Power jack and USB port

The power jack accepts the barrel plug of the output
cable from a DC power source to operate the CPAP.
The range of DC input voltage acceptable to the
CPAP is 14VDC to 19VDC.
A variety of power sources may power the CPAP.
When using a wall outlet, the AC power supply
connects to the CPAP.
An optional mobile power adaptor connects to a DC
power outlet when auto, marine, or other sources of
power are accessible.
Optional battery packs are available to power the
CPAP.
USB port
A mini-AB USB port is provided for direct data
exchange between the CPAP and a computer via a
USB data cable. This interface allows the clinician to
configure the CPAP for the patient's prescription and
allows the patient to view and email therapy data to
the clinician.
USB port Power jack
Description of CPAP system components
