip tension is too great. Use a
Flat Head Screwdriver)
If installed, remove and clean the grease filter (grease filter can be
cleaned in dishwasher). The grease filter may need to be cleaned more
regularly depending on oven usage
Remove any loose soil from the Fan/Element compartment. Wipe clean
using a clean damp cloth
For hard to remove soil spray undiluted oven cleaner onto soiled areas.
Close the Fan/Element compartment. Allow 10-15 minutes for oven
cleaner to dissolve soil
Run appropriate cleaning cycle to ensure all oven cleaner is removed
from the oven

Door Cavity

Press the two clips to release the hinged glass door
Using a warm soapy water and a clean damp cloth, wipe down the
internal surfaces of the door cavity and glass. Ensure to wipe out the
stainless steel drainage channel on the bottom of the door and make
sure the drain hole is clear of soil build up (located near door hinge)
Close hinged glass door. Ensure clips have secured glass

Air Filter (if fitted)

Remove air filter and wash in warm soapy water. Allow to dry
Re-install air filter
Depending on the work environment this may need to be done on a
weekly basis. This is the main breathing point for the internal controls of
the oven and must be kept clean and clear of debris
1
Page 5
Monthly Cleaning
2
1
2
Due to continuous product research and development,
the information contained herein is subject to change without notice.
