TRACGV300VCUM001 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession. -
Page 3: Table Of Contents
2. Product Overview ........................8 2.1. Check Parts List ......................... 8 2.2. Parts List ..........................9 2.3. Interface Definition ......................10 2.4. GV300VC User Cable Colour ..................11 3. Get Started ..........................12 3.1. Open the Case ........................12 3.2. Close the Case ........................12 3.3. Install the Internal Backup Battery ................... 13 3.4. Switch on the Backup Battery .................. - Page 4 TERMS AND ABBREVIATIONS..................7 TABLE 3. PARTS LIST........................9 TABLE 4. DESCRIPTION OF 16 PIN CONNECTIONS..............10 TABLE 5. GV300VC USER CABLE COLOUR DEFINITION............11 TABLE 6. GPS ANTENNA SPECIFICATION................14 TABLE 7. ELECTRICAL CHARACTERISTICS OF IGNITION DETECTION ......16 TABLE 8. ...
- Page 5 FIGURE 12. DIGITAL OUTPUT INTERNAL DRIVE CIRCUIT............18 FIGURE 13. TYPICAL CONNECTION WITH RELAY ..............18 FIGURE 14. TYPICAL CONNECTION WITH LED ...............19 FIGURE 15. GV300VC LED ON THE CASE ..................19 FIGURE 16. TYPICAL CONNECTION WITH RS232 PORT ............21 TRACGV300VCUM001...
-
Page 6: Revision History
GV300VC User Manual 0. Revision History Revision Date Author Description of change 1.00 2014-09-01 York Zhu Initial TRACGV300VCUM001 - 6 -... -
Page 7: Introduction
GV300VC User Manual 1. Introduction The GV300VC is a compact GPS tracker designed for a wide variety of vehicle tracking applications. It has multiple I/O interfaces that can be used for monitoring or controlling external devices. Its built-in GPS receiver has superior sensitivity and fast time to first fix. Its dual band CDMA2000-1x allows the GV300VC's location to be monitored in real time or periodically tracked by a backend server and mobile devices. -
Page 8: Product Overview
GV300VC User Manual 2. Product Overview 2.1 Check Parts List Before starting, check whether all the following items have been included with your GV300. If anything is missing, please contact your supplier. Figure 1. Appearance of GV300VC TRACGV300VCUM001 - 8 -... -
Page 9: Parts List
GV300VC User Manual 2.2 Parts List Table 3. Parts List Name Picture GV300VC Locator 80*49*26 mm User Cable GPS Antenna (Optional) DATA_CABLE_M (Optional) TRACGV300VCUM001 - 9 -... -
Page 10: Interface Definition
The GV300 has a 16 PIN interface connector which contains the connections for power, I/O, RS232, etc. The sequence and definition of the 16PIN connector are shown in the following figure: Figure 2. The 16 PIN Connector on the GV300VC Table 4. Description of 16 PIN Connections... -
Page 11: Gv300Vc User Cable Colour
GV300VC User Manual TRACGV300VCUM001 2.4 GV300VC User Cable Colour Table 5. GV300VC User Cable Colour definition Definition Definition Color Color Cable OUT2 Yellow Brown/White OUT3 Brown Green AD1/IN3 Black Blue OUT1 White/Black Orange Green or Pink Orange/Black White AGND Gray/ Black... -
Page 12: Get Started
GV300VC User Manual 3. Get Started 3.1 Open the Case Figure 3. Open the Case Insert the triangular-pry-opener into the gap of the case as shown above, and push the opener up until the case is unsnapped. 3.2 Close the Case Figure 4. -
Page 13: Install The Internal Backup Battery
GV300VC has an internal backup Li-ion battery. 3.4 Switch on the Backup Battery To use the GV300VC backup battery, the switch must be in the ON position. The switch on the case and the ON/OFF position are shown below. Figure 6. Switch and ON/OFF position Note: 1. -
Page 14: Install The External Gps Antenna (Optional)
GV300VC User Manual 3.5 Install the External GPS Antenna (Optional) There is a SMA GPS antenna connector on GV300VC. The GV300VC will automatically detect and use an external antenna when connected. Figure 7. GPS Antenna of GV300VC 3.5.1. GPS Antenna Specification Table 6. -
Page 15: Ignition Detection
GV300VC User Manual Figure 8. Typical Power Connection 3.7 Ignition Detection Table 7. Electrical Characteristics of Ignition Detection Logical status Electrical characteristics Active 5.0V to 32V Inactive 0V to 3V or Open TRACGV300VCUM001 - 15 -... -
Page 16: Digital Inputs
There are three general purpose digital inputs on GV300VC. They are all negative trigger. 3.8 Digital Inputs Table 8. -
Page 17: Analog Inputs
GV300VC User Manual 3.9 Analog Inputs There are two analog inputs on GV300VC, and the analog input voltage range is from 0 to 16V. The following diagram shows the recommended connection. Figure 11. Typical Analog Input Connection Note: PIN 15 is a multifunction pin: it can be configured as a digital input or an analog input. - Page 18 GV300VC User Manual Figure 13. Typical Connection with Relay Figure 14. Typical Connection with LED Note: 1. OUT1 will latch the output state during reset. 2. Many modern relays come with a flyback diode pre-installed internal to the relay itself. If the relay has this diode, ensure the relay polarity is properly connected.
-
Page 19: Device Status Led
GV300VC User Manual 3.11 Device Status LED CELL LED Figure 15. GV300VC LED on the Case Device status LED status CELL Device is searching CDMA2000 network. Fast flashing (note1) (Note 3) Device has registered to CDMA2000 network. Slow flashing (Note 4) GPS chip is powered off. -
Page 20: Serial Port/Uart Interface
GV300VC User Manual External power in and internal battery is charging. Fast flashing External power in and internal battery is fully charged. Table 10. Definition of Device Status and LED Note: 1. CDMA2000 LED cannot be configured. 2. GPS LED and PWR LED can be configured to turn off after a period of time using the configuration tool 3. - Page 21 GV300VC User Manual WARNING: This device complies with part 15 of the FCC Rules. Operation is subject to the following two con ditions: (1)This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause unde sired operation.
