Keithley System SourceMeter 2601B Instrument Specifications page 5

Voltage output headroom
Over-temperature protection
Limit/compliance
Voltage source output
settling time
Current source output
settling time
10
For sink operation (quadrants II and IV) without sink mode enabled, add 10 % of compliance range and ±0.02 % of limit settling to the
corresponding voltage source accuracy specifications. For 100 mV range add an additional 60 mV of uncertainty. Specifications apply with
sink mode enabled.
11
For sink operation (quadrants II and IV) without sink mode enabled, add 0.06 % of limit range to the corresponding current limit accuracy
specifications. Specifications apply with sink mode enabled.
12
Add 150 µs when measuring on the 1 A range.
Specifications are subject to change without notice
SPEC-2602B Rev. B / February 2014
Models 2601B, 2602B and 2604B System SourceMeter Instrument Specifications
40 V range

Maximum output voltage = 42 V – (total voltage drop across source leads).
Maximum 1 Ω source lead.
6 V range

Maximum output voltage = 8 V – (total voltage drop across source leads).
Maximum 1 Ω source lead.
Internally sensed temperature overload puts the instrument in standby mode
Bipolar limit (compliance) set with a single value
10
Voltage:

Minimum value is 10 mV; accuracy is the same as voltage source
11
Current:

Minimum value is 10 nA; accuracy is the same as current source
Time required to reach within 0.1 % of final value after source level command is
processed on a fixed range.
Voltage range
100 mV
1 V
10 V
12
40 V
Time required to reach within 0.1 % of final value after source level command is
processed on a fixed range

Values below for I × R
out
Current range
3 A
1 A to 10 mA
1 mA
100 µA
10 µA
1 µA
100 nA
Settling time
< 50 µs
< 50 µs
< 110 µs
< 150 µs
= 1 V
load
Settling time
< 80 µs (Current < 2.5 A, R
< 80 µs (R
load
< 100 µs
< 150 µs
< 500 µs
< 2 ms
< 20 ms
> 2 Ω)
load
> 6 Ω)
5 of 13
