- Page 1 ® XLR PRO Radio Frequency (RF) Module User Guide PRELIMINARY DRAFT...
- Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of Digi International. Digi provides this document “as is,” without warranty of any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or merchantability for a particular purpose.
-
Page 3: Table Of Contents
Contents About the XLR PRO Radio Frequency (RF) Module XLR PRO RF Module Technical Specifications XLR PRO RF Module Receiver Sensitivity XLR PRO RF Module Pin Signals XLR PRO RF Module Data Rates XLR PRO Certifications FCC (United States) Certification... - Page 4 PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide...
-
Page 5: About The Xlr Pro Radio Frequency (Rf) Module
About the XLR PRO Radio Frequency (RF) Module The XLR PRO Application Name is a high performance, industrial grade long-range RF solution using Chirp Spread Spectrum (CSS) technology to maximize range and significantly increase immunity to interference. XLR PRO Application Name Technical Specifications... -
Page 6: Xlr Pro Rf Module Receiver Sensitivity
-106 1.1 Mbps -104 2.3 Mbps -100 3.1 Mbps XLR PRO Application Name Pin Signals Pin # Name Description Reserved Do not connect Reserved Do not connect Reserved Do not connect PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide... - Page 7 GPIO/Analog Input Reserved Do not connect DIO2/AD2 GPIO/Analog Input Reserved Do not connect DIO1/AD1 GPIO/Analog Input Reserved Do not connect DIO4 GPIO Reserved Do not connect DIO5/ASSOC GPIO/Associate Indicator DIO19/SPI_nATTN GPIO/SPI Attention PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide...
- Page 8 Reserved Do not connect DIO14/DIN/nConfig UART Data in nSHUTDOWN Module Shutdown Ground VDD_5V Power Supply Reserved Do not connect Reserved Do not connect Reserved Do not connect Reserved Do not connect PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide...
-
Page 9: Xlr Pro Rf Module Data Rates
9.380 0x01 12.50 0x02 28.14 0x03 37.52 0x04 65.66 0x05 87.55 0x06 140.7 0x07 187.6 0x08 290.8 0x09 387.7 0x0A 590.9 0x0B 787.8 0x0C 1191 0x0D 1588 0x0E 2392 0x0F 3189 PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide... - Page 10 PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide...
-
Page 11: Xlr Pro Certifications
Required Label Text on page 11) is placed on the outside of the final product and within the final product operation manual. 2 The XLR PRO RF module may be used only with antennas that have been tested and approved for use with this module refer to XLR PRO Approved Antennas on page 15. -
Page 12: Fcc Notices
FCC Notices IMPORTANT: The XLR PRO OEM RF Module has been certified by the FCC for use with other products without any further certification (as per FCC section 2.1091). Modifications not expressly approved by Digi International could void the user's authority to operate the equipment. -
Page 13: Ic (Industry Canada) Certification
RF power - cable loss + antenna gain <= 36 dBm eirp Fixed Base Station and Mobile Applications Digi RF Modules are pre-FCC approved for use in fixed base station and mobile applications. When the antenna is mounted at least 20cm (8") from nearby persons, the application is considered a mobile application. - Page 14 Transmitters with Detachable Antennas This radio transmitter (IC: 1846A-XLRP) has been approved by Industry Canada to operate with the antenna types listed in XLR PRO Approved Antennas on page 15 with the maximum permissible gain and required antenna impedance for each antenna type indicated.
-
Page 15: Xlr Pro Approved Antennas
OMNI RPSMA Fixed A09-F8 OMNI RPSMA Fixed A09-M7 OMNI RPSMAF Fixed A09-W7SM OMNI RPSMA Fixed A09-F0TM OMNI RPTNC Fixed A09-F1TM OMNI RPTNC Fixed A09-F2TM OMNI RPTNC Fixed A09-F3TM OMNI RPTNC Fixed PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide... -
Page 16: Yagi Antennas
Connector (dBi) Application in dB A09-Y6 2-Element Yagi Fixed/Mobile A09-Y7 3-Element Yagi Fixed/Mobile A09-Y8 4-Element Yagi Fixed/Mobile A09-Y9 4-Element Yagi Fixed/Mobile A09-Y10 5-Element Yagi 10.1 Fixed/Mobile A09-Y11 6-Element Yagi 11.1 Fixed/Mobile PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide... - Page 17 9-Element Yagi RPTNC 13.1 Fixed/Mobile A09-Y14TM 10-Element Yagi RPTNC 14.1 Fixed/Mobile A09-Y14TM 12-Element Yagi RPTNC 14.1 Fixed/Mobile A09-Y15TM 13-Element Yagi RPTNC 15.1 Fixed/Mobile A09-Y15TM 15-Element Yagi RPTNC 15.1 Fixed/Mobile Max Gain 15.1 PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide...
- Page 18 PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide...
- Page 19 PRELIMINARY DRAFT XLR PRO Radio Frequency Module User Guide...
- Page 20 © Digi International. All rights reserved Part Number 90001407 A PRELIMINARY DRAFT...
