Chapter 1

Screen elements

Screen element
Window title bar
Menu bar
Display navigation
Tabs for soft keys
Tabs for displays
Editor tool bar
Wheel Assignments
Live displays
10
What does it show?
• The show file name is displayed on the right.
• Minimize, maximize, and close window controls
are displayed on the left.
The title bar can be hidden to maximize display
real estate.
Seven menus are available on the menu bar. Tap a
menu to view the options offered.
• Standard display controls: go to previous view,
go to last view, go up on level.
• Vector icons to: open the Workspace tree, show/
hide the Window title bar, toggle soft key display
formats, and lock the display.
Tabs, which are added to panes, display soft keys
for show objects and playback components. The
object category is set using the Workspace tree.
Current status of output on the playback wings
(faders and QKeys), AB crossfader, and the master
playback.
Vector's system tool bar is context sensitive,
changing according to the current function.
The wheel display is context sensitive showing the
parameters for the selected moving device.
Wheels are also used for programming effects and
fade rate control.
A grid format shows the current output for
fixtures. The live display grid setup can be
modified in the Grid Properties dialog box.
