- Page 1 Teamline 5140 Installation Guide 03 January 2019...
-
Page 2: Table Of Contents
Contents Before you install Teamline 5140 Prerequisites Create a Skype for Business account Skype for Business requirements Exchange requirements Changing the room display title About the Teamline 5140 system The connectors Dimensions Connecting Teamline 5140 to peripherals Positioning the Teamline 5140 system... - Page 3 Pinout for StarLeaf microphone cable The connectors and pin positions Cable recommendations for room systems HDMI cables USB cables Camera cables VISCA cable requirements Pinout Teamline 5140 safety and compliance information Installation Ventilation Servicing Power requirements Operating environment Approvals information EU/EEC...
-
Page 4: Before You Install Teamline 5140
Before you install Teamline 5140 Before you install Teamline 5140 Before installing the Teamline system, read the Teamline 5140 safety and compliance information (p31). Prerequisites Ensure you have: One or two commercial displays that support a 1080p60 input format Note: Interlaced input is not supported. -
Page 5: Changing The Room Display Title
Before you install Teamline 5140 Note: Invitation emails to the Teamline system must contain the necessary attachments for conferencing facilities to function correctly. Otherwise, participants will be unable to use the Join Now option on the touchscreen. Automatic meeting responses may delete attachments;... -
Page 6: About The Teamline 5140 System
(USB 3.0) Dimensions The Teamline 5140 system is designed so that it doesn't need to be rack mounted; however, it can be wall mounted or mounted to the back of your display. Note: If you are using wireless (for example, Miracast) to connect devices to present content in meetings, ensure the system is not enclosed in a rack or behind a display. - Page 7 About the Teamline 5140 system Dimension Metric Imperial Width 150 mm 5.9 in Depth 152 mm 5.98 in Height 57 mm 2.24 in Teamline 5140, 03 January 2019 Page 7 of 33...
-
Page 8: Connecting Teamline 5140 To Peripherals
Connecting Teamline 5140 to peripherals Connecting Teamline 5140 to peripherals What's in the box? Teamline 5140 room system StarLeaf Touch touchscreen controller Wall mounting kit Cables Power cable Ethernet cable Two HDMI to HDMI cables (1.8 meters/5.9 feet) Patch cable (2 meters/6.6 feet) USB A to mini B (2.5 meters/8.2 feet) -
Page 9: Connecting The Touchscreen To The Teamline System
Connecting the touchscreen to the Teamline system Before you can use the StarLeaf Touch for your meetings, you must pair it with the Teamline system. To do this: 1. Connect the touchscreen to a Power over Ethernet (PoE) enabled port. -
Page 10: Connecting Displays And Audio
Mini DisplayPort to the screen using the supplied cable and adaptor. To do this, connect a Mini DisplayPort connector on the Teamline 5140 to a screen using a a Mini DisplayPort-to-HDMI adaptor and an HDMI-to-HDMI cable. For a two display system, connect the second display in the same way. -
Page 11: Mounting The Teamline 5140 System
Mounting the Teamline 5140 system Mounting the Teamline 5140 system The Teamline 5140 system is shipped with a mounting kit containing a VESA mount bracket, can be used to mount the system to the back of a display or to a wall. - Page 12 Mounting the Teamline 5140 system 3. Slide the system on to the VESA mount bracket. Note: The screws provided for mounting the bracket to displays may not fit all models. To attach and use the VESA bracket on a wall: 1.
-
Page 13: Mount Dimensions
Mounting the Teamline 5140 system Mount dimensions Teamline 5140, 03 January 2019 Page 13 of 33... -
Page 14: Configuring Teamline 5140
StarLeaf. Select On-premise if you are using a local version of Maestro that has been installed by StarLeaf on your local network. Connecting the system to Maestro To connect the Teamline system to Maestro: 1. -
Page 15: Changing System Settings
Note: If the address entered is invalid, you are not notified on the touchscreen. Ensure you enter the correct details. Teamline 5140, 03 January 2019 Page 15 of 33... -
Page 16: Ports And Protocols
5355 Windows devices TCP/UDP Used to resolve (LLMNR) names on the local network Inbound Port Host Protocol Notes DHCP server UDP (DHCP) Responses from DHCP server Teamline 5140, 03 January 2019 Page 16 of 33... -
Page 17: On-Premise Skype For Business 2015 Or Lync 2013
1024-65535 Audio, video, and Front end server application sharing Other client 1024-65535 TCP (PSOM) Peer-to-peer file Front end server transfer for Other client conferencing file transfer. Clients use PSOM Teamline 5140, 03 January 2019 Page 17 of 33... -
Page 18: Teamline Systems On External Networks
Skype for Business Online The full range of Skype for Business Online IP addresses is available at: https://support.office.com/en-us/article/Office-365-URLs-and-IP-address-ranges-8548a211- 3fe7-47cb-abb1-355ea5aa88a2?ui=en-US&rs=en-US&ad=US&fromAR=1#BKMK_LYO All source ports are ephemeral, that is, 1024-65535, unless otherwise specified. Teamline 5140, 03 January 2019 Page 18 of 33... -
Page 19: Outbound
Inbound Port Host Protocol Notes 50,000-50,019 TCP/UDP Audio (source port Skype for Business Online 50,000-59,999) servers Other client 50,020-50,039 TCP/UDP Audio (source port Skype for Business Online 50,000-59,999) servers Other client Teamline 5140, 03 January 2019 Page 19 of 33... -
Page 20: Internal For Teamline 5140
Skype for Business Online (source port 50,000- servers 59,999) Other client Internal for Teamline 5140 All connections from the touchscreen controller to the Teamline 5140 system use IPv6 and always originate from ephemeral ports. Port Protocol Notes 69, 443, 5000,... -
Page 21: System Led Behavior
Data Rate LED When off, 10 Mb/s data rate is (On the right when looking selected. When green, 100 Mb/s is at the port) selected. When yellow, 1000 Mb/s data rate is selected Teamline 5140, 03 January 2019 Page 21 of 33... -
Page 22: Using Cameras With Teamline 5140
Using cameras with Teamline 5140 Using cameras with Teamline 5140 The following cameras are supported with the Teamline 5140 system: Details Logitech BRIO VHD-V71 Logitech MeetUp Very small to small Small to large meeting Very small to small Use case... -
Page 23: Shelf Dimensions
Using cameras with Teamline 5140 Shelf dimensions Logitech VHD-V71 BRIO and MeetUp 150 x 175 x 200 Dimensions of required mounting shelf required (can accommodate mount connected directly cables and start up sequence) display) Note: If you are using the Logitech Meetup camera, ensure you are running the latest version of the camera firmware. - Page 24 Using cameras with Teamline 5140 VHD-V71 at 2m Logitech MeetUp at 2m For information about installing and using Logitech cameras, refer to the Logitech web site. For information about installing the VHD-V71 camera, see Installing the VHD-V71 camera (p25). Teamline 5140, 03 January 2019...
-
Page 25: Installing The Vhd-V71 Camera
1. Connect the supplied USB 2.0 cable to the USB 2.0 connector on the camera. Connect the other end to the Camera In USB connector on the Teamline system. 2. Connect power to the DC 12V power input connector on the back of the camera. Teamline 5140, 03 January 2019 Page 25 of 33... -
Page 26: Microphone Selection, Placement, And Setup
Mute button with dual-colour LED indicator to provide muting control and status Designed to be resistant to RF interference The StarLeaf microphone effectively picks up participants of all volumes within a radius of 1.5m (4ft) centered on the microphone: The effective pickup area of the microphone should be considered with the dimensions of the conference table in the meeting room to decide on the correct audio products for this environment. -
Page 27: Pinout For Starleaf Microphone Cable
Pinout for StarLeaf microphone cable The table below shows the pinout for the XLR-to-mini USB cable that is provided with the StarLeaf Microphone for use with StarLeaf room systems. Pins on XLR connector Pins on Mini USB connector Function Ground... -
Page 28: Cable Recommendations For Room Systems
To install cameras further than 5 meters from the system, you can extend cables using a third-party product called an extender. This product effectively carries the media and camera-control signals across a cat 6 Ethernet cable. StarLeaf has partnered with Sound Control Technologies to provide this solution, and is available at http://www.soundcontrol.net/solutions/#... -
Page 29: Visca Cable Requirements
Pinout The following diagram shows the pinout for the Camera Control connector on the rear of the Teamline room system: Pin Function Direction on the Teamline system Output Input Output Input Teamline 5140, 03 January 2019 Page 29 of 33... - Page 30 VISCA cable requirements Pin Function Direction on the Teamline system Output Input Teamline 5140, 03 January 2019 Page 30 of 33...
-
Page 31: Teamline 5140 Safety And Compliance Information
Allow an adequate space around the unit to promote a good air flow for cooling of the Teamline 5140. Do not block the fan inlet or outlets. Ensure that the fan intake is not placed inline with the outlet from any other fan or convection cooled device. To avoid blocking the lower side vents do not operate the Teamline 5140 on a carpet or soft surface. -
Page 32: Approvals Information
Teamline 5140 safety and compliance information Environment Temperature Humidity Operating environment 0°C to 50°C 10% to 95% (non-condensing) Non-operating environment -40°C to 60°C 10% to 95% (non-condensing) Approvals information EU/EEC The Declaration of Conformity is available on request. Directive 2006/95/EC and 2014/35/EU (Low Voltage Directive):... -
Page 33: Legal Information
StarLeaf Limited. StarLeaf Limited reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of StarLeaf Limited to provide notification of such revision or change. StarLeaf Limited provides this documentation without warranty, term, or condition of any...
