Error Code Error Message
FFBFFC0AB5 VTEX1629_ERROR_CONF_LIMIT_CHECKING_NOT_SUPPORTED_AT_CURR_FS
FFBFFC0AB6 VTEX1629_ERROR_FS_NOT_SUPPORTED_WHEN_CONF_LIMIT_CHECKING_ENABLED
FFBFFC0AB7 VTEX1629_ERROR_INVALID_COEFFICIENT_SELECTOR
FFBFFC0AB8 VTEX1629_ERROR_XML_PARSE_ERROR
FFBFFC0AB9 VTEX1629_ERROR_FAILED_TO_LOAD_FACTORY_CAL
FFBFFC0ABA VTEX1629_ERROR_PASSED_IN_ARRAYS_NOT_LARGE_ENOUGH
FFBFFC0ABB VTEX1629_ERROR_SENSOR_LED_LIT_UP_ON_ANOTHER_CHANNEL
FFBFFC0ABC VTEX1629_ERROR_TEDS_OPS_NOT_SUPPORTED_DURING_SENSOR_IDENTIFY
FFBFFC0ABD VTEX1629_ERROR_FRONT_PANEL_SHUNT_ACTIVE
FFBFFC0ABE VTEX1629_ERROR_TEDS_SHUNT_ACTIVE
FFBFFC0ABF VTEX1629_ERROR_INTERNAL_SHUNT_REMOTE_ACTIVE
FFBFFC0AC0 VTEX1629_ERROR_SENSOR_LED_ACTIVE
FFBFFC0AC1 VTEX1629_ERROR_TEDS_SHUNT_ENABLED_ON_MULTIPLE_CHANNELS
FFBFFC0AC2 VTEX1629_ERROR_TEDS_OPS_NOT_SUPPORTED_WHEN_USING_TEDS_SHUNT
FFBFFC0AC3 VTEX1629_ERROR_SCANLIST_CONTAINS_BAD_CHANNEL
FFBFFC0AC7 VTEX1629_ERROR_INVALID_LID
FFBFFC0AC8 VTEX1629_ERROR_NOT_CONNECTED
FFBFFC0AC9 VTEX1629_ERROR_ALREADY_STREAMING
FFBFFC0ACA VTEX1629_ERROR_APP_QUERY_RESPONSE_MISMATCH
FFBFFC0ACA VTEX1629_ERROR_APP_QUERY_RESPONSE_MISMATCH
FFBFFC0ACB VTEX1629_ERROR_DATA_READER_THREAD_ERROR
FFBFFC0ACB VTEX1629_ERROR_DATA_READER_THREAD_ERROR
FFBFFC0ACC VTEX1629_ERROR_INCONSISTENT_CONF_SCANLIST
FFBFFC0ACC VTEX1629_ERROR_INCONSISTENT_CONF_SCANLIST
FFBFFC0ACD VTEX1629_ERROR_INVALID_CHANNEL_LIST_LENGTH
FFBFFC0ACE VTEX1629_ERROR_INVALID_GAIN
FFBFFC0ACF VTEX1629_ERROR_INVALID_CONVERSION_CONFIG
FFBFFC0AD1 VTEX1629_ERROR_INVALID_CONF_SCANLIST_LENGTH
FFBFFC0AD2 VTEX1629_ERROR_INVALID_CONF_SCANLIST_ENTRY
FFBFFC0AD3 VTEX1629_ERROR_INVALID_PARAMETER_LIST_LENGTH
FFBFFC0AD4 VTEX1629_ERROR_INVALID_LEADWIRE_RESISTANCE_VALUE
FFBFFC0AD5 VTEX1629_ERROR_INVALID_LEADWIRE_DESENSITIZATION_FACTOR
FFBFFC0AD6 VTEX1629_ERROR_INVALID_EXCITE_POS_VOLT
FFBFFC0AD7 VTEX1629_ERROR_INVALID_EXCITE_NEG_VOLT
FFBFFC0AD8 VTEX1629_ERROR_INVALID_GAIN_SETTING
FFBFFC0AD9 VTEX1629_ERROR_INVALID_COMPRES_TYPE
FFBFFC0ADA VTEX1629_ERROR_INVALID_SHUNT_SRC
FFBFFC0ADB VTEX1629_ERROR_CONF_TOO_MANY_ENTRIES
FFBFFC0ADC VTEX1629_ERROR_FPGA_TRIGABORT_ACQ_TO_IDLE_TIMEOUT
FFBFFC0ADD VTEX1629_ERROR_TEDS_INFO_CRC_FAILURE
FFBFFC0ADE VTEX1629_ERROR_TEDS_ID_CRC_FAILURE
308
Meaning
Confidence limit checking not supported
at current sampling frequency.
Sample frequency not supported when
confidence limit checking is enabled.
Invalid coefficientSelector.
Error parsing XML file. File structure
might be incorrect.
Unable to download nominal factory
calibration file from instrument for use in
reporting self-calibration coefficients.
The passed in array(s) are not large
enough to store all the requested data
from the instrument.
Only one sensor LED can be on at a
time.
TEDS operations not allowed on the
same analog board (channels 1-15).
Sensor identification not allowed on the
same analog board (channels 1-15).
Sensor identification not allowed on the
same analog board (channels 1-15).
Sensor identification not allowed on the
same analog board (channels 1-15).
Operation not allowed when the sensor
identification LED is on.
TEDS shunt is enabled on multiple
channels belonging to the same analog
board (channels 1-15).
TEDS operation not supported when the
TEDS shunt is enabled on the same
analog board (channels 1-15).
Scanlist contains channels that failed
calibration.
Invalid link ID.
Error: Not connected.
Error: Already streaming.
Application query response mismatch.
Application query response mismatch.
Data reader thread error.
Data reader thread error.
Inconsistent confidence scanlist.
Inconsistent confidence scanlist.
Invalid channel list length.
Invalid gain.
Invalid conversion configuration.
Invalid confidence scanlist length.
Invalid confidence scanlist entry.
Invalid parameter list length.
Invalid lead wire resistance value.
Invalid lead wire desensitization factor.
Invalid positive excitation voltage.
Invalid negative excitation voltage.
Invalid gain setting.
Invalid completion resistor type.
Invalid shunt source.
Too many conf entries.
FPGA acquisition to idle timeout.
TEDS info CRC failure.
TEDS ID CRC failure.
