IMPORTANT SAFEGUARDS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. GRAPHIC SYMBOL EXPLANATION The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
Page 3
CAUTION Do not drop or strike this equipment. Sensitive electronics inside are vulnerable to excessive shock. Do not install the equipment near any naked flames or heat sources. Excessive heat could damage this unit. Do not expose this unit to rain or excessive moisture, avoid smoke and dust.
Page 4
CONGRATULATIONS Thank you for purchasing this Outdoor D/N CMOS HD Vandal Resistant Dome IR IP Camera. You now own one of the many fine network products we manufactured. This product has been carefully inspected under rigid quality control and should reach you in perfect condition.
WARRANTY INFORMATION Please complete the following product purchase information. The factory will requests this information when contacted for technical support, or warranty repair. It is also valuable in case of loss or theft. Purchase Date : Serial Number : Model Number :...
PART DESCRIPTION & DIMENSION Unit: mm 120° DC12V Power Input Jack (DC12V 10%) ± RJ-45 Network Connector Reset Cable To restore the server to factory default setting. Bottom Chassis Outer Cover Camera Body Network Indicator LEDs Green(LINK): Network cable connected, this LED lit. Orange(ACT): Data communications, this LED flashes.
INSTALLATION 1. Please use the enclosed hexagon screw driver to untighten the 4 screws on the outer cover (FIG.1). FIG. 1 2. Bottom chassis installation has 2 methods 2-1. Using bottom plate Use flat screw(M4.0*8) to screw bottom plate and bottom chassis together ...
Page 8
120 ° FIG. 4 3. Plug the network cable and power cable to RJ-45 network connector and DC power input jack of the IP camera (FIG.5). RJ-45 DC12V Network Cable Power Input FIG. 5 4. Then, use hexagon screw driver to screw outer cover and camera body into bottom chassis (FIG.6), do not tighten the screws yet.
Page 9
FIG. 6 FIG. 7 5. Using the screw driver to adjust zoom and focus of lens for image of video (FIG.8). Zoom Focus FIG. 8...
Page 10
H.264 HD IP Cameras OUTDOOR D/N CMOS HD VANDAL RESISTANT DOME IR IP CAMERA IPD552EX2.2/4.2 N/P IPR312SX3 INSTRUCTION MANUAL INSTRUCTION MANUAL 3. CD Software Pack SYSTEM ARCHITECTURES For connecting IPR312SX to the network, please follow one of the system architectures: (1).
(2). Use DC12V power adapter and network switch connected to a network. LAN / Internet Non-PoE Switch IPR312SX DC12V Adaptor EMERGENCY FACTORY DEFAULT Use hardware to restore factory default settings, follow these steps: 1. The "RESET" cable short 10 seconds, then release. 2.
SPECIFICATIONS OUTDOOR D/N CMOS HD VANDAL RESISTANT DOME IR IP CAMERA Model No. IPR312SX3 Focal Length 3 ~ 9mm I r i s F1.2 L e n s 6 2 . 3 ~ 2 1 . 2 ° ° Angle of view 4 5 .
Page 13
DHCP, PPPoE, DNS, RTSP, RTCP, Telnet Mobile Phone and PDA iPhone and Android support Support System Integration ONVIF C M X Free CMX support Video Display LILIN Universal ActiveX / Quick Time Embedded Linux 2.4.19 Design and specification are subject to change without notice. 66-IPR31CSE-1...
