A F
LPHABETICAL UNCTION
The following table provides a summary of the function calls used by the EX1629 along with an
abbreviated description of the function. The pages following this table are function definitions that
provide in-depth detail for each function. A sample function definition is provided immediately
following this table to illustrate what each section of the definition describes.
Command
vtex1629_abort
vtex1629_allow_all_channels
vtex1629_break_lock
vtex1629_check_lock
vtex1629_clear_stored_config
vtex1629_close
vtex1629_compare_digests
vtex1629_dio_clear_event
vtex1629_dio_clear_events_all
vtex1629_disable_logging
vtex1629_disable_streaming_data
vtex1629_enable_logging
vtex1629_enable_streaming_data
vtex1629_enable_streaming_dataEx
vtex1629_erase_teds_data
vtex1629_error_message
vtex1629_findinstr
vtex1629_get_arm_count
vtex1629_get_arm_delay
vtex1629_get_arm_source
vtex1629_get_bridge_limit
vtex1629_get_bridge_limit_enabled
vtex1629_get_cal_coefficients
vtex1629_get_cal_file
vtex1629_get_cal_file_size
vtex1629_get_cal_source
vtex1629_get_completion_resistor
vtex1629_get_conf_scanlist
vtex1629_get_confidence_limit
98
S
ET
Description
Aborts data acquisition.
Allows the user to include channels that failed
calibration in the scanlist for data acquisition.
Releases a lock on the instrument.
Queries the lock status of the instrument.
Erases the stored configuration from nonvolatile
storage.
Closes an instrument programming session.
Compares the two provided digests byte-by-
byte.
Clears the DIO event configuration for the
specified inputLine.
Clears the DIO event configuration for all
events.
Stops the logging of driver calls.
Stops streaming data from instrument.
Allows an application to log messages to a file
for later review.
Starts data streaming from instrument.
Start data streaming from instrument (expert
mode).
Erases the data on a TEDS device for one
particular channel.
Outputs the error message associated with the
statusCode parameter.
Scans the LAN for available EX1629
instruments.
Queries and returns the arm count for the
EX1629.
Queries and returns the arm delay for the
EX1629.
Queries and returns the current setting for the
arm source.
Queries and returns the minimum and maximum
bridge limit values.
Queries and returns the enabled status of the
bridge limit function.
Queries and returns the value of a selected
calibration coefficient for one or more channels.
Reads up to bufferSize characters from the
EX1629 and places them in the XML buffer.
Returns the total buffer size required to read the
cal data.
Queries and returns the current setting for the
calibration input source.
Queries and returns the mode and the value of
the completion resistor for a specific channel.
Queries and returns a list of confidence data
values that are currently configured to be
measured and stored with data acquisition.
Queries and retrieves the current confidence
limit settings.
EX1629 Command Set
