Vtex1629_Set_Lxibus_Configuration - VTI Instruments EX1629 User Manual

VTI Instruments Corp.
F P
UNCTION ROTOTYPE
ViStatus vtex1629_set_lxibus_configuration (ViSession vi, ViInt32 lxiLine, ViInt32 inOut, ViInt32
transmissionScope);
F P
UNCTION ARAMETERS
vi = contains a session handle to the instrument. This handle is obtained by the function and remains valid until the
session is closed.
lxiLine = an integer input value that indicates which LXI Trigger Bus channel the function will configure. Valid
input values: 0 to 7.
inOut = an integer input value that indicates whether the specified LXI Trigger Bus channel will be configured for
input or output. Valid input values: 0 or 1.
transmissionScope = an integer input value indicating whether transmissions on the specified channel will be input
from an output to the external LXI bus, or will be kept internal to the EX1629. Valid input values: 0 or 1.
D I R V
ATA TEM ESET ALUE
inOut = 0
D
ESCRIPTION
This function configures several characteristics of a specific LXI Trigger Bus channel. Specifically, it configures
channel direction and the scope of transmissions.
Decimal Hex
Value Value
0 0x00 VTEX1629_LXI_LINE_ZERO
1 0x01 VTEX1629_LXI_LINE_ONE
2 0x02 VTEX1629_LXI_LINE_TWO
3 0x03 VTEX1629_LXI_LINE_THREE
4 0x04 VTEX1629_LXI_LINE_FOUR
5 0x05 VTEX1629_LXI_LINE_FIVE
6 0x06 VTEX1629_LXI_LINE_SIX
7 0x07 VTEX1629_LXI_LINE_SEVEN
The inOut parameter configures the direction of the LXI Trigger Bus channel. The permissible values indicate the
following:
Decimal Hex
Value Value
0 0x00 VTEX1629_LXI_INPUT
1 0x01 VTEX1629_LXI_OUTPUT
The transmissionScope parameter indicates whether the specified LXI channel is configured to communicate with
other devices on the external LXI bus or simply configured to communicate on the internal LXI bus. In the case of
an output, the transmissionScope indicates whether the output will be driven out onto the external LXI bus in
addition to being driven on the internal LXI bus. In the case of an input, the transmissionScope determines if the
input is read from the external bus or read from the internal bus. The permissible values indicate the following:
Decimal Hex
Value Value
0 0x00 VTEX1629_LXI_INTERNAL
1 0x01 VTEX1629_LXI_INTERNAL_EXTERNAL
