Live Node - Compulite Vector Violet User Manual

Node
Camera Viewer
Scheduler
Desktop list

Live node

Node
Channel
Spot
Matrix
Matrix List
Media
Server
Topo View
Tip! Use a large display pane for live fixtures.
Function
View images seen by the camera connected to Vector
on the USB port or via IP address.
The scheduler is a tool for setting events that trigger
macros according to date and time settings.
Desktop is a special display area that functions just like
the desktop on your pc. Populate it with
icons for one click or hot key operation.
Function
Displays, in the active pane, the channels in the show and their
current output.
Displays, in the active pane, the spot in the show and their
current output.
Displays the matrix programmer.
Displays a list of all matrixes defined in the Patch Manager.
Displays the media servers in the show and their current
output.
Displays the topo map defined in the Patch Manager.
VECTOR
SETTING UP AND OVERVIEW
23
