- Page 1 StarLeaf GT Mini Installation Guide 01 February 2018...
-
Page 2: Table Of Contents
Installing the Conference Phone 2220 Installing the Conference Phone 2220 Using Group Telepresence About StarLeaf touchscreen controllers Touchscreen controller features Appendix: LED behavior Network port LED behavior StarLeaf Controller Port LED behavior Legal information StarLeaf GT Mini, 01 February 2018 Page 2 of 31... - Page 3 Third party software acknowledgments Disclaimers and notices StarLeaf GT Mini, 01 February 2018 Page 3 of 31...
-
Page 4: About The Codec
This port is for a 4P4C connector providing an RS-232 interface. This is the same connector used in RJ9, RJ10, and RJ22. There is both a serial and an IP API option for the GT Mini and a StarLeaf Room Systems API guide is available... -
Page 5: Using The Correct Hdmi And Dvi Cables
For short cable lengths of up to 5m (17 feet), use 28AWG or thicker core. For longer lengths, use 24AWG or thicker. StarLeaf does not support the use of HDMI or DVI cables of longer than 15m (49 feet) with the codec. -
Page 6: Extending The Camera Cables
About the codec Extending the camera cables StarLeaf room systems that use a PTZ camera are provided with camera connection cables of 5m in length. If you need to install the camera further than 5m from the room system, you must extend those cables. -
Page 7: Gt Mini Dimensions And Mounting
GT Mini dimensions and mounting GT Mini dimensions and mounting StarLeaf GT Mini, 01 February 2018 Page 7 of 31... -
Page 8: About The Touchscreen Controller
About the touchscreen controller Every Group Telepresence system comes with a touchscreen controller: the StarLeaf Touch 2035. You use the touchscreen controller as the means for making and controlling video calls with Group Telepresence. Through the touchscreen controller, you can access the directory and contacts. -
Page 9: How To Install Gt Mini 3330
(p7). Connecting cables to the codec 1. Using an Ethernet cable, connect the StarLeaf Controller port on the codec to the network port (PoE) on the rear of the touchscreen controller. The network port on the touchscreen controller is marked with this symbol:... - Page 10 How to install GT Mini 3330 Note: The touchscreen controller must connect directly to the codec; do not connect the touchscreen controller via a switch to the codec. Note: If you are using the StarLeaf Conference Phone 2220, refer to Installing the Conference Phone 2220 (p23).
-
Page 11: Mounting The Camera
(telepresence screen 1). Connecting to the Cloud Provisioning the room system through the Portal Either you or your reseller can register the room system using the StarLeaf Portal. To do this: 1. In the StarLeaf Portal, choose Room systems > Add room system. - Page 12 QuickConnect The touchscreen controller receives power from the Group Telepresence System. The first time it starts up it displays the screen shown below. Enter your StarLeaf QuickConnect code. The touchscreen controller displays the meeting room name and extension number as per your StarLeaf Cloud account.
- Page 13 StarLeaf microphones or 3rd party microphones. In this case, audio played into the line-in connector is played out through the device selected in Audio outputs also sent to the far end StarLeaf GT Mini, 01 February 2018 Page 13 of 31...
- Page 14 The Group Telepresence system includes a selection of adaptors to be used with the DVI-I to DVI-I cable where the video output of a PC is other than DVI-I (for example, VGA, HDMI, DVI-D). StarLeaf GT Mini, 01 February 2018 Page 14 of 31...
-
Page 15: About The Camera
Camera presets allow you to save up to five pre-defined camera positions. Users can then select these positions from the touchscreen controller. To create camera presets: 1. Use the touchscreen controller to move the camera to the required position. StarLeaf GT Mini, 01 February 2018 Page 15 of 31... - Page 16 About the camera 2. On the StarLeaf Portal, find the Edit room system page for this meeting room system and open the Audio and video settings. 3. In the Portal, enter a name for the preset and select Save. To move the camera to a preset, select Test.
- Page 17 About the camera StarLeaf GT Mini, 01 February 2018 Page 17 of 31...
-
Page 18: Audio Settings For Group Telepresence
StarLeaf GT Mini 3330 and Group Telepresence 3351 both offer phantom power through each of its XLR connectors for use by active microphones, such as the StarLeaf Microphone. The phantom power supply can be enabled or disabled here. It is compatible with active microphones, which are designed for 48V phantom power. -
Page 19: Line In Microphones
Use this setting to adjust the audio gain on the line out from the Group Telepresence system. This might be necessary to adjust the volume where you have connected external speakers to the line out connectors. StarLeaf GT Mini, 01 February 2018 Page 19 of 31... -
Page 20: Advanced Settings
API mode If you have purchased the Endpoint Control API option from StarLeaf, you can enable the API on each room system. You need to select whether you use the API over the serial connection or instead use an IP connection. -
Page 21: Typical Installation Of Gt Mini
Link/Act Gigabit Link/Act Gigabit Computer In DVI-I Video Out HDMI Amplifier and loudspeakers (Optional) Line In 360-00230 PC audio-out Network (Optional) Microphone PC video-out (XLR cable) (Optional) Telepresence screen 2 Telepresence screen 1 (Optional) StarLeaf Group Telepresence Installation Guide Page 21 of 31... -
Page 22: Using The Conference Phone 2220
If you are using the Conference Phone 2220, the installation procedure for the Group Telepresence system is slightly different. The diagram below shows how to connect the StarLeaf Touch to the Conference Phone and into the StarLeaf Controller connector on the rear of the Group Telepresence system. -
Page 23: Installing The Conference Phone 2220
Network StarLeaf Controller Only Use with any Group Telepresence or GT Mini system. Note: Do not use crossover network cables The recommended distance between Touch 2035 and Conference Phone 2220 is at least 50cm (20”). DATA PWR StarLeaf StarLeaf Power... -
Page 24: Using Group Telepresence
Information about using Group Telepresence is in the Knowledge Center. If you have any problems with Group Telepresence, for example if there are audio or video issues, contact StarLeaf technical support for guidance. To do so, go to the Knowledge Center. StarLeaf GT Mini, 01 February 2018... -
Page 25: About Starleaf Touchscreen Controllers
About StarLeaf touchscreen controllers About StarLeaf touchscreen controllers Every StarLeaf hardware endpoint is provided with a touchscreen controller. You use the touchscreen controller as the means for making and controlling video calls. Through the touchscreen controller, you can access the directory and contacts. You can use the touchscreen controller to create ad hoc conferences, and to add and remove participants. - Page 26 The StarLeaf Touch 2035 The figure below shows the features on the StarLeaf Touch 2035. The StarLeaf Phone 2120 The figure below shows the features on the front of the StarLeaf Phone 2120. Message waiting indicator Audio volume down Audio volume up...
-
Page 27: Touchscreen Controller Features
About StarLeaf touchscreen controllers Touchscreen controller features Table 1: Front panel features and controls (Phone 2120, Touch 2035) Button Description Press during a call to increase audio volume or, if you are not in a call, Audio volume press to increase the loudness of the ringer... - Page 28 Hang up Touch 2035 only. Press to end the current call Answer/Make Touch 2035 only. Press to answer an incoming call. At other times, press to access the dial screen and the directory call StarLeaf GT Mini, 01 February 2018...
- Page 29 About StarLeaf touchscreen controllers StarLeaf GT Mini, 01 February 2018 Page 29 of 31...
-
Page 30: Appendix: Led Behavior
Gigabit LED (Green) On for 1000 Mbit/s link, off for 10/100 Mbit/s link or (On the right when looking at the no link port) StarLeaf GT Mini, 01 February 2018 Page 30 of 31... -
Page 31: Legal Information
StarLeaf Limited. StarLeaf Limited reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of StarLeaf Limited to provide notification of such revision or change. StarLeaf Limited provides this documentation without warranty, term, or condition of any...
