Chapter 3

Setting parameter values

The wheels, trackball, and console keys are used to set values for
moving light parameters and channel levels.
Parameter values are displayed in the live displays. The parameter's
display format options are found under the

Using the wheels and wheel banks

The vertical wheel controls the dimmer for all fixtures. The trackball
controls pan and tilt for moving devices. When fixtures do not have pan
and tilt parameters, such as Channels, the trackball will also function as
a dimmer wheel.
Figure 15: Vertical (intensity) wheel, trackball, pan and tilt locks
Parameters are organized, by type, into wheel banks.The five flat
encoders control all parameters including the dimmer, pan, and tilt.
ATTENTION!
dedicated dimmer wheel.
Wheel banks
(Parameter
types)
Figure 16: Parameter (type) bank keys
INTENSITY
POSITION
COLOR
54
The Vector Violet has a 6th wheel which acts as a
Possible parameters
Dimmer, strobe
Pan, tilt, movement speed
Cyan, yellow, magenta, color wheels, color speed
menu.
Format
