Error Code Error Message
FFBFFC0A42 VTEX1629_ERROR_CAL_UNSET_VALUES
FFBFFC0A43 VTEX1629_ERROR_CAL_FILENAME_TOO_LONG
FFBFFC0A44 VTEX1629_ERROR_CAL_NOMINAL_CAL_NOT_PRESENT
FFBFFC0A45 VTEX1629_ERROR_INVALID_CUTOFF_FREQ
FFBFFC0A46 VTEX1629_ERROR_SHUNT_FP_VAL_UNEQUAL
FFBFFC0A47 VTEX1629_ERROR_LXI_INPUT_CONFIG_CONFLICT
FFBFFC0A48 VTEX1629_ERROR_LXI_OUTPUT_CONFIG_CONFLICT
FFBFFC0A49 VTEX1629_ERROR_LXI_INPUT_MISCONFIGURATION
FFBFFC0A4A VTEX1629_ERROR_LXI_OUTPUT_MISCONFIGURATION
FFBFFC0A4B VTEX1629_ERROR_LXI_OUTPUT_CONFLICT
FFBFFC0A4C VTEX1629_ERROR_INVALID_MODE_FOR_SOFT_TRIGGERARM
FFBFFC0A4D VTEX1629_ERROR_PRETRIGGER_NOT_SUPPORTED_YET
FFBFFC0A4E VTEX1629_ERROR_NO_SERIAL_NUMBER
FFBFFC0A4F VTEX1629_ERROR_FIFO_STREAMING_ENABLED
FFBFFC0A50 VTEX1629_ERROR_INSUFFICIENT_UPTIME_FOR_CAL
FFBFFC0A51 VTEX1629_ERROR_CAL_SELF_CAL_NOT_PRESENT
FFBFFC0A51 VTEX1629_ERROR_CAL_SELF_CAL_NOT_PRESENT
FFBFFC0A52 VTEX1629_ERROR_FPGA_TRIGINIT_NOT_IN_IDLE_STATE
FFBFFC0A53 VTEX1629_ERROR_FPGA_TRIGINIT_IDLE_TO_ACQ_TIMEOUT
FFBFFC0A54 VTEX1629_ERROR_NO_MAC_ADDR
FFBFFC0A55 VTEX1629_ERROR_CAL_IN_PROGRESS
FFBFFC0A56 VTEX1629_ERROR_CAL_BLOCKS_PRESENT
FFBFFC0A57 VTEX1629_ERROR_XML_REQUIRE_TEDS
FFBFFC0A58 VTEX1629_ERROR_TRIGINIT_FPGA_ADC_INTR_OFF
FFBFFC0A59 VTEX1629_ERROR_SHUNT_FPS_ENABLED_ON_MULTIPLE_CHANNELS
FFBFFC0A5A VTEX1629_ERROR_INVALID_TRIGGER_COUNT
FFBFFC0A5B VTEX1629_ERROR_SET_INT_SHUNT_VALUE
FFBFFC0A5C VTEX1629_ERROR_INVALID_PULLUP_VALUE
FFBFFC0A5D VTEX1629_ERROR_INVALID_DIO_DIRECTION
FFBFFC0A5E VTEX1629_ERROR_INVALID_URN_SIZE
FFBFFC0A5F VTEX1629_ERROR_INVALID_USER_DATA
FFBFFC0A60 VTEX1629_ERROR_CONFIG_FILE_NOT_PRESENT
FFBFFC0A61 VTEX1629_ERROR_INCONSISTENT_CONF_WT
FFBFFC0A62 VTEX1629_ERROR_INCONSISTENT_TRIGGER_TIMESTAMP
FFBFFC0A63 VTEX1629_ERROR_INCONSISTENT_SYNC_TIMESTAMP
FFBFFC0A64 VTEX1629_ERROR_MLAN_BUFFER_OVERFLOW
FFBFFC0A65 VTEX1629_ERROR_MLAN_BUFFER_LEN_MISMATCH
FFBFFC0A66 VTEX1629_ERROR_UNSUPPORTED_TEDS_DEVICE
EX1629 Command Set
www.vtiinstruments.com
Meaning
Missing calibration data.
Calibration file name too long.
Calibration file missing.
Invalid filter cutoff frequency.
Front panel resistor value is not equal for
blocks of 16 channels.
LXI input configuration conflicts with an
existing output.
LXI output configuration conflicts with an
existing input.
The specified LXI input line is not
configured as an input.
The specified LXI output line is not
configured as an output.
The specified LXI output conflicts with
another output.
Software arm and trigger is only
available in trigger pattern mode.
Pre-trigger samples are not yet
supported.
No serial number programmed on
device.
Read FIFO not valid. Streaming interface
is enabled.
Insufficient instrument uptime to perform
calibration. Please see User's Manual for
more details.
Self-calibration file not present.
Self-calibration data is not present.
Trigger state machine is not in the idle
state.
Time out in trigger system.
No MAC Address programmed on
device.
Some operations cannot be performed
while self-calibration is in progress.
Calibration blocks detected.
Required TEDS ID not available.
A soft sync is required before trigger
initialization can be performed.
Within sixteen channel blocks
Trigger/arm count must be greater than
zero.
Internal shunt resistor is not user
defined.
Invalid pullup value.
Invalid DIO direction.
Invalid MLAN URN size.
Invalid user data.
Specified configuration file not present.
Confidence weight is not consistent
across all channels.
Trigger timestamp is not consistent
across all channels.
Sync timestamp is not consistent across
all channels.
MicroLAN buffer overflow.
MicroLAN buffer length mismatch.
Unsupported TEDS device.
