- Page 1 StarLeaf GT Mini 3330 Installation Guide 01 April 2021...
-
Page 2: Table Of Contents
3.5mm audio connector pinout Extending the camera cables GT Mini dimensions and mounting Getting the best room system experience Optimizing your room Audio and video setup How to install GT Mini 3330 Pack contents QuickConnect StarLeaf Pronto DVI-I cable About the camera Camera control for PTZ cameras... - Page 3 LED behavior for GT Mini Network port LED behavior StarLeaf Controller Port LED behavior Using a smartboard with a GT Mini Smartboard with external PC Smartboard with internal PC GT Mini 3330 safety and compliance information Installation Ventilation Servicing Power requirements Operating environment...
-
Page 4: About The Codec
This port is for a 4P4C connector providing an RS-232 interface. This is the same connector used in RJ9, RJ10, and RJ22. There is both a serial and an IP API option for the GT Mini and a StarLeaf Room Systems API guide is available... -
Page 5: Using The Correct Hdmi And Dvi Cables
For short cable lengths of up to 5m (17 feet), use 28AWG or thicker core. For longer lengths, use 24AWG or thicker. StarLeaf does not support the use of HDMI or DVI cables of longer than 15m (49 feet) with the codec. -
Page 6: Starleaf Pronto
About the codec StarLeaf Pronto StarLeaf Pronto allows users to meet and share in an instant. When you connect Pronto to your laptop, your screen and audio are shared with the room so that you are ready to present immediately. Your StarLeaf meetings are also synchronized with the room, allowing you to join with one touch. -
Page 7: 3.5Mm Audio Connector Pinout
Ground = back Extending the camera cables StarLeaf room systems that use a PTZ camera are provided with camera connection cables of 5m in length. If you need to install the camera further than 5m from the room system, you must extend those cables. -
Page 8: Gt Mini Dimensions And Mounting
GT Mini dimensions and mounting GT Mini dimensions and mounting StarLeaf installation guide, 01 April 2021 Page 8 of 34... -
Page 9: Getting The Best Room System Experience
Position the camera to be in-line or above where people will sit in the room Configure camera presets and other audio and video settings at StarLeaf Portal > Room systems > Edit room system > Audio and video settings StarLeaf installation guide, 01 April 2021 Page 9 of 34... -
Page 10: How To Install Gt Mini 3330
How to install GT Mini 3330 How to install GT Mini 3330 Before installing a StarLeaf product, read the safety information at www.starleaf.com/safety. Pre-requisites Before installing the room system, ensure you have the following: A StarLeaf account One or two room screens that support a 1080p60 input format (use TVs/screens that have an audio-output capability, or alternatively, you can connect loud speakers to the codec). - Page 11 How to install GT Mini 3330 1. Using an Ethernet cable, connect the StarLeaf Controller port on the codec to the network port (PoE) on the rear of the touchscreen controller. The network port on the touchscreen controller is marked with this symbol: The touchscreen controller must connect directly to the codec;...
- Page 12 To connect your room system to StarLeaf you must provision it through the Portal as described in the video and instructions below. Either you or your reseller can register the room system using the StarLeaf Portal. To do this: 1. In the StarLeaf Portal, choose Room systems >...
-
Page 13: Quickconnect
QuickConnect The touchscreen controller receives power from the Group Telepresence System. The first time it starts up it displays the screen shown below. Enter your StarLeaf QuickConnect code. StarLeaf installation guide, 01 April 2021 Page 13 of 34... - Page 14 How to install GT Mini 3330 The touchscreen controller displays the meeting room name and extension number as per your StarLeaf account. This is the home screen of the touchscreen controller. The Group Telepresence System is ready to make and receive calls. An example home...
-
Page 15: Starleaf Pronto
You can connect your laptop, in order to share content, in one of two ways: StarLeaf Pronto StarLeaf Pronto allows users to meet and share in an instant. When you connect Pronto to your laptop, your screen and audio are shared with the room so that you are ready to present immediately. -
Page 16: About The Camera
(You will not see these controls if you are using a GT Mini with a USB camera.) Camera control on the GT Mini 3330: Camera presets are pre-defined camera positions. For example, a pre-defined position that points the camera at the whiteboard, or that changes the camera to a wide-angled view. - Page 17 Camera presets, enter a name for the preset and select Save. To try out presets without saving them, click Test next to a preset. To delete a preset, select Clear. StarLeaf installation guide, 01 April 2021 Page 17 of 34...
- Page 18 About the camera StarLeaf installation guide, 01 April 2021 Page 18 of 34...
-
Page 19: Audio Settings For Group Telepresence
Phantom power is a way of providing power to a microphone. The StarLeaf GT Mini 3330 and Group Telepresence 3351 both offer phantom power through each of its XLR connectors for use by active microphones, such as the StarLeaf Microphone. -
Page 20: Line In Microphones
Audio outputs. For more information, refer to 'Using the line-in connector' in How to install GT Mini 3330 (p10). Gain: Using this setting alters the gain on the line-in connector on the Group Telepresence system Disable ECAN: This setting, when selected, disables echo cancellation. - Page 21 Portal, or the gain settings of external equipment, can be adjusted to calibrate the SPL of the test tone. When you play the pink noise, the volume resets to default. StarLeaf installation guide, 01 April 2021 Page 21 of 34...
-
Page 22: Advanced Settings
API mode If you have purchased the Endpoint Control API option from StarLeaf, you can enable the API on each room system. You need to select whether you use the API over the serial connection or instead use an IP connection. -
Page 23: Typical Installation Of Gt Mini
Typical installation of GT Mini This diagram shows a typical installation of a GT Mini: StarLeaf Group Telepresence Installation Guide Page 23 of 34... -
Page 24: Using Group Telepresence
Information about using Group Telepresence is in the Knowledge Center. If you have any problems with Group Telepresence, for example if there are audio or video issues, contact StarLeaf technical support for guidance. To do so, go to the Knowledge Center. StarLeaf installation guide, 01 April 2021... -
Page 25: About Starleaf Touchscreen Controllers
About StarLeaf touchscreen controllers About StarLeaf touchscreen controllers Every StarLeaf hardware endpoint is provided with a touchscreen controller. You use the touchscreen controller as the means for making and controlling video calls. Through the touchscreen controller, you can access the directory and contacts. You can use the touchscreen controller to create ad hoc conferences, and to add and remove participants. - Page 26 Return to the home screen. Double tap to access Settings for the touchscreen Adjust the output volume of your meeting room using the icons StarLeaf installation guide, 01 April 2021 Page 26 of 34...
- Page 27 About StarLeaf touchscreen controllers StarLeaf Touch 2035/2036 The figure below shows the basic controls of the StarLeaf Touch 2035/2036: StarLeaf installation guide, 01 April 2021 Page 27 of 34...
- Page 28 About StarLeaf touchscreen controllers StarLeaf installation guide, 01 April 2021 Page 28 of 34...
-
Page 29: Led Behavior For Gt Mini
Gigabit LED (Green) On for 1000 Mbit/s link, off for 10/100 Mbit/s link or (On the right when looking at the no link port) StarLeaf installation guide, 01 April 2021 Page 29 of 34... -
Page 30: Using A Smartboard With A Gt Mini
The USB cable transmits signals (e.g. from a person touching the smartboard screen) back to the PC. To integrate with StarLeaf, you need to think of the GT Mini as being 'inserted' in the video cable between the PC and the smart board. -
Page 31: Gt Mini 3330 Safety And Compliance Information
Power requirements The GT Mini must be connected to the AC/DC adaptor approved by StarLeaf (StarLeaf part number 712-00040). The plug that connects AC power to the is the main disconnect device for the GT Mini and must always be easily accessible. -
Page 32: Operating Environment
GT Mini 3330 safety and compliance information Operating environment The StarLeaf GT Mini must only be used indoors and within the following environmental conditions: Table 2: Operating environment Environment Temperature Humidity Operating environment 0°C to 35°C 10% to 95% (non-condensing) Non-operating environment -10°C to 60°C... -
Page 33: Canada
GT Mini 3330 safety and compliance information You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Canada ICES-003 Class B Notice This Class B digital apparatus complies with Canadian ICES-003. -
Page 34: Legal Information
StarLeaf Limited. StarLeaf Limited reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of StarLeaf Limited to provide notification of such revision or change. StarLeaf Limited provides this documentation without warranty, term, or condition of any...
