The Sphinx Project Eighteen design
The Sphinx Project Eighteen was designed for the
ever-increasing group of quality-conscious
audiophiles.
We are very proud of the tradition connected with
the SPHINX name, especially concerning audio
quality perfection.
This service manual will help you to optimally
service and repair the Sphinx Project Eighteen True
Dual Mono Power Amplifier.
The power amp handles the largest signal peaks
and transients with ease, and has no problem with
any size and type of loudspeaker load: even the
most demanding.
These characteristics are the result of several new
technologies and components. For instance the
unique power supply which assures a stable and
noise free operation. The special toroidal
transformer (one for each channel!) of 650 VA has
the size of a 1000 VA model: safely over-specified.
Thanks to the generous energy reserve of 66,000
µF (formed by 30 capacitors in parallel), unlimited
power is available for the largest signal peaks.
Furthermore there are three completely separate
power supplies for the input section, driver section
and the logic and indicator section.
Much attention has also been paid to the physical
layout, the positioning of components and the
internal grounding. This results in a equivalent input
noise value of <1 µV (<-120 dBV): remarkable for a
pre-amp, but really astounding for a big power amp
with two transformers.
All of this means that the Project Eighteen can work
with all kind of loads from every loudspeaker: even
the most difficult ones like electrostatic and
magnetostatic...
To obtain the maximum quality from this power amp
it is necessary to use it with top quality audio
components preferably with other Sphinx
components.
Please also refer to the User Manual of the
Project Eighteen for information about
functions not described in this manual.
It is important to familiarise yourself with the
special functions, operation and possibilities
of the Sphinx Project Eighteen.

1. UNPACKING

Before leaving the factory every Project Eighteen is
subjected to stringent and extensive technical and
exterior quality inspections. This ensures the user
many years of high quality audio from a perfect-
looking product.
Attention: The power amp weighs over 24 kg!
Never lift it out of the box without someone
helping you.
We recommend owners to ship the Project
Eighteen in its original carton.
After unpacking the Project Eighteen we therefore
recommend you carefully check it for any transport
damage.
If you find any damage and the product has not
been shipped in the original carton the ensuing
repair costs will not be covered by the warranty.

2. SPHINX WARRANTY CARD

To be entitled to any warranty repairs the owner
must have send the filled out warranty card to
Sphinx or a distributor where it has been registered.
Other regulations may apply in your specific
country: when in doubt, please consult the proper
authorities.

3. CONTACTING THE MANUFACTURER

In case of any problem not covered in this manual
or if you have other questions you may contact the
Sphinx International Service Department in The
Netherlands (local time: GMT +1h) during office
hours at the following numbers:
Telephone (+31) 35 602 0302
Fax (+31) 35 602 2806
E-mail audionl@euronet.nl
It is always very helpful and efficient if you have all
relevant information about the specific product and
the problem ready.
