- Page 1 GV35 User manual GV35 GPS Locator User Manual TRACGV35UM001 Revision: 1.00 http://www.queclink.com sales@queclink.com TRACGV35UM001...
- Page 2 TRACGV35UM001 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.
-
Page 3: Table Of Contents
GV35 User manual Contents 1. Introduction...........................7 1.1. Reference..........................7 1.2. Terms and Abbreviations.....................7 2. Product Overview .........................8 2.1. Check Part List ........................8 2.2. Parts List..........................9 2.3. Interface Definition ......................9 3. Getting Started ..........................11 3.1. Opening the Case ......................11 3.2. Closing the Case........................ 11 3.3. - Page 4 GV35 User manual Table Index TABLE 1: GV35 PROTOCOL REFERENCE ..................7 TABLE 2: TERMS AND ABBREVIATIONS ..................7 TABLE 3: PART LIST ..........................9 TABLE 4: DESCRIPTION OF 6 PIN CONNECTIONS ...............10 TABLE 5: ELECTRICAL CHARACTERISTICS OF IGNITION DETECTION.........13 TABLE 6: ELECTRICAL CHARACTERISTICS OF THE DIGITAL INPUT ........13 TABLE 7: ELECTRICAL CHARACTERISTICS OF DDIGITAL OUTPUT........15...
- Page 5 GV35 User manual Figure Index FIGURE 1. APPEARANCE OF GV35 ....................8 FIGURE 2. THE 6 PIN CONNECTOR ON THE GV35..............10 FIGURE 3. OPENING THE CASE....................11 FIGURE 4. CLOSING THE CASE....................11 FIGURE 5. SIM CARD INSTALLATION..................12 FIGURE 6. TYPICAL POWER CONNECTION................12 FIGURE 7.
- Page 6 GV35 User manual Revision History Revision Date Author Description of change 1.00 2012-5-17 Cid Xu Initial TRACGV35UM001 - 6 -...
-
Page 7: Introduction
GV35 User manual 1. Introduction The GV35 is a powerful GPS locator designed for vehicle or asset tracking. It has superior receiver sensitivity, fast TTFF (Time to First Fix) and supports Quad-Band GSM frequencies 850/900/1800/1900, its location can be monitored in real time or be periodically tracked by a backend server or other specified terminals. -
Page 8: Product Overview
GV35 User manual 2. Product Overview 2.1. Check Part List Before starting, check all the following items have been included with your GV35. If anything is missing, please contact your supplier. Figure 1. Appearance of GV35 TRACGV35UM001... -
Page 9: Parts List
Relay Inserted spring Relay Inserted spring Protective sleeve 2.3. Interface Definition The GV35 has a 6 PIN interface connector. It contains the connections for power and I/O. The sequence and definition of the 6PIN connector are shown in following figure: TRACGV35UM001... - Page 10 GV35 User manual Figure 2. The 6 PIN connector on the GV35 Table 4: Description of 6 PIN Connections Index Description Comment Ground Digital input, negative trigger External DC power input, 9-16V OUT1 Open drain output signal(max drive current is 150mA)
-
Page 11: Getting Started
GV35 User manual 3. Getting Started 3.1. Opening the Case Figure 3. Opening the Case Insert the triangular-pry-opener into the gap of the case as shown below, push the opener up until the case unsnapped. 3.2. Closing the Case Figure 4. -
Page 12: Installing A Sim Card
GV35 User manual Place the cover on the bottom in the position as shown in the following figure. Slide the cover follow the direction of the arrow until it snapped. 3.3. Installing a SIM Card Open the case and ensure the unit is not powered (unplug the 6Pin cable and switch the internal battery to off position). -
Page 13: Ignition Detection
IGN signal can be configured to start transmitting information to backend server when ignition is on; and enter power saving mode when ignition is off. 3.6. Digital Input There is a general purpose digital input on GV35. It is negative trigger. Table 6: Electrical Characteristics of the digital input TRACGV35UM001... -
Page 14: Digital Output
Typical Digital Input Connection 3.7. Digital Output There is a digital output on GV35 which is open drain type and can latch the output statue when there is no control. The output has a built-in over current and recovery PTC fuse and the maximum drain current is 150 mA. -
Page 15: Relay
1 - OUT1 will latch the output state during reset. 3.8. Relay There is a built-in relay on GV35. The relay can latch the output statue when there is no control to relay. The rating load of the relay is 20A/14V.. -
Page 16: Device Status Led
GV35 User manual Figure 11. Typical Connection with relay Note: 1 - Relay will latch the output state during reset. 3.9. Device Status LED Figure 12. GV35 LED on the Case TRACGV35UM001 - 16 -... - Page 17 GV35 User manual Table 9: Definition of Device status and LED Device status LED status Device is searching GSM network Fast flashing (note1) (Note3) Device has registered to GSM network. Slow flashing (Note4) GPS chip is powered off (note 2) GPS chip is searching GPS info.
