Chapter 3

Output color code

The default color scheme for the console's output shows the output
source:
Color
Yellow
Red Backround
White Background
Blue
Green
Yellow
Purple
Red
Note: Values displayed in white and red are the values normally included
when storing a cue. More specific store commands are available in the
Store Options dialog box; see the Vector Reference Guide.
52
What it means
Fixture numbers for fixtures that are active in
the editor.
Values active in the editor and currently under
wheel control.
Values in the editor, but not currently under
wheel control.
Output from Master PB values that are higher
than those in the previous cue for the same
fixtures.
Master playback output values that are lower
than those in the previous cue for the same
fixtures.
Output from the playback devices (faders and
QKeys).
Tracking in Master PB.
Redundant tracking in Master PB.
