- Page 1 GTm 5140 Installation and Admin Guide 27 April 2018...
-
Page 2: Table Of Contents
LEDs Dimensions About the touchscreen controller Windows 10 user interface Skype for Business user interface Lync/Skype for Business/Exchange requirements for StarLeaf GTm 5140 Lync/Skype for Business requirements Exchange requirements How to install GTm 5140 Configuring the GTm 5140 Camera presets... -
Page 3: About The Gtm 5140 Codec
About the GTm 5140 codec About the GTm 5140 codec The connectors The figure below shows the connectors on the rear of the GTm 5140 codec. Telepresence Telepresence Network Microphone Power screen 1 screen 2 USB 2.0 Camera (USB 3.0) -
Page 4: Leds
There are Power and Status LEDs on the front of the codec. LED behavior is described in Appendix: LED behavior (p18). Dimensions The GTm 5140 is designed so that it doesn't need to be rack mounted. However, it can be wall mounted or mounted to the back of your telepresence screen. Dimension Metric... -
Page 5: About The Touchscreen Controller
About the touchscreen controller About the touchscreen controller The GTm 5140 comes with a touchscreen controller: the StarLeaf Touch 2035. You use the touchscreen controller as the means for making and controlling video calls with GTm 5140. Through the touchscreen controller, you can access the directory and contacts, recent calls, and also the screen-share controls when in a video call. -
Page 6: Lync/Skype For Business/Exchange Requirements For Starleaf Gtm 5140
Lync/Skype for Business/Exchange requirements for StarLeaf GTm 5140 Lync/Skype for Business/Exchange requirements for StarLeaf GTm 5140 Lync/Skype for Business requirements The GTm supports: Lync 2010 Server, Lync 2013 Server, Skype for Business 2015 Server Note: If the deployment is not a Lync 2013 server, ensure that the Lync 2013 user interface is enabled. -
Page 7: How To Install Gtm 5140
How to install GTm 5140 How to install GTm 5140 Before installing the StarLeaf GTm 5140, read the safety information at GTm 5140 safety compliance. Pre-requisites Before installing the GTm 5140, ensure you have the following: One or two telepresence screens that support a 1080p60 input format (use televisions that have an audio-output capability, or alternatively, you can connect loud speakers to the codec). - Page 8 > networking > network port speed. Note: By default, the GTm 5140 uses DHCP to acquire an IP address. If necessary, you can configure the GTm 5140 with a static IP address, to do so: On the touchscreen controller, go to settings >...
- Page 9 How to install GTm 5140 GTm 5140, 27 April 2018 Page 9 of 24...
- Page 10 MAC address from the bottom of the codec into the field. Mounting the camera StarLeaf recommends that when you mount the camera, you place it at the top of the screen, as opposed to the base. This makes it easier for you to see the participants on the screen while still appearing to make eye contact.
-
Page 11: Configuring The Gtm 5140
Demo/Unmanaged GTm configuration. Near-end camera control for GTm 5140 If you have connected a PTZ camera to the GTm 5140, the Camera Control tab on the home screen allows you to control it. GTm 5140, 27 April 2018 Page 11 of 24... -
Page 12: Camera Presets
There are a few methods you can use to share content from a laptop. The first, and the easiest, is to use a sharing device. After you have paired the device with the GTm 5140, plug it into your laptop and follow the instructions given for the device. The other two methods are for sharing your screen with a room or a conference without a sharing device using Skype for Business. - Page 13 The camera and microphone will come out of standby mode if there is an active call. Standby mode can be disabled using Maestro. Refer to the Knowledge Center for more information about standby mode. GTm 5140, 27 April 2018 Page 13 of 24...
-
Page 14: Mounting The Gtm 5140 Unit
Mounting the GTm 5140 unit The GTm 5140 is shipped with a wall mounting kit containing a VESA mount bracket, which can be used to mount the unit to either the back of a monitor or TV, or to a wall. To attach and use the VESA bracket with a monitor or TV: 1. -
Page 15: Mount Dimensions
2. Attach the two slightly larger black screws provided to the bottom chassis cover of the GTm 5140. 3. Slide the GTm 5140 onto the VESA mount bracket. Mount Dimensions The dimensions of the VESA mount bracket are as shown below:... - Page 16 Mounting the GTm 5140 unit GTm 5140, 27 April 2018 Page 16 of 24...
-
Page 17: Typical Installation Of Gtm 5140
Typical installation of GTm 5140 This diagram shows a typical installation of a GTm 5140 system. Configuration Connecting the controller To view settings and IP address, press settings on the Connect the controller to the network using an touchscreen controller. -
Page 18: Appendix: Led Behavior
Data Rate LED When off, 10 Mb/s data rate is (On the right when looking selected. When green, 100 Mb/s is at the port) selected. When yellow, 1000 Mb/s data rate is selected GTm 5140, 27 April 2018 Page 18 of 24... -
Page 19: Appendix: Ports And Protocols
All source ports are ephemeral, that is, 1024-65535, unless otherwise specified. Inbound Port Host Protocol Notes DHCP server UDP (DHCP) Responses from DHCP server TCP (HTTP) Endpoint control API GTm 5140, 27 April 2018 Page 19 of 24... -
Page 20: Internal For Gtm 5140
StarLeaf internal endpoint control 5152, 23456 application layer protocols) Note: All connections from the touchscreen controller to the GTm 5140 codec use IPv6 and always originate from ephemeral ports. On-premise Skype for Business 2015 or Lync 2013 Outbound Port Host... -
Page 21: Gtm On External Network
(UDP) 1024-65535 Other client Audio, and video 1024-65535 Other client Audio, video, and application sharing 50,000-59,999 Edge server Audio, and video 50,000-59,999 Edge server Audio, video, and application sharing GTm 5140, 27 April 2018 Page 21 of 24... -
Page 22: Skype For Business Online
50,059) Other client All source ports are ephemeral, that is, 1024-65535, unless otherwise specified. The full range of Skype for Business Online IP addresses is available here https://support.office.com/en-us/article/Office-365-URLs-and-IP-address-ranges-8548a211- 3fe7-47cb-abb1-355ea5aa88a2?ui=en-US&rs=en-US&ad=US&fromAR=1#BKMK_LYO GTm 5140, 27 April 2018 Page 22 of 24... -
Page 23: Inbound
(source port 50,000- servers‡ 59,999) Other client All source ports are ephemeral, i.e. 1024-65535, unless otherwise specified. ‡The full range of Skype for Business Online IP addresses is available here https://support.office.com/en-us/article/Office-365-URLs-and-IP-address-ranges-8548a211- 3fe7-47cb-abb1-355ea5aa88a2?ui=en-US&rs=en-US&ad=US&fromAR=1#BKMK_LYO GTm 5140, 27 April 2018 Page 23 of 24... -
Page 24: Legal Information
StarLeaf Limited. StarLeaf Limited reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of StarLeaf Limited to provide notification of such revision or change. StarLeaf Limited provides this documentation without warranty, term, or condition of any...
