Page 1: Quick Installation Guide
IPC0522 1080P HD Door Station IP Camera Quick Installation Guide... - Page 2 CAUTION Do not drop or strike this equipment Do not install the equipment near any naked flames or heat sources Do not expose this unit to rain, moisture, smoke or dust environment Do not cover the opening of the cabinet with cloth and plastic or to install this unit in poor ventilated places.
-
Page 3: Product Overview
Product Overview ① Front cover ② Main body ③ Rear housing ④ Lens ⑤ IR LED ⑥ Microphone ⑦ Light sensor ⑧ PIR ⑨ White LED ⑩ Speaker ⑪ Doorbell button Unit: mm... -
Page 4: Installation
Installation 1. Loosen the screws and open the front metal cover with a torx wrench (FIG.1). Then, detach the main plastic body from the rear housing using a Philips screwdriver (FIG.2). 2. Drill holes on the wall according to the mounting position sticker (FIG.3). - Page 5 4. Connect the RJ-45 network connector and DC12V power input terminal separately (FIG.6). Then ensure the main plastic body and the rear housing are aligned and assembled properly before securing the screws (FIG.7). 5. Close the front metal cover, and tighten the two screws to secure the device (FIG.8).
-
Page 6: System Overview
System Overview Descriptions of input/output devices Micro SD Card Slot ① Reset Key ② Wi-Fi Setup Button (Wi-Fi Model Only) ③ 1. Press and hold the button for 2–5 seconds to enter the QR Scan Mode. 2. Press and hold the button for more than 6 seconds to enable the AP mode. - Page 7 System Architectures To connect the HD Door Station to the network, please deploy one of the following system architectures: (1). Use a DC12V power adapter and a network switch to connect to the network. HD Door Station (2). Use a PoE network switch to connect to the network. HD Door Station (3).
-
Page 8: Emergency Factory Default
Merit LILIN Universal ActiveX software components are required for web interface display of JPEG or H.264 Full HD video. When you login to the IP camera by Internet Explorer, the security warning dialog box will prompt the installation of the LILIN Universal ActiveX. Click Install to download it. - Page 9 IPScan software from the installation CD, and paste to your computer. Alternatively, you can execute the IPScan software from the installation CD, or download the software from the Merit LILIN website (www.meritlilin.com). To change the settings of the IP address, subnet mask, gateway, or HTTP port, you can follow the steps below: 1.
- Page 10 Configuring IP Addresses via Web Interface To change an IP address via web interface, type the default IP address (192.168.0.200) in the Internet browser and follow the steps below: 1. Login to the H.264 Full HD IP camera by the default username “admin”...
- Page 11 Once complete, you can access the IP camera’s live video by entering the default IP address via your Internet browser. As the security warning dialog box appears, click OK to download the ActiveX directly from the IP camera. Login There are two levels of user authentication, including admin and guest, that can access the IP camera.
- Page 12 The default usernames and passwords are as follows: Administrator Username admin Password pass To logon the H.264 FULL HD IP camera, please type username and password in logon HTML page and click on Submit button to enter the system. -10-...
- Page 13 66-IPC0522CSM...
