Strain
Bridge
RJ-45 Pin#
12345678
D I
RIVER NSTALLATION
The EX1629 is shipped with a VTI Instruments Corp. Drivers and Product Manuals CD which
includes software drivers, user's manuals, the VTI Instruments Product Catalog, as well as some
third-party software. Please refer to the ReadMe.txt file included on the Distribution CD for
installation instructions specific to revision of the CD provided.
N C
ETWORK ONFIGURATION
With its default network configuration, the EX1629 will attempt to locate a DHCP server. If one is
found, the IP address assigned by the DHCP server will be used. Otherwise, after a timeout of 20
seconds, the unit will attempt to obtain an IP address by using AutoIP.
NOTE At any time, the EX1629 can be returned to a known, default network configuration by using the
LCI (LAN Configuration Initialize) mechanism. See Reset Button for more information.
EX1629 Preparation for Use
Wideband Output
8-pin telcom
connector (RJ-45)
Pin 1
+Excitation
10K
Pin 8
+Excitation Sense
10K
Pin 6 +Sense
Pin 3
-Sense
10K
Pin 7
-Excitation Sense
10K
-Excitation
Pin 2
350
120
User
Pin 5 -R Cal
Pin 4
+R Cal
F 2-8: W
IGURE
(1 of 48 channels)
+ Excitation
- Excitation
+Sense
Wagner
+Cal
AGND
TRIFILAR
FILTER
-Sense
-Cal
AGND
Internal
55K
Rcal
O D
IDEBAND UTPUT IAGRAM
www.vtiinstruments.com
Instrumentation
Amplifier
+
x1
430 kHz 60.3 kHz
LOW-PASS x10 LOW-PASS ADC
FILTER x100 FILTER
-
150
Hi
Lo
150
Shield
Wideband Output
+Excitation Sense
-Excitation Sense
TEDS
COMM
External customer
shunt cal
resistor terminals
35
